NOVAspx
ELECTRIC, AIRLESS PAINT SPRAYER
3000 psi (207 bar , 21 MPa) Maximum Working Pressure
Model 824–012, Series A
Standard mount; complete sprayer with hose, gun,
RAC IV DripLess
Tip Guard and SwitchTip
The SHERWIN–WILLIAMS COMPANY, CLEVELAND, OHIO 44115
This manual contains important
warnings and information.
READ AND RETAIN FOR REFERENCE
OWNER'S
MANUAL
824–015
Supercedes Rev. B
Model 824–012
Rev. C
06973A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sherwin-Williams NOVAspx 824-012
Summary of Contents for Sherwin-Williams NOVAspx 824-012
- Page 1 OWNER’S MANUAL 824–015 This manual contains important warnings and information. Rev. C READ AND RETAIN FOR REFERENCE Supercedes Rev. B NOVAspx ELECTRIC, AIRLESS PAINT SPRAYER 3000 psi (207 bar , 21 MPa) Maximum Working Pressure Model 824–012, Series A Standard mount; complete sprayer with hose, gun, RAC IV DripLess Tip Guard and SwitchTip Model 824–012...
-
Page 2: Table Of Contents
........Sherwin-Williams Warranty 32 .... -
Page 3: Warnings
WARNING INJECTION HAZARD Spray from the gun, leaks or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. Fluid injected into the skin is a serious injury. - Page 4 WARNING EQUIPMENT MISUSE HAZARD Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury. INSTRUCTIONS This equipment is for professional use only. Read all instruction manuals, tags, and labels before operating the equipment. Use the equipment only for its intended purpose. If you are not sure, call your distributor. Do not alter or modify this equipment.
-
Page 5: Component Identification And Function
Component Identification and Function Model 824–012 Shown 06973A Fig. 1 Motor DC motor, 120 Vac, 15A, 1 phase Drive Assembly Transfers power from DC motor to the displacement pump Pressure Adjusting Knob Controls fluid outlet pressure ON/OFF Switch Power switch that controls 120 Vac power to sprayer Fluid Outlet Hose and spray gun is connected here Displacement Pump... -
Page 6: Setup
Setup 2. Fill the wet–cup (102). Pry off the wet-cup seal. WARNING Fill the cup 1/3 full with Graco Throat Seal Liquid (TSL), supplied. Install the wet-cup seal. If you supply your own hoses and spray gun, be sure the hoses are electrically conductive, that the 3. -
Page 7: Operation
Setup Grounding Grounded Outlets WARNING Improper installation or alteration of the grounding Grounding Prong plug will result in a risk of electric shock, fire or Fig. 3 explosion that could cause serious injury or death. 2. Do not alter the ground prong or use an adapter. 1. - Page 8 Operation How to use the RAC IV tip guard. WARNING INJECTION HAZARD To reduce the risk of serious injury, whenever you are instructed to relieve pressure, follow the Pressure Relief Tip handle shown in Procedure on page 9. spraying position. Turn handle 180 , The tip guard alerts you to the risk and helps prevent trigger gun to clear clog...
-
Page 9: Startup
Startup NOTE: Refer to Fig. 2 and the other figures referenced WARNING in the text as you start the sprayer. INJECTION HAZARD 1. Open the pressure drain valve (42). See Fig. 8. The system pressure must be manually relieved to prevent the system from 2. - Page 10 Startup b. If more coverage is needed, use a larger tip WARNING rather than increasing the pressure. FIRE AND EXPLOSION HAZARD To reduce the risk of static sparking and c. Adjust the direction of the spray pattern. See splashing when priming or flushing the Fig.
-
Page 11: Shutdown And Care
Shutdown and Care WARNING WARNING INJECTION HAZARD INJECTION HAZARD See the warning section INJECTION To reduce the risk of serious injury, HAZARD on page 3 for information on whenever you are instructed to relieve the hazard of using damaged hoses. pressure, follow the Pressure Relief Procedure on page 9. -
Page 12: Flushing
Flushing When to Flush 3. Pour one-half gallon (2 liters) of compatible solvent into a grounded metal flushing pail. Put the suction 1. Before using a new sprayer: flush out the oil hose in the pail. which was left in to protect pump parts. 4. -
Page 13: Troubleshooting
Troubleshooting WARNING INJECTION HAZARD To reduce the risk of serious injury, whenever you are instructed to relieve pressure, follow the Pres- sure Relief Procedure on page 9. Basic Problem Solving Check everything in the troubleshooting table before disassembling the sprayer. TYPE OF PROBLEM WHAT TO CHECK WHAT TO DO... - Page 14 Basic Problem Solving TYPE OF PROBLEM WHAT TO CHECK WHAT TO DO If check is OK, go to next check When check is not OK, refer to this column Electrical 5. Check motor armature commutator for burn 5. Remove motor and have motor shop (continued) spots, gouges and extreme roughness.
- Page 15 Intermediate Problem Solving TYPE OF PROBLEM WHAT TO CHECK WHAT TO DO If check is OK, go to next check When check is not OK, refer to this column Low output 3. Release gun trigger. Observe resting position of 3. If pump consistently comes to rest with (continued) pump rod (107).
- Page 16 Intermediate Problem Solving TYPE OF PROBLEM WHAT TO CHECK WHAT TO DO When check is not OK, refer to this column If check is OK, go to next check 1. Spray tip worn beyond sprayer pressure capa- 1. Replace spray tip. Spray Pattern Variations bility.
-
Page 17: Motor Test
Motor Test WARNING INJECTION HAZARD To reduce the risk of serious injury, whenever you are instructed to relieve pressure, follow the Pressure Relief Procedure on page 9. For checking armature, motor winding and brush electrical continuity. Setup Remove the drive housing. See page 24. This is to ensure that any resistance you notice in the armature test is due to the motor and not to worn gears in the drive housing. -
Page 18: General Repair Information
General Repair Information WARNING WARNING INJECTION HAZARD HOT SURFACE HAZARD To reduce the risk of serious injury, During operation, the motor and drive whenever you are instructed to relieve housing become very hot and could burn pressure, follow the Pressure Relief your skin if touched. -
Page 19: Motor Brush
Motor Brushes NOTE: Replace brushes when worn to about 0.5 in. Motor lead; do not disconnect (12.5 mm). Always check both brushes. Brush Repair Minimum 0.5” (12.5 mm) Kit 236–967, which includes spring clip 112–766, is available for motors manufactured by Pacific Scientific. Included in Brush Repair Kit 236–967 NOTE: Replacement brushes may last only half as... - Page 20 Motor Brushes 9. Test the brushes. WARNING a. Remove the pump connecting rod pin (17). See Fig. 18, page 21. MOVING PARTS HAZARD Do not touch the brushes, leads, springs b. With the sprayer OFF, turn the pressure con- or brush holders while the sprayer is trol knob fully counterclockwise to minimum plugged in to reduce the risk of electric pressure.
- Page 21 Displacement Pump Repair 2. Align the hole in the rod (107) with the connecting WARNING rod assembly (15). Use a screwdriver to push the retaining spring (18) up and push in the pin (17). INJECTION HAZARD Push the retaining spring (18) into place around To reduce the risk of serious injury, the connecting rod.
- Page 22 Motor 9. Align the new motor with the base and reinstall the WARNING screws (46). INJECTION HAZARD 10. Assemble the drive housing to the motor. Follow To reduce the risk of serious injury, steps 8 to 10 on page 24. whenever you are instructed to relieve 11.
-
Page 23: Motor Start Board
Motor Start Board 5. Install the new cord (50) in the reverse order of disassembly. 6. Install the junction box. Be sure no leads are WARNING pinched against the motor or by the motor start board. Also be sure the gasket (89) is installed. INJECTION HAZARD To reduce the risk of serious injury, On/Off Switch... -
Page 24: Drive Housing, Connecting Rod, Crankshaft
Drive Housing, Connecting Rod, Crankshaft WARNING CAUTION INJECTION HAZARD Do not allow the gear (16) to fall; it may stay at- To reduce the risk of serious injury, tached to the drive housing or to the motor. whenever you are instructed to relieve Do not lose the thrust balls (11a or 4a) or let them fall pressure, follow the Pressure Relief between the gears, which will damage the drive hous-... - Page 25 Drive Housing, Connecting Rod, Crankshaft REF A Torque to 80 in–lb (9 N.m) Quantity of three Quantity of one Apply a total of 3 fl. oz.(29 cc) of grease to gears. Note: Filter not shown 02815 Fig. 24...
-
Page 26: Pressure Control
Pressure Control 7. Loosely install the screws (63) and then torque WARNING them to 21 in–lb (2.4 N.m). INJECTION HAZARD 8. Install the front cover (13). Connect the harness To reduce the risk of serious injury, (A) to the motor start board (47). whenever you are instructed to relieve 9. -
Page 27: Pressure Transducer
Pressure Transducer WARNING INJECTION HAZARD To reduce the risk of serious injury, whenever you are instructed to relieve pressure, follow the Pressure Relief Procedure on page 9. NOTE: See Fig. 26 for this procedure. 1. Remove the displacement pump. See page 21. 2. -
Page 28: Drain Valve
Drain Valve Repair WARNING 1. Unscrew the spring retainer from the valve body. INJECTION HAZARD Remove the spring, washers and stem/ball. Clean To reduce the risk of serious injury, any debris from the ball or seat area. whenever you are instructed to relieve 2. -
Page 29: Technical Data
Technical Data DANGER LABELS The English language DANGER label shown on page 1 Power Requirements ....120 VAC, 60 Hz, is also on your sprayer. If you have painters who do not 1 phase, 15A minimum read English, order one of the following labels to apply Generator... - Page 30 Sprayer Parts Drawing Model 824–012, Series A Label See detail on page 31 REF 33 REF 32 OUTSIDE LABEL INSIDE LABEL 06974A...
- Page 31 Sprayer Parts List Model 824–012, Series A Includes items 3 to 89 as listed below Ref. Ref. Part No. Description Qty. Part No. Description Qty. 820–879 GRIP, handle 820–910 BASE, valve 821–024 MOTOR KIT 820–911 PIN, grooved, 3/32 x 1” Includes items 4a to 4g 820–912 HANDLE, drain valve...
-
Page 32: Sherwin-Williams Warranty
All written and visual data contained in this document reflects the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. The SHERWIN-WILLIAMS COMPANY, 101 PROSPECT AVENUE, CLEVELAND, OHIO 44115 PRINTED IN USA 824–015 February 1997, Revised May 1998...
