- Page 1 FL-2291 Ovens Rev. 3 (5/08) Page 1 of 10 5925 Heisley Road • Mentor, OH 44060-1833 INSTALLATION, OPERATION and MAINTENANCE MANUAL for Cres Cor HUMIDITY UNDERCOUNTER OVENS 2000 WATTS CO151XWUA5B Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
-
Page 2: Table Of Contents
Replacement Parts………………………………………...………...…………...7, 8 Illustrations; Hot Unit…………….………………………...……...…..…………...9 Wiring Diagram...10 TIMER PROGRAMMING…….……………………………………….………...…...FL-2222 SERVICE POLICY and AGENCY LIST……………………………...…...………..FL-1400 Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com 5925 Heisley Road • Mentor, OH 44060-1833 TABLE OF CONTENTS WARNING WARNING RISK OF FIRE OR ELECTRIC SHOCK... -
Page 3: Installation Instructions
Fill water pan with three (3) gallons of HOT water (see CAUTION). Use of treated water is recommended for proper operation and to maintain warranty. Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com Most jurisdictions consider our low-temperature ovens (maximum temperature is 350°F/177°C) as low-heat appliances not requiring vent hoods. -
Page 4: Operating Instructions
(1) Press START/STOP button. (2) Adjust time by using UP and DOWN arrow- buttons. (3) Press START/STOP button to restart oven. Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com 5925 Heisley Road • Mentor, OH 44060-1833 OPERATING INSTRUCTIONS PROOF... -
Page 5: Maintenance Instructions
Hard Water Spots (Stainless Steel) & Scale *Mild detergents include soaps and non-abrasive cleaners. Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com HOW TO CLEAN THE UNIT MAINTENANCE: CABINET Wipe the inside of cabinet after daily use. Leave doors slightly open to fully dry interior. -
Page 6: Trouble Shooting Guide
Refer to our Service Agency list, FL-1400 (found in the back of this manual), of authorized service centers. Instructions for replacing parts are included in replacement parts list. Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com 5925 Heisley Road • Mentor, OH 44060-1833 TROUBLE-SHOOTING GUIDE 3. - Page 7 Remove screws around top cover. Disconnect the yellow cord between top and bottom, in the back of the cabinet (see Figure 2). Lift off Hot Unit. Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com Undercounter FL-2291 Ovens Rev. 3 (5/08)
-
Page 8: Replacement Parts
Door Latch Kit Latch Strike Door Hinge Door Assembly Door Gasket Universal Angles Casters Casters w/brake Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com 5925 Heisley Road • Mentor, OH 44060-1833 REPLACEMENT PARTS: PROOF WATER HOLD Figure 3 Control Panel Hot Unit Replacement Parts Part No. - Page 9 Undercounter FL-2291 Ovens Rev. 3 (5/08) Page 9 of 10 5925 Heisley Road • Mentor, OH 44060-1833 REPLACEMENT PARTS: Include all information on nameplate when ordering parts. Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
-
Page 10: Wiring Diagram
Undercounter FL-2291 Ovens Rev. 3 (5/08) Page 10 of 10 5925 Heisley Road • Mentor, OH 44060-1833 WIRING DIAGRAM Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com...
