Cres Cor CO151X185B Installation, Operation And Maintenance Manual

Cres cor undercounter ovens operation and maintenance manual co151xua5b, co151x185b
Hide thumbs Also See for CO151X185B:

Advertisement

Table of Contents

FL-2290
Undercounter Ovens
5925 Heisley Road • Mentor, OH 44060-1833
1 of 9
Rev. 2 (2/05)
Page
877/CRES COR (273-7267) • 440/350-1100
Fax: 440/350-7267 • www.crescor.com
INSTALLATION, OPERATION and
MAINTENANCE MANUAL
for CRES COR UNDERCOUNTER OVENS
1920 WATTS
CO151XUA5B
CO151X185B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CO151X185B and is the answer not in the manual?

Questions and answers

Related Manuals for Cres Cor CO151X185B

Summary of Contents for Cres Cor CO151X185B

  • Page 1 FL-2290 Undercounter Ovens 5925 Heisley Road • Mentor, OH 44060-1833 1 of 9 Rev. 2 (2/05) Page 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com INSTALLATION, OPERATION and MAINTENANCE MANUAL for CRES COR UNDERCOUNTER OVENS 1920 WATTS CO151XUA5B CO151X185B...

  • Page 2: Table Of Contents

    5925 Heisley Road • Mentor, OH 44060-1833 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com TABLE OF CONTENTS SUBJECT INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS Illustration, Figure 1 MAINTENANCE INSTRUCTIONS How to Clean the Unit Trouble Shooting Guide Replacement Parts Illustrations; Hot Unit...

  • Page 3: Rev. 2 (2/05)

    5925 Heisley Road • Mentor, OH 44060-1833 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com INSTALLATION INSTRUCTIONS: VENTING YOUR OVEN: 1. The purpose of ventilation hoods is to direct and capture smoke, grease-laden vapors, heat, odors, or fumes. 2. Low temperature equipment (maximum temperature 250°F/121°C) does not...

  • Page 4: Operating Instructions

    5925 Heisley Road • Mentor, OH 44060-1833 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com HOW TO SET TIMER: A. Press the UP arrow-button (on the Timer) to increase the time. The longer the button is held down, the faster the time will increase.

  • Page 5: Maintenance Instructions

    5925 Heisley Road • Mentor, OH 44060-1833 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com HOW TO CLEAN THE UNIT: BEFORE cleaning the cabinet: 1. Unplug cord from wall. Allow cabinet to cool. 2. Do NOT hose cabinet with water.

  • Page 6: Replacement Parts

    5925 Heisley Road • Mentor, OH 44060-1833 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com TROUBLE-SHOOTING GUIDE, PROBLEM Cabinet does not heat, or doesn’t heat properly Blowers do not operate Heater will not shut off Vent fan does not shut off...
  • Page 7 5925 Heisley Road • Mentor, OH 44060-1833 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com Include all information on nameplate when ordering parts. ITEM DESCRIPTION 1. Switch (On/Off) 2. Timer, Digital 3. Knob, Thermostat 3. Control Board 4. Pilot Light, Yellow 5.
  • Page 8 5925 Heisley Road • Mentor, OH 44060-1833 8 of 9 Rev. 2 (2/05) Page 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com REPLACEMENT PARTS: Include all information on nameplate when ordering parts. FIGURE 3; Hot Unit w/o Top Cover (For parts description, refer to page 7.)

  • Page 9: Wiring Diagrams

    FL-2290 Undercounter Ovens 5925 Heisley Road • Mentor, OH 44060-1833 9 of 9 Rev. 2 (2/05) Page 877/CRES COR (273-7267) • 440/350-1100 Fax: 440/350-7267 • www.crescor.com WIRING DIAGRAM...
