Standard Features - True TR2RRT-2S-2S Specifications

Model:
TR2RRT-2S-2S

STANDARD FEATURES

DESIGN
• True's solid door roll-thru's are
designed with enduring quality that
protects your long term investment.
• Designed using the highest quality
materials and components to
provide the user with colder product
temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser maintains
cabinet temperatures of 33°F to 38°F
(.5°C to 3.3°C) for the best in food
preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True roll-thru's a more
effi cient low velocity, high volume
airfl ow design. This unique design
ensures faster temperature recovery
and shorter run times in the busiest of
foodservice environments.
• Top mounted refrigeration system
with evaporator positioned out of
food zone to maximize capacity.
• Hot gas condensate for energy
effi ciency.
PLAN VIEW
ELEVATION
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366 • (636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl. Fax# (001)636-272-7546 • www.truemfg.com
TR Series:
Roll-Thru Solid Door
Refrigerator
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel
doors, front, sides, rear and bottom.
• Interior - 300 series stainless steel liner
and fl oor.
• Insulation - entire cabinet structure
and solid doors are foamed-in-
place using high density, CFC free,
polyurethane insulation.
• Four (4) heavy gauge stainless steel
ramps (one per door).
• Designed to accept roll-in racks
(inboard castors) with a maximum
dimension of 27"L x 29"D x 66"H
(686 mm x 737 mm x 1677 mm).
DOORS
• Front and rear doors are 300
series stainless steel exterior and
liners. Doors opens within cabinet
dimension.
• Door locks standard.
• Lifetime guaranteed recessed door
handles. Each door fi tted with 12"
(305 mm) long recessed handle that
is foamed-in-place with a sheet
metal interlock to ensure permanent
attachment.
• Three (3) lifetime guaranteed, cam-
lift hinges per door. Full 180° open
capability with a stay open feature at
120°.
• Magnetic door gaskets of one piece
construction, removable without tools
for ease of cleaning.
• Doors are fi eld reversible.
1"
1
4 / "
4
(26 mm)
(108 mm)
83 3 / "
4
(2128 mm)
3
84 / "
4
(2153 mm)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
TRUE FOOD SERVICE EQUIPMENT
45 3 / "
8
(1153 mm)
4 1 / "
4
(108 mm)
RIGHT VIEW
Model
KCL
TR2RRT-2S-2S
LIGHTING
• Incandescent interior lighting, safety
shielded.
MODEL FEATURES
• Exterior digital temperature display,
available with either °F or °C.
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• Interior bumpers protect cabinet walls
from abuse caused by roll-in carts.
• NSF-7 compliant for open food
product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for fi nal connection to a
115/60/1 phase, 15 amp dedicated
outlet. Cord and plug set included.
115/60/1
NEMA-5-15R
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ Metal door handles (factory installed).
❒ Electronic temperature control (factory
installed).
❒ Correctional facilities options.
❒ Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant). Consult factory technical
service department for BTU information.
FRONT OF CABINET
68"
(1728 mm)
PLAN VIEW
Elevation Right Plan
TFQY55E TFQY82S TFQY98P
30"
(762 mm)
7
96 / "
8
(2461 mm)
7
36 / "
8
(937 mm)
30"
(762 mm)
3D
TFQZ423
