True TR1RRI-1S Specifications

TR Series
Roll-In Refrigerators
Swing
Model Doors
SOLID DOORS
TR1RRI-1S 1
TR2RRI-2S 2
SOLID DOORS 89" HIGH
TR1RRI89-1S 1
TR2RRI89-2S 2
* Height does not include 1" for system mechanical components.
Roll-Thru Refrigerators
Swing
Model Doors
SOLID DOORS
TR1RRT-1S-1S 2
TR2RRT-2S-2S 4
SOLID DOORS 89" HIGH
TR1RRT89-1S-1S 2
TR2RRT89-2S-2S 4
* Height does not include 1" for system mechanical components.
TR2RRI-2S
FEATURES/BENEFITS
• Oversized and balanced, environmen-
tally friendly, refrigeration system,
factory sealed and pre-lubricated for
long life.
• Food safe refrigerators hold 33°F to
38°F.
• Accepts roll-in rack (inboard castor) with
maximum dimensions of
27"W x 29"D x 66"H.
89" high models accept roll-in/thru rack
(inboard castor) with maximum dimen-
sions of 27"W x 29"D x 72"H.
(supplied by others)
• Exterior - 300 series stainless steel
front, bottom and back. Stainless steel
sides.
True Website: www.truemfg.com
For additional information regarding dimensions/specifications, please contact factory.
Cu. Crated
Ft. HP Amps Weight
1
37 / 8.9 400
3
75 1 / 11.8 706
2
1
38 / 8.9 485
3
80 1 / 11.8 786
2
All dimensions rounded up to the nearest 1/8".
Cu. Crated
Ft. HP Amps Weight
37 1 / 8.9 475
3
75 1 / 9.5 781
2
38 1 / 8.9 495
3
80 1 / 9.5 821
2
All dimensions rounded up to the nearest 1/8".
• Interior - 300 series stainless steel
walls, back, floor & door liner.
• Heavy gauge doors.
• Three rugged cam-lift hinges per door-
lifetime guaranteed. Designed for easy
product access with a full 180 degree
open capability and stay open feature at
120 degrees.
Heavy gauge stainless steel ramp
•
standard for each door.
• Exterior mounted digital electronic ther-
mometer features manual defogger.
• Interior bumpers protect cabinet.
• Foamed-in-place polyurethane high
density cell insulation (CFC Free).
• Incandescent interior lighting.
• Energy saver switch.
Cabinet Dimensions
L D H*
35 x 34 1 / x 83 3 /
2 4
68 x 34 x 83
1 / 3 /
2 4
35 x 34 1 / x 89
2
68 x 34 x 89
1 /
2
Cabinet Dimensions
L D H*
35 x 36 x 83
7 / 3 /
8 4
68 x 36 7 x 83 3
/ /
8 4
35 x 36 x 89
7 /
8
68 x 36 7 x 89
/
8
Roll-thru models feature
front and rear swing doors,
each with a heavy duty
stainless steel ramp for
roll-thru service.
Parts Department • 1-800-424-TRUE
The new
consultant
choice
for roll-in &
roll-thru
rack
applications.
TR1RRI89-1S
TR1RRT-1S-1S
• Lifetime guaranteed recessed door
handles.
• Door locks standard.
• Top mounted unit positioned out of
food zone to maximize storage capacity.
• Glass condensate pan to prevent elec-
trolysis.
• Hot gas condensate for energy
efficiency.
• Self-contained system.
• Reversible wiper gaskets for positive seal.
• Field reversible door swing.
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
Toll Free Number • 1-800-325-6152
