Standard Features - True TG2DT-2S Specifications

Model:
TG2DT-2S

STANDARD FEATURES

DESIGN
• True's solid door reach-in's are designed with
enduring quality that protects your long term
investment.
• Designed using the highest quality materials
and components to provide the user with colder
product temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Two independent, self contained refrigeration
systems; CFC free, environmentally friendly and
factory balanced.
• R134A refrigerator refrigerant - R404A freezer
refrigerant.
• Extra large evaporator coils balanced with higher
horsepower compressors and large condensers
maintains 33°F to 38°F (.5°C to 3.3°C) in the
refrigerator section and -10°F (-23.3°C) in the freezer
section.
• Sealed, cast iron, self-lubricating evaporator fan
motor(s) and larger fan blades give True reach-
in's a more effi cient low velocity, high volume
airfl ow design. This unique design ensures faster
temperature recovery and shorter run times in the
busiest of foodservice environments.
• Top mounted refrigeration system with evaporator
position out of food zone to maximize interior
capacity.
• Freezer features automatic defrost system, time-
initiated, temperature-terminated. Saves energy
consumption and provides shortest possible defrost
cycle.
• Automatic evaporator fan motor delay during defrost
cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors and
rainshield. Anodized quality aluminum sides, back
and bottom.
• Interior - NSF approved, white aluminum side walls
and back liner. 300 series stainless steel fl oor with
coved corners.
• Insulation - entire cabinet structure and solid doors
are foamed-in-place using high density, CFC free,
polyurethane insulation.
• Welded, heavy duty galvanized frame rail dipped in
rust inhibiting enamel paint for corrosion protection
inside and out.
PLAN VIEW
77"
(1956 mm)
1 3 / "
ELEVATION
16
(31 mm)
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366 • (636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl. Fax# (001)636-272-7546 • www.truemfg.com
TG Series:
Reach-In Solid Door Dual Temperature
Refrigerator / Freezer
• Frame rail fi tted with 4" (102 mm) diameter stem
castors - locks provided on front set.
DOORS
• 300 series stainless steel exterior and liners. Doors
open within cabinet dimension.
• Door locks standard.
• Lifetime guaranteed recessed door handles. Each
door fi tted with 12" (305 mm) long recessed handle
that is foamed-in-place with a sheet metal interlock
to ensure permanent attachment.
• Positive seal self-closing doors with 120° stay open
feature. Lifetime guaranteed door hinges.
• Magnetic door gaskets of one piece construction,
removable without tools for ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated wire shelves
21 13 / " x 28
16
supports included per shelf. Shelves adjustable on 6"
(153 mm) increments.
• Four (4) different interior kits available (see Kit
Options). Pilasters and tray slides require fi eld
installation.
LIGHTING
• Compartmentalized incandescent interior lighting
(one per section), safety shielded.
MODEL FEATURES
• Two (2) exterior digital temperature displays,
available with either °F or °C .
• Evaporator is epoxy coated to eliminate the potential
of corrosion.
• Backguard in freezer section improves airfl ow.
• Minimum wattage heater in cabinet frame and
freezer door.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and ready for
fi nal connection to a 115/208-230/60/1 phase, 3 pole,
4 wire, 20 amp dedicated outlet. Cord and plug set
included.
1"
(26 mm)
3
78 / "
16
(1986 mm)
3
84 / "
16
(2139 mm)
5"
(127 mm)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
TRUE FOOD SERVICE EQUIPMENT
13 / " (555 mm x 732 mm). Four (4) shelf
16
115/208-230/1
NEMA-14-20R
9
5 / "
16
(142 mm)
1
44 / "
4
(1124 mm)
RIGHT VIEW
4"
(102 mm)
Model
KCL
TG2DT-2S
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/fl anged legs.
❒ 6" (153 mm) stainless steel legs.
❒ Stainless steel rail skirt for use with legs (fi eld
installed).
❒ Metal door handles (factory installed).
❒ Novelty baskets.
❒ Additional shelves.
❒ Electronic temperature control (factory installed).
❒ Correctional facilities options.
❒ Curb mountable units.
❒ Remote cabinets (condensing unit supplied by others;
system comes standard with 404A expansion valve
and requires R404A refrigerant). Consult factory
technical service department for BTU information.
KIT OPTIONS
Upcharge applies. Lead time may apply.
❒ Kit #1: Nine (9) sets of #1 type tray slides and pilasters
(fi eld installed), bottom support of one (1) 18"L x
26"D (458 mm x 661 mm) pan or two (2) 14"L x 18"D
(356 mm x 458 mm) pans.
❒ Kit #2: One (1) set half-section #2 steel rod tray slides
and pilasters (fi eld installed), rim support of one (1)
18"L x 26"D (458 mm x 661 mm) pan.
❒ Kit #3: Six (6) sets of universal type tray slides and
pilasters (fi eld installed), bottom support of one (1)
18"L x 26"D (458 mm x 661 mm) pan, two (2) 14"L x
18"D (356 mm x 458 mm) pans or two (2) 12"L x 20"D
(305 mm x 508 mm) pans.
❒ Kit #4: Three (3) chrome shelves 21
(555 mm x 732 mm). Four (4) shelf supports included
per shelf (fi eld installed); adjustable on 6" (153 mm)
increments. Optional wall mounted shelf support
pilasters (fi eld installed) with four (4) shelf clips per
shelf available; adjustable on
(must order at time of cabinet order).
❒ Additional kit option components available
individually.
51 3 /
8
(1305 mm)
2 5 / "
16
19 1 / "
16
(59 mm)
(485 mm)
15
36 / "
16
(939 mm)
5
34 / "
8
(880 mm)
PLAN VIEW
Elevation Right
TFQX99E TFQY57S
13 3
/ "L x 28 / "D
16 16
1
/ " (13 mm) increments
2
"
1
3 / "
4
(83 mm)
60 1 / "
2
(1537 mm)
17
23 / "
32
(598 mm)
Plan 3D
TFQX99P TFQX993
