1. Transparent protective lid.
2. LED indicator.
3. Resettable frangible element.
4. SmartBracket mounting panel.
5.
Tamper button
surface or remove it from the mounting panel.
6. Power button.
7. QR code with the device ID for pairing the button with an Ajax hub.
8. Hole for the special tool.
9. Special tool (key).
Compatible hubs and range extenders
An Ajax hub with the rmware
device to operate.
Hubs
. Triggers when someone tries to detach the button from the
OS Malevich 2.17
and higher is required for the
Radio signal range extenders
