MISTRAL TC60 BOTTLE COOLER
Installation, Operating and Servicing
Instructions
Please make a note of your product details for
future use:
Date Purchased: _________________________
Model Number: __________________________
Serial Number: __________________________
Dealer: ________________________________
________________________________
_______
A34/108 R1
Page | 1
ECN 4825 October 2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IMC MISTRAL TC60
Summary of Contents for IMC MISTRAL TC60
- Page 1 MISTRAL TC60 BOTTLE COOLER Installation, Operating and Servicing Instructions Please make a note of your product details for future use: Date Purchased: _________________________ Model Number: __________________________ Serial Number: __________________________ Dealer: ________________________________ ________________________________ _______ A34/108 R1 ECN 4825 October 2022 Page | 1...
-
Page 2: Table Of Contents
CONTENTS WARRANTY ....................... 3 DELIVERY......................3 INTODUCTION ....................3 INSTALLATION ....................5 TURNING LED LIGHTS ON-OFF ..............6 REVERSING DIRECTION OF DOOR ..............7 ELECTRICITY SUPPLY CONNECTION ............9 COMMISSIONING ..................... 9 CHANGING THE CONTROLLER SET POINT ..........10 USING YOUR BOTTLE COOLER ..............10 CLEANING ....................... -
Page 3: Warranty
WARRANTY These bottle coolers are guaranteed by Lincat/IMC for 2 years from the date of purchase from Lincat/IMC, or from one of its stockists, dealers or distributors. The guarantee is limited to the replacement of faulty parts or products and excludes any consequential loss or expense incurred by the purchaser. - Page 4 Mistral Dimensions: 500 mm 600mm 1850mm Page | 4...
-
Page 5: Installation
INSTALLATION For the Installer These Instructions contain important information designed to help the user obtain the maximum benefit from their investment in a Lincat/IMC Mistral Bottle Cooler. Please read them carefully before starting work, and consult with the supplier in the event of any queries. -
Page 6: Turning Led Lights On-Off
TURNING LED LIGHTS ON-OFF The cabinet is illuminated by a LED light unit, this light can be turned on or off by depressing the switch that is located on the plinth next to the digital controller. When the switch is flush the lights are on. Light Switch Page | 6... -
Page 7: Reversing Direction Of Door
REVERSING DIRECTION OF DOOR On delivery the door of the Mistral TC60 is hinged on the right hand side of the cabinet. However, it is possible to move the hinge to the other side of the cabinet by following the steps below. - Page 8 Unscrew the fixings retaining the door handle and the hinge pin. Remove the door handle. Refit the door handle on the right hand side of the door and screw in the handle fasteners. Apply one drop of Loctite Studlock 270 to the hinge pin thread. ...
-
Page 9: Electricity Supply Connection
ELECTRICITY SUPPLY CONNECTION Position the unit in the chosen site. The electricity supply connection should be made to a power outlet socket or isolator mounted on the wall close to the machine. This socket or isolator must be accessible once the machine is installed. -
Page 10: Changing The Controller Set Point
CHANGING THE CONTROLLER SET POINT The electronic temperature controller is factory set to 4°C and will cycle the air temperature between 2°C and 6°C. The set point can be adjusted between 0°C and 18°C by following the button sequence below: Press SET the current SET Point will be displayed, if Loc is displayed then the controller is locked, to unlock press and hold the SET button for 3 seconds,... -
Page 11: Cleaning
Hook the shelf supports in the required location. Ensure all shelf supports are at the same height for a level shelf. The support strips are numbered to aid positioning. Replace the shelf. Extra shelves are available from Lincat/IMC. Page | 11... -
Page 12: Maintenance
Other than regular cleaning the unit requires no maintenance by the end user. It is recommended that the unit is serviced by a Lincat/IMC approved engineer at least once a year. Details of IMC Service Contracts are available on application. -
Page 13: Do's And Don'ts
DO’S AND DON’TS Install on a level surface. Ensure plug is accessible with the unit installed. Regularly clean the condenser and compressor. Rotate stock of bottles. Don’t Sit or stand on the unit worktop. Don’t Load with boxed goods. Don’t Leave the doors open. Don’t Cover the shelves with any protective materials which may obstruct air circulation through them. -
Page 14: End Of Life Disposal
END OF LIFE DISPOSAL At the end of its useful life the unit must be disposed of correctly and safely, to meet the requirements of EU legislation regarding the recovery of ozone depleting substances. The unit must be sent to a specialist recovery, recycling and disposal site that is licensed for the disposal of refrigerated equipment. -
Page 15: Spare Parts List
SPARE PARTS LIST Mistral TC60 Part No Description A11/264 Door Gasket A12/055 Pilaster Strip A12/041 Z1 Shelf A12/082 Wine Shelf A12/036 Shelf Clip (4 per shelf) A21/011 Lock, clip & keys G30/550 Electronic Controller G60/348 Mains Cable G60/349 Mains cable EU plug... -
Page 16: Ordering Spare Parts
For installations outside the UK please contact your supplier. For information on IMC spares and service support (if applicable), please call Lincat on +44 (0) 1522 875520. Alternatively, contact us via email: Lincat Spares Desk E-mail: spares@Lincat.co.uk...
