Kebo F95-9512CH Installation Instructions Manual

4" lavatory faucet

Advertisement

in.
dans
her(17).
For more information, visit our web site: www.bathdepot.ca/kebo-brand
Pour plus d'information, visitez notre site web: www.baindepot.com/marque-kebo

Tools You May Need

Outils requis
Adjustable wrench
Clé à molette
Groove joint plier
Pinces multiprises
Pipe tape
Ruban teflon
Allen key
Clé hexagonale
F95-9512CH
4" LAVATORY FAUCET
Solid brass construction,
Ceramic cartridge,
Ceramic cartridge,
¼ turn ceramic cartridge,
Deluxe finish,
Mechanical pop-up included,
Cartridge with limited lifetime warranty,
Easy installation.
ROBINET DE LAVABO 4"
Construction de laiton solide,
Cartouche de céramique,
Cartouche de céramique ¼ de tour,
Fini luxueux,
Bonde mécanique incluse,
Garantie à vie limitée sur les cartouches,
Installation simple.
Flow rate chart
Diagramme de débit
6
5
4
3
2
1
0
10
20
30
40
Flow pressure in PSI / Volume de débit en PSI
1 GPM = 3.785 LPM
PSI
10
20
30
40
LPM
2.4
3.8
4.6
5.3
Because of difference of city
water system or others,
water pressure may differ, and
cause the flow rate to
change a little bit.
En raison des différences entre
les systèmes d'eau de ville
ou autre, la pression d'eau
peut varier et provoquer un
léger changement dans le débit.
50
60
50
60
5.4
6.6
Rev 25, July, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F95-9512CH and is the answer not in the manual?

Questions and answers

Martine
July 3, 2025

Comment changer la cartouche du robinet Kebo F95-9512

Subscribe to Our Youtube Channel

Summary of Contents for Kebo F95-9512CH

  • Page 1 Clé hexagonale peut varier et provoquer un léger changement dans le débit. For more information, visit our web site: www.bathdepot.ca/kebo-brand Pour plus d'information, visitez notre site web: www.baindepot.com/marque-kebo Rev 25, July, 2022...
  • Page 2 Plastic pop-up installation / Installation de la bonde mécanique en plastique Gasket Flange / Coupole 1. Install plastic washer, rubber washer and lock nut onto pop-up body from basin Joint underneath. Insert flange and gasket into basin and then screw flange to connect with pop-up Rubber washer body.
  • Page 3 Replacement parts / Pièces de remplacement Faucet Spec Spécification du robinet p-up RP-HENT12HOT RP-HENT12COLD Description Quantity Factory No. RP No. Numéro Description Quantité Numéro d'usine Numéro de RP. Handle / Poignée 1H01104CP Allen screw / Vis hexagonale 1L20001NT Button / Bouton 1C00045NC Base / Base 1E00892CP...
  • Page 4 1. Place plastic gasket(16) below decorative plate(7) and insert faucet into the basin. Placer le joint de plastique(16) sous la plaque décorative(7) et insérer le robinet dans les trous. 2. Secure faucet to sink with mounting nut(19), metal washer(18) rubber washer(17). Tighten mounting nut(19).
  • Page 5 À qui la garantie s’applique-t-elle? KEBO offre une garantie limitée de 25 ans à partir de la date d’achat, exclusive au premier acheteur et tant qu’il réside dans la propriété. Cette garantie s’applique aux robinets monotrou, 4’’, 8’’, aux robinets de bain, de bain-douche, de cuisine ainsi qu’à la robinetterie de douche. La garantie est destinée à...
  • Page 6 To whom does this warranty apply? KEBO offers a 25-year limited warranty from the date of purchase, exclusive to the first buyer as long as he/she resides in the same property. The warranty applies to single-hole, 4", 8", bathtub, tub-shower, kitchen and shower faucets. The warranty is intended for residential and/or domestic use.
