Kebo SH-PN-60211 Quick Start Manual

Shower column
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
Shower installation only
Installation pour douche seulement
r
t la
JETS
Tools You May Need
Outils requis
Adjustable wrench
Clé à molette
Groove joint plier
Pinces multiprises
Pipe tape
Ruban teflon
Allen key
Clé hexagonale
For more information , visit our web site
Pour plus d'information, visitez notre site web
SH-PN-60211
SHOWER COLUMN
Pressure balance valve,
Solid brass construction with deluxe finish,
7-7/8" rain shower head,
Hand shower,
59" steel braided hose,
Cartridge with limited lifetime warranty,
Easy to install.
COLONNE DE DOUCHE
Pression balancée,
Construction en laiton solide de fini luxueux,
Douche pluie 7-7/8",
Douchette,
Flexible tressé de métal 59",
Garantie à vie limitée sur les cartouches,
Installation simple.
Flow rate chart
Diagramme de débit
15
13
11
9
7
5
3
0
10
20
Hand shower
Flow pressure in PSI / Volume de débit en PSI
1 GPM = 3.785 LPM
Hand shower/ Douchette
PSI
10
20
L/MIN
3.5
4.0
Spout / Bec
PSI
10
20
L/MIN
4.0
5.2
Shower head / Pomme de douche
PSI
10
20
L/MIN
3.8
5.7
water system or others,
water pressure may differ, and
cause the flow rate to
change a little bit.
En raison des différences entre
les systèmes d'eau de ville
ou autre, la pression d'eau
peut varier et provoquer un
léger changement dans le débit.
www.kebofaucet.com
www.kebofaucet.com
30
40
50
60
Spout
Shower Head
30
40
50
60
5.8
6.8
7.8
10.0
30
40
50
60
6.2
7.0
7.9
8.6
30
40
50
60
7.6
8.4
9.9
13.2
08/01/16 Rev.A
