True GDIM-26 Specifications

Glass Door Merchandisers
Ice Merchandisers
Swing Cu.
Model Doors Ft.
WITH TANK
GDIM-26 1 26
GDIM-49 2 49
WITHOUT TANK
GDIM-26NT 1 26
GDIM-49NT 2 49
Rosewood and black vinyl exterior available at no extra charge.
† Depth does not include 1 3 / " for door handle.
8
GDIM-26NT
FEATURES/BENEFITS
• Oversized environmentally friendly
(134A) refrigeration system, factory
sealed and prelubricated for long life.
• Holds 20°F to 25°F.
• Exterior - durable and permanent non-
peel or chip white laminated vinyl.
Interior - attractive, NSF approved, white
•
aluminum with 300 series stainless steel
floor.
• GDIM-26 & GDIM-49 standard with 12"
basin to protect from melt-down of prod-
uct.
• GDIM-26NT & GDIM-49NT standard
without 12" basin for additional capacity
requirements (no extra charge).
• Standard backguard and floor rack
improve airflow.
True Website: www.truemfg.com
For additional information regarding dimensions/specifications, please contact factory.
Floor Crated
Racks HP Amps Weight
1 1 / 9.8 325
3
2 1 / 10.1 500
2
1
1 / 9.8 375
3
2 1 / 10.1 580
2
All dimensions rounded up to the nearest 1/8".
GDIM-49
• Capacity - GDIM-26 holds 50 eight
pound bags; GDIM-49 holds 100 eight
pound bags.
GDIM-26NT holds 54 eight pound
bags; GDIM-49NT holds 117 eight
pound bags.
• Fluorescent interior lighting.
• Integrated door light (IDL) standard.
Energy efficient, triple pane, thermal
•
insulated glass doors.
• Extruded, aluminum door frames.
• Foamed-in-place polyurethane high den-
sity cell insulation (CFC Free).
• Automatic defrost system time-initiated,
temperature-terminated.
• Automatic evaporator fan motor delay
during defrost cycle.
Cabinet Dimensions
L D† H
30 x 29 x 78
1 / 1 /
2 4
54 x 29 x 78
1 / 1 /
2 4
30 x 29 1 / x 78 1 /
2 4
54 x 29 x 78
1 / 1 /
2 4
Parts Department • 1-800-424-TRUE
Our floor
space saving
ice merchandisers
uniformly match True
GDM refrigerators and
freezers.
• Minimum wattage heater in cabinet frame
and doors.
• Bottom mount compressor.
• Energy efficient.
• Available with optional legs or 2
diameter castors.
• Optional black interiors available.
Upcharge and lead times will apply.
• See our website www.truemfg.com for the
latest color & sign offerings.
Bottom Mounted Units Have...
• Allows for top storage.
• Compressor can be serviced easily, and
accessed by a single repairman.
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
Toll Free Number • 1-800-325-6152
GDIM-26
1 / "
2
