P13.06 Sensor Length
Min: 0.01 cm Max: 400 cm
Length of the metallic markings worked into the belt in the direction of belt travel.
P13.07 Sensor Width
Min: 0.01 cm Max: 400 cm
Width of the metallic markings worked into the belt at right angles to the direction of belt
travel.
P13.08 Sensor Offset
Min: -400 cm Max: 400 cm
The zero point of recording the belt drift can be corrected with the offset. Unfortunately, this
restricts the maximum display zone. This is why greater differences should be calibrated by
mechanically shifting the sensor.
The new display = the old display - the offset
P13.09 Belt Drift
Min: 0.01 cm Max: 400 cm
Threshold value for belt misalignment identification to generate an event message Event:
Belt Drift.
P13.10 Event: Belt Drift
Event Group: WM Number: 04
The belt has exceeded the tolerance levels set.
Steps:
1. Remove any soiling to the tail and drive pulleys
2. Align the belt
Monitoring may also be subject to error. Therefore: keep an eye on the service value for the
belt motion sensor and correct any errors that may arise.
Related threshold value: Belt Drift
P13.11 Belt Skew
Min: 0.01 cm Max: 400 cm
Threshold of the belt drift for detection of event Event: Belt Skew.
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
Default: 8.2 cm
Default: 12 cm
Default: 0 cm
Default: 3 cm
Default: W1
Default: 4 cm
