P19.12 Baud rate
Alternative: 2400
4800
9600
19200
38400
Data transfer rate at Modbus-RTU.
P19.13 Data Format
Alternative: 8-O-1
8-E-1
8-N-1
Modbus-RTU always uses an 11-bit character frame.
Example: 8-O-1 means:
1 start bit, 8 data bit, odd parity, 1 stop bit
N = no parity, E = even parity)
P19.14 Physics
Alternative: RS485-2-wire
RS485-4-wire
RS232
Selects the electrical interface type. (Modbus RTU)
P19.15 Address
Min: 0 Max: 126
The address of the slave at the PROFIBUS.
P19.16 FLOAT-Format
Alternative: IEEE
SIEMENS-KG
Information on the formats for all setpoints, measuring values and floating point parame-
ters.
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
Default: 9600
Default: 8-O-1
Default: RS232
Default: 16
Default: IEEE
