Aspb Connections For 16 Analog And 16 Digital Audio Channels - Tektronix Profile PDR300 Installation Manual

J17 J16 J15 J14
Channels
In
Out
Analog
Channels
In
Out
Figure 2-18. ASPB Connections for 16 Analog and 16 Digital Audio Channels
ASPB
J13 J12 J11 J10 J9 J8 J7 J6
Analog Digital (AES/EBU)
1-8
Channels
Digital (AES/EBU)
9-16 1-8
Channels
PROFILE
Profile Video File Server Installation
Connecting Audio
J5 J4 J3 J2 J1
AES
9-16
Ref Monitor
PAC216
Audio
Chassis
AES
Ref Monitor
PACXLR
Audio
Breakout
Panel
9676-51
2-23
