Instruction CF-RD Room Thermostat with Display
2. Installation
Note:
• To activate batteries in the Room Thermostat
please remove enclosed strips from the batteries.
• The assignment of the Room Thermostats to the
Master Controller should be within 1½m distance
Activate Install mode on
Master Controller - g. 1.
• Use the menu selection button
Install mode. Install LED
• Activate Install mode by pressing OK
LED goes ON
Activate Install mode on
Room Thermostat
• Press the push button
during communication
Select output on Master Controller
• All available output LEDs on Master Controller
light up, and the rst of them ashes
• Press output selection button
output ( ashes) and accept with OK
• All output LEDs
stays ON shortly
VI.UH.Q1.52
go OFF. Selected output
Produced by Danfoss Floor Heating Hydronics 08.2008
to select the
ashes
.
LED and
, select desired
.
Install
icker
