Arista Networks, Inc. The information contained herein is subject to change without notice. Arista Networks and the Arista logo are trademarks of Arista Networks, Inc in the United States and other countries. Other product or service names may be trademarks or service marks of others.
This guide is focused on the installation and basic configuration of the Awake Network Detection and Response (NDR) products. Arista offers the Awake Network Security Platform through its subsidiary, Awake Security. The AI based software platform operates on a physical appliance or a set of physical and/or virtual appliances.
Aucune pièce réparable par l'utilisateur à l'intérieur. Confiez toute réparation à un technicien qualifié. Safety Information Refer to the Arista Networks Compliance and Safety Guides document, translated into a number of languages and available at the bottom of the page in the Hardware tab at https://www.arista.com/...
Rack Units Dimensions (W x H x D) Weight appliance SKU (RUs) DCA-NDR-S100MB 43.7 x 4.3 x 65.0 cm (17.2 x 1.7 x 25.6 20.87 kg (46 lbs.) DCA-NDR-S1 43.7 x 4.3 x 65.0 cm (17.2 x 1.7 x 25.6 20.87 kg (46 lbs.)
Chapter 2 Preparation Site Selection The following criteria should be considered when selecting a site to install the Awake Security appliance(s): • Temperature and Ventilation: For proper ventilation, install the Awake Security appliance where there is ample airflow to the front and back of the Awake Security appliance. The ambient temperature should not go below 0°...
Note: No additional equipment is required for installation into tool-less four post racks. Accessory kit does not include screws for attaching the Awake Security appliance to the equipment rack. When installing the appliance into an equipment rack with unthreaded post holes, nuts are also required to secure the device to the rack posts.
Chapter 3 Rack Mounting an Awake Security Appliance This chapter describes the rack mounting procedure that is identical for all Awake Security appliances covered by this guide. Illustrations in this chapter depict the mounting of Awake 1RU and 2RU appliances. Ce chapitre décrit la procédure de montage en rack qui est identique pour toutes les appliances Awake Security couvertes par ce guide.
Page 12
5. Position the alignment pins on the rear end of the rail to the holes on the rack (D) and push the rail into the rack until the quick release bracket snaps into place, securing the rail to the rack. 6.
Rack Mounting an Awake Security Appliance 8. Slide the appliance rails into the rack rails, keeping the pressure even on both sides. Figure 3: Installing the Appliance into a Rack Note: You may have to depress the bracket clips while inserting the appliance. When the server has been pushed completely into the rack, you should hear the bracket clip locks with an audible click.
Page 14
2. Install the inner rails to the side of the appliance. Figure 5: Install inner rails 3. Press the button to slide the rail in. Figure 6: Slide the Rail in Note: Ensure that the rails are attached in the same rack position number in all four corners.
Page 15
Rack Mounting an Awake Security Appliance 5. Secure the rack to the rail with screws. Figure 8: Screw in the rails 6. Repeat the previous step to mount four corners. Figure 9: Mount all four corners 7. Insert the appliance rails into the rack rails and slide the appliance all the way in. Figure 10: Positioning the appliance...
Page 16
8. Install screws into the handles to secure the appliance. Figure 11: Securing the Appliance...
• For a nucleus cluster with more than two nucleus appliances, attach a network cable from one of the interconnect ports from each nucleus and connect it to the supplied Arista switch. Refer to the Rear Panel...
Chapter 5 Configuring the Awake Security Platform Once the appliances are physically installed and cabled up, the next step is software configuration of the individual Awake Security appliances which once configured will combine to become the Awake Security Platform: Connecting to the Admin CLI Configuring the Appliance Verifying the Configuration Connecting to the Admin CLI...
1. Enter the set interface static <ip> <netmask> <default gateway> where specified variables denotes the following values: • <ip> - IP address of the management interface • <netmask> - Netmask of the network (for example, 255.255.255.0) • <default gateway> - Default gateway of the network CLI displays the following prompt: Applying network settings now might cause the network to disconnect.
Configuring the Awake Security Platform 4. If no further configuration changes are required, enter the reboot command to restart the device. 5.2.5 Configuring IPMI / DRAC Interface Awake appliances provide a dedicated network interface for the Intelligent Platform Management Interface (IPMI) and the Dell™ Remote Assistant Card (DRAC) interface. Perform the following steps to configure IPMI: 1.
Status Indicators The control panel LEDs are located on the right side of the appliance and display system, fan, and power supply status. They are labeled in either Figure 13: DCA-NDR-S100MB, DCA-NDR-S1 Figure 14: DCA-NDR-A5, DCA-NDR-NB10, DCA-NDR-S5, DCA-NDR-S10. Control Panel Indicators Front panel LEDs are located on the upper right corner of the device for 1RU Awake appliances.
Rear Panel Status Indicators The two LED indicators above either side of each management port and each packet capture port are link and activity indicators. DCA-NDR-S100MB, DCA-NDR-S5, DCA-NDR-S10, DCA-NDR-A5 Packet Capture Port LEDs 1 Link LEDs 2 Activity LEDs...
Page 25
Status Indicators Label Indication Meaning Link Green Linked at 10 Gb Yellow Linked at 1 Gb Activity Blinking Actively transmitting or receiving data No link DCA-NDR-NB10 Interconnect Port LEDs 1 Link LED 3 Link LED 2 Activity LED 4 Activity LED Label Indication Meaning...
Page 26
IPMI LAN Port LEDs 1 Link LED 2 Activity LED The green, amber, or off indicates the speed of The yellow LED indicates activity. the connection. Table 2: IPMI Link LEDs LED Color Definition Amber: Solid 1 Gb/s Green: Solid 100 Mb/s No connection or 10 Mb/s...
4 Screws 2 Rear rails 5 AC Power cables 3 Front rails Cables A pair of AC power cables (part number: NEMA 5-15p) is included in the accessory kit. Note: All provided power cables are for use with Arista products only.
This appendix displays the front panel of all Awake Security appliances covered by this guide. Note: All devices are designed to fit into a 19” rack. The appearance may be different than those shown based on PSU and fan modules used. Figure 17: DCA-NDR-S100MB, DCA-NDR-S1 1 Unused port 4 Right rack ear brackets...
This appendix displays the rear panel of all Awake Security appliances covered by this guide. Note: All devices are designed to fit into a 19” rack. The appearance may be different than those shown based on the PSU types and the modules used. DCA-NDR-S100MB, DCA-NDR-S1 1 IPMI LAN port 7 Unused port...
Page 32
1 Unused slot 7 COM port 2 Packet capture ports 8 IPMI LAN ports 3 SSD drives 9 USB ports 4 Unused slots 10 Management port 5 VGA 11 Power supplies 6 UID LED DCA-NDR-S10 1 Unused slot 7 COM port 2 Interconnect ports 8 IPMI LAN ports 3 SSD drives...
Page 33
Rear Panel 1 Unused slot 7 COM port 2 Interconnect ports 8 IPMI LAN ports 3 SSD drives 9 USB ports 4 Unused slots 10 Management port 5 VGA 11 Power supplies 6 UID LED...
Page 35
This appendix lists the regulatory model numbers (RMNs) for the product models of the Awake Security appliances described in this document. Table 3: Regulatory Model Numbers and Product Numbers Regulatory Model Numbers (RMNs) Product Numbers 815-R5H12 DCA-NDR-S100MB 815-R5H12 DCA-NDR-S1 829UAS-16 DCA-NDR-S5 829U-R16H12...
