Summary of Contents for Jetson Relay
- Page 1 Relay Folding Kids' Electric Scooter. A guide for your ride. IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE. MODELS: JRELAY-BLK | JRELAY-CMO | JRELAY2-BLK...
- Page 3 Jetson's top two riding rules: Be safe. Have fun!
-
Page 5: Table Of Contents
......................9 Assembling the Handlebar ....................10 Unfolding/Folding the Relay ....................1 2 Adjusting the Handlebar ......... -
Page 6: Safety Warnings
Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Before each cycle of operation, the operator shall perform the preoperation checks specified by the manufacturer: That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;... - Page 7 • Prolonged exposure to UV rays, rain and the elements may damage the enclosure materials, store indoors when not in use. MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from the Jetson Care Team. This will void any warranty, and can lead to malfunctions which may cause injury.
-
Page 8: Product Overview
Product Overview 1. HANDLEBAR 2. POWER BUTTON 3. CHARGING PORT 4. STEM CLAMP 5. FRONT TIRE 6. FOLDING MECHANISM 7. DECK 8. REAR FOOT BRAKE 9. REAR TIRE 10. REFECTOR 11. KICKSTAND 12. E-BRAKE 13. LCD SCREEN 14. THUMB THROTTLE 15. - Page 9 PLEASE NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
-
Page 10: Specs & Features
Specs & Features • MOTOR TYPE: 150W HUB • MAX SPEED: 10 MPH • MAX RANGE: 5 MILES • BATTERY: 21.6V, 2.5AH LITHIUM-ION • RECOMMENDED AGE: 8+ • CLIMBING ANGLE: UP TO 10° • PRODUCT FOLDED: 29.5”L × 15.1”W × 10.6”H •... -
Page 11: Online Resources
Online Resources Scan for our most updated Relay onboarding materials and support resources. -
Page 12: Assembling The Handlebar
1. Getting Started Assembling the Handlebar • EXTEND STEM HEIGHT ADJUSTMENT TO THE TALLEST LENGTH. (REFER TO SECTION 1.3 OF THIS MANUAL.) • MAKE SURE WIRES ARE ALIGNED AND PULLED STRAIGHT UP. • LOWER THE HANDLEBAR ONTO THE STEM WHILE CAREFULLY TUCKING EXCESS WIRES INTO STEM. IMPORTANT: DO NOT PULL TOO HARD. - Page 13 BOLT CLAMP • POSITION THE HANDLEBAR ON THE TOP OF THE STEM SO THAT THE PRE-DRILLED HOLE IN THE HANDLEBAR ALIGNS WITH THE HOLE IN THE STEM. • PLACE CLAMP OVER HANDLEBAR SO THAT THE HOLE IN THE CLAMP ALIGNS WITH THE HOLE IN THE HANDLEBAR.
-
Page 14: Unfolding/Folding The Relay
Unfolding/Folding the Relay TO UNFOLD OR FOLD, FIRST PRESS DOWN ON THE FOLDING MECHANISM. - Page 15 DOWN TO FOLD. UP TO UNFOLD. • MAKE SURE TO RAISE OR LOWER THE STEM UNTIL YOU HEAR THE CLICK—OTHERWISE THE STEM MAY NOT BE SECURE.
-
Page 16: Adjusting The Handlebar
KNOB STEM CLAMP LEVER Adjusting the Handlebar • OPEN THE STEM CLAMP LEVER. • TWIST THE KNOB TO WIDEN THE CLAMP OPENING. - Page 17 PRESS IN • WHILE PRESSING IN THE PIN, RAISE OR LOWER THE HANDLEBAR UNTIL THE PIN CLICKS INTO ANOTHER PRE-DRILLED PIN HOLE IN THE STEM. • WHEN THE PIN IS IN POSITION, CLOSE THE STEM CLAMP LEVER AND TIGHTEN THE KNOB UNTIL THE STEM IS SECURE.
-
Page 18: Charging The Battery
CHARGER INTO THE CHARGING PORT. • WHEN DISCONNECTING THE CHARGER, ALWAYS UNPLUG THE CHARGER FROM THE WALL FIRST. • NEVER TURN ON THE RELAY WHILE IT IS CHARGING. • CHARGE THE BATTERY UNTIL IT IS FULLY CHARGED - UP TO 5 HOURS. -
Page 19: Riding The Relay
2. Making Moves Riding the Relay • PLACE ONE FOOT AT THE FRONT OF THE SCOOTER DECK FACING FORWARD. PLACE THE OTHER FOOT BEHIND IT, TURNED OUTWARDS AT A 70-90° ANGLE. • USE YOUR BACK FOOT TO PUSH OFF THE GROUND AND PROPEL THE SCOOTER FORWARD 5 TO 8 TIMES BEFORE STARTING UP THE MOTOR WITH THE THUMB THROTTLE. -
Page 20: Using The Functions On The Handlebar
Using the Functions on the Handlebar E-BRAKE E-BRAKE: • USE THE E-BRAKE LIKE THE REAR FOOT BRAKE: TO SLOW DOWN OR STOP. • PRESS DOWN ON THE E-BRAKE SLOWLY TO AVOID STOPPING ABRUPTLY OR LOSING CONTROL. THUMB THROTTLE: LCD SCREEN •... -
Page 21: Using The Rear Foot Brake & Kickstand
Using the Rear Foot Brake & Kickstand USING THE KICKSTAND: • TO LOWER THE KICKSTAND, PIVOT IT DOWN FROM THE SIDE OF THE SCOOTER DECK. TILT THE SCOOTER TO REST ON THE KICKSTAND. • TO RAISE IT, PIVOT IT UP TOWARDS THE REAR WHEEL OF THE SCOOTER DECK. -
Page 22: Helmet Safety
Helmet Safety PROPER POSITIONING: IMPROPER POSITIONING: THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. A FALL COULD RESULT IN SERIOUS INJURY. * WEAR A HELMET, APPROPRIATE CLOTHING, SHOES, AND SAFETY GEAR. AVOID CLOTHING THAT CAN GET CAUGHT INTO OR UNDER THE WHEELS. -
Page 23: Care & Maintenance
• TO CLEAN THE RELAY, CAREFULLY WIPE WITH A DAMP CLOTH AND THEN DRY WITH A DRY CLOTH. • DO NOT APPLY WATER DIRECTLY TO THE RELAY. THIS CAN CAUSE DAMAGE TO THE ELECTRICAL SYSTEMS, AS WELL AS DETERIORATION OF THE FRAME, WHICH CAN RESULT IN MALFUNCTION THAT LEADS TO PERSONAL INJURY. -
Page 24: Warranty Coverage
All new Jetson products, excluding parts and accessories, are warranted against defects in materials and workmanship for a period of one year from the date of original retail purchase when used in accordance with Jetson's user manuals (refer to ridejetson.com/support). - Page 26 Stay connected. Be sure to follow @ridejetson on social media to learn about fantastic offers, giveaways, and all the latest Jetson news. Loving your ride? Then be sure to leave a review at ridejetson.com/reviews. We can’t wait to hear from you!
- Page 28 Date Code: 08/2023 Document Edition: v1.2 © 2023, JETSON. ALL RIGHTS RESERVED. Manufactured by JETSON ELECTRIC BIKES LLC. No portion of this document, including shape, copy, graphics, and design, may be reproduced or transmitted in any form or by any means.
