Crest Audio Ci 20 X 4 Specification Sheet

(Ci 20x8 model shown)
Power Ratings
Ci 20x8
Ci 20x4
1kHz, 0.02% THD+N Power figures are watts per channel, all channels driven.

FeATUres OVerVieW:

• Four- and eight-channel versions available, each rated @
200 watts per channel @ 8 ohms or 70 volts (100-volts
isolated outputs with optional accessories).
• Individual channels may be selected as low impedance or
70 volt
• Tour Class® protection
• Front and rear panel indicators for amplifier status
• Variable-speed fan
• Sequential turn-on standard
• Euro-style input connectors
• Barrier strip output connectors
• One controlled-voltage input per channel standard
• One fault relay per channel standard
• Module bay provided to input Nx module bay accessories
for full amplifier control and monitoring via NexSys® 4
software or MediaMatrix® product and digital audio
distribution
• 100- and 50-volt operation supported with external
accessories
• EN60849 and ANSI60849 compliant with optional
accessories
Dual
8Ω 4Ω
220 w 150 w
220 w 150 w
Multi-Channel
Power Processing
Amplifiers
70 volt
200 w
220 w
DesCriPTiOn:
The Ci Series is the next generation family of elevated efficiency
amplification from Crest Audio. Ci amplifiers are designed to
drive low-impedance or 70-volt speaker loads without bridging
between channels. Bridged operations are supported for
additional power into 8-ohm loads or 140-volt operation.
As with all Crest Audio products, sonic performance is of
primary importance. In addition, high-efficiency, comprehensive
load protection and compact packaging have been achieved in
the Ci design.
The Ci Series amplifiers incorporate Crest Audio's tried-and-
true modular approach to intelligent amplifier configuration.
Through the provision of a single module bay, these amplifiers
may accommodate modules that facilitate load monitoring,
digital audio delivery and Crest Audio's NexSys networking.
A full complement of features and options makes this series
very versatile, whether powering airport systems, restaurant
audio or a myriad of other applications. The Ci Series amplifiers
bring a new generation of amplification to Crest Audio.
Ci
s e r i e s
Bridged
8Ω 140 volt
300 w 400 w
300 w 440 w
™
