- Page 1 CPX Series Power Amplifiers 1 | CPX 2 | CPX Operating Manual CPX 1 POWER AMPLIFIER TEMP CPX 2 POWER AMPLIFIER TEMP CPX 3 POWER AMPLIFIER TEMP www.crestaudio.com...
- Page 2 (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Warning: Changes or modifications to the equipment not approved by Crest Audio can void the user’s authority to use the equipment.
- Page 3 Inspect the amplifier during unpacking. If any damage is found, notify your dealer immediately. Be sure to save the carton and all packing materials. Should you ever need to ship the unit back to Crest Audio®, one of its service centers, or the dealer; use only the original factory packing.
- Page 4 If the fuses open instantly each time you attempt to turn the unit on, it should be taken to a qualified Crest Audio Service Center for...
- Page 5 CHANNEL CHANNEL CHANNEL BRIDGE A PRODUCT OF 40 Hz LINE OUTS INPUTS MOUNT IN RACK ONLY - INSTALLER SUR CREST AUDIO INC. THRU SUPPORT DE MONTAGE SEULEMENT 5022 HWY 493 MERIDIAN, MS 39305 USA BRIDGE WWW.CRESTAUDIO.COM 150 Hz X-OVER STEREO...
- Page 6 Rear Panel pins 1+ and 2+ in parallel, and pins 1- and 2- in parallel. For the CHANNEL A and CHANNEL B twist locks, the respective channel output appears on pins 1+ and 2+. Pins 1- and 2- are chassis ground. For the BRIDGE twist lock, CHANNEL A appears on pins 1+ and 2+, and CHANNEL B appears on pins 1- and 2-.
- Page 7 When using Bridge mode, the connected enclosure impedance must be 4 or 8 Ohms — never below 4 Ohms. Crest Audio's patented GCL (Gain Comparator Limiting) circuit enables the sound technician to maximize the performance of the amplifier/speaker combination by preventing the power amplifier from running out of headroom (clipping). This limiting system is activated by a unique circuit that senses signal conditions that might overload the amplifier and activates compression (reduces the channel gain) when clipping is imminent.
- Page 8 Specifications CPX 1 CPX 2 CPX 3 Rated Power @ 120 VAC or 240 VAC Stereo* Mode 2 Ω, 1 kHz, 1% THD (RMS per channel) 300 W 450 W 625 W 4 Ω, 1 kHz, 1% THD (RMS per channel)
- Page 9 Specifications CPX 1 CPX 2 CPX 3 Cooling System Temperature dependent, 1 x Two-Speed DC Fan air flow - back to front Protection Full short circuit, open circuit, Over-temp thermal, RF, Stable into any load Load Turn on/off muting, DC (triac crowbar), Low-cut filter...
- Page 10 CHANNEL CHANNEL CHANNEL BRIDGE A PRODUCT OF 40 Hz LINE OUTS INPUTS MOUNT IN RACK ONLY - INSTALLER SUR CREST AUDIO INC. THRU SUPPORT DE MONTAGE SEULEMENT 5022 HWY 493 MERIDIAN, MS 39305 USA BRIDGE WWW.CRESTAUDIO.COM 150 Hz X-OVER STEREO...
- Page 11 CHANNEL BRIDGE CHANNEL CHANNEL A PRODUCT OF 40 Hz LINE OUTS INPUTS MOUNT IN RACK ONLY - INSTALLER SUR CREST AUDIO INC. THRU SUPPORT DE MONTAGE SEULEMENT 5022 HWY 493 MERIDIAN, MS 39305 USA BRIDGE WWW.CRESTAUDIO.COM 150 Hz X-OVER STEREO...
- Page 12 Wire Gauge stranded cable length wire gauge power loss 8 Ohms load 4 Ohms load 2 Ohms load 2.9% 5.6% 10.8% meters 1.74 0.75 1.16 0.58 1.16 0.35 0.70 1.39 0.22 0.44 0.87 meters 4.3% 8.2% 15.5% 0.75 10.8 1.45 0.87 1.74 0.55...
- Page 13 Wire Gauge stranded cable length wire gauge power loss 8 Ohms load 4 Ohms load 2 Ohms load feet 0.81% 1.61% 3.2% 0.51 1.02 0.32 0.64 1.28 0.20 0.40 0.80 0.128 0.25 0.51 feet 1.61% 3.2% 6.2% 1.02 0.64 1.28 0.40 0.80 1.60...
- Page 14 Features and specifications subject to change without notice. Crest Audio 5022 HWY 493 N. Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005 The bar is the symbol for marking of new waste and...
