ELI-S-400 CEC
SINEWAVE INVERTER
Installation and Operation Instructions
ELI SERIES EMERGENCY LIGHTING INVERTERS
! IMPORTANT SAFEGUARDS !
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
Do not use outdoors.
2. Do not let power supply cords touch hot surfaces.
3. This product is suitable for use in damp locations where the ambient temperature is 20ºC minimum,
30ºC maximum. Product is not suitable for heated air outlets and wet or hazardous locations. DO
NOT INSTALL NEAR GAS OR ELECTRIC HEATERS.
4. Equipment should be mounted securely in locations and at heights where it will not be readily
subjected to tampering by unauthorized personnel.
5. The use of accessory equipment and replacement parts not recommended by the manufacturer may
cause an unsafe condition.
6. Do not use this equipment for other than its intended purpose.
7.
The AC voltage rating of this equipment is 120 or 277 VAC. Do not connect equipment to any other
voltage.
8. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference that may cause undesired operation.
Consumer Information:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
! IMPORTANT ! - PLEASE TAKE NOTE BEFORE THE INSTALLATION:
You must determine how the connected emergency lighting fixtures are to operate; normally-on (unswitched
and always energized), normally-off (only energized during a power failure), or switched on/off. Wire
according to the appropriate wiring diagram given below. Consult factory for special wiring diagrams.
Ensure that ALL combined/connected Emergency lighting loads are UNDER this product's maximum output
rating of 400VA
ELI-S-400 CEC WILL deliver upto 400VA into the connected lighting loads.
THIS PRODUCT INCLUDES RECHARGEABLE LEAD-ACID BATTERIES.
THE BATTERIES MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Pb
Collierville, TN USA • Tech Support 888-263-4638 • Fax 901-853-5009 • www.bodine.com
SAVE THESE INSTRUCTIONS
2/3/2023
Bodine © 2023 Signify Holding. All rights reserved.
442296136811
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED,
INCLUDING THE FOLLOWING:
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bodine ELI-S-400 CEC
Summary of Contents for Bodine ELI-S-400 CEC
- Page 1 Ensure that ALL combined/connected Emergency lighting loads are UNDER this product's maximum output rating of 400VA ELI-S-400 CEC WILL deliver upto 400VA into the connected lighting loads. THIS PRODUCT INCLUDES RECHARGEABLE LEAD-ACID BATTERIES. THE BATTERIES MUST BE RECYCLED OR DISPOSED OF PROPERLY.
- Page 2 Voltage Emergency Run Time Voltage Power AC Load* (Autoselect) ELI-S-400 CEC 120/277Vac 120/277Vac 400 VA 400 VA Minimum of 90 minutes * NOTE: AC Input Power to an LED or Fluorescent Driver/Ballast is always more than the output power. These inef- ficiencies must be accounted for in the design as they will likely reduce the maximum connected load to something less than 400W.
- Page 3 STEP #2 BATTERY INSTALLATION AND CABLE CONNECTION This product is provided with four sealed Lead acid batteries. Only the batteries supplied by the inverter manufacturer should be used. Install the batteries as shown, referring to Illustrations 2A and 2B. With the unit secured to the mounting surface, begin installation by sliding the batteries into the enclosure. Connect the battery cables using the supplied hardware.
- Page 4 When AC power is restored, the unit returns to normal charging mode. The ELI-S-400 CEC operates the emergency lighting load for a minimum of 90 minutes. NOTE: Driver efficiency and power factor must be taken into account. This may reduce the maximum AC load connected.
- Page 5 MAINTENANCE & TROUBLESHOOTING WARNING: Always turn off SW-1(first), then turn off AC power to the equipment inside the case before servicing. ! REFER ANY SERVICING TO QUALIFIED PERSONNEL ! Servicing should be performed only by qualified service technicians. Use only manufacturer supplied replacement parts.
- Page 6 Replacement Batteries Model Installation Kit Battery Harnesses Fuse Part No. Quantity ELI-S-400 CEC 1x PRT00143 2x PRT00144 1x Littlefuse 0312030 PRT00400 1 Required Battery Maintenance: The batteries supplied with this equipment require no maintenance. However, the inverter should be tested periodically, and batteries replaced whenever they will no longer operate the connected fixtures for the rated run-time.
