- Page 1 ® Respirox E-20A System User Manual 0123...
-
Page 2: Table Of Contents
E-20A System User Manual V2.11 Table of Contents 1. Symbols ···································································································· 1 1.1 Control Buttons ·················································································· 1 1.2 Device Symbols ·················································································· 1 2. Warning, Caution and Important Tip ································································· 2 3. Intended Use ······························································································ 2 4. Contraindications ························································································· 3 5. Specifications ······························································································ 4 6. - Page 3 E-20A System User Manual V2.11 17. Transferring the Device to Another Patient ························································ 27 18. Reordering ······························································································· 27 19. Technical Support ······················································································ 27 20. Disposal ·································································································· 27 21. Troubleshooting ························································································ 28 21.1 Common Problems in Patients and Corresponding Solutions ························· 28 21.2 Common Problems in the Device and Corresponding Solutions ·····················...
-
Page 4: Symbols
E-20A System User Manual V2.11 1. Symbols 1.1 Control Buttons Ramp Button Mute Button Knob 1.2 Device Symbols Follow Instructions for Use Operating Instructions Type BF Applied Part (mask) Class II (Double Insulated) AC Power DC Power IP22 ≥ 12.5 mm Diameter, Dripping (15° tilted) -
Page 5: Warning, Caution And Important Tip
Warnings, Cautions, and Important Tips appear throughout this manual as they apply. 3. Intended Use The E-20A system is a CPAP (Continuous Positive Airway Pressure) device designed for the treatment of adult Obstructive Sleep Apnea (OSA) only, either in the hospital or at home. -
Page 6: Contraindications
E-20A System User Manual V2.11 4. Contraindications Studies have shown that the following pre-existing conditions may contraindicate the use of positive airway pressure therapy for some patients: Absolute Contraindications: Pneumothorax, mediastinal emphysema; cerebrospinal fluid leak, traumatic brain injury, or pneumocephalus; shock caused by a variety of conditions before treatment;... -
Page 7: Specifications
E-20A System User Manual V2.11 5. Specifications Device Size Dimensions: 170 mm × 180 mm × 118 mm, or 290 mm × 180 mm × 134 mm (with the humidifier) Weight: 1.5 kg, or 2.5 kg (with the humidifier) Product Use, Transport and Storage... -
Page 8: Available Therapies
E-20A System User Manual V2.11 Sound Pressure Level < 30 dB, when the device is working at the pressure of 10 hPa. Sound Power Level < 38 dB, when the device is working at the pressure of 10 hPa. Maximum Flow... -
Page 9: Glossary
E-20A System User Manual V2.11 7. Glossary Apnea A condition marked by the cessation of spontaneous breathing. Auto-CPAP Adjust CPAP pressure automatically to improve patient comfort based on monitoring of apnea and snoring events. Auto Off When this feature is enabled, the device automatically discontinues therapy whenever the mask is removed. -
Page 10: Model
E-20A System User Manual V2.11 Means the time unit “minute”. Means the time unit “hour”. yy mm dd / mm dd yy / dd mm yy Means the date. 8. Model Product Description Maximum Model Product Optional Optional Work Work... -
Page 11: Package Contents
E-20A System User Manual V2.11 9. Package Contents After unpacking the system, make sure you have everything shown here (Different models of the product contain different components): Articles Qty. Notes Main Device Heated Humidifier Optional Shield Air Filter Power Adapter... -
Page 12: System Features
E-20A System User Manual V2.11 10. System Features Humidifier Indicator Display Screen Mute Button Power Indicator Knob Air Outlet Ramp Button Humidifier Connector Shield Fig. 10-1 Name Function Indicate the humidity level. There are five levels in total. The number of Humidifier indicator lights that light up is directly proportional to the humidity level. -
Page 13: First Time Setup
E-20A System User Manual V2.11 SD Card Slot Communications Port DC Inlet Filter Cap Fig. 10-2 Name Function SD Card Slot Insert the SD card into this slot Communications Connected to external equipment (Not for connection to Port unrecommended devices) -
Page 14: Installing The Air Filter And Filter Cap
E-20A System User Manual V2.11 • Air must flow freely around the device for it to work properly. 11.2 Installing the Air Filter and Filter Cap (1) Attach the air filter to the filter cap, as shown in Fig. 11-1. -
Page 15: Assembling The Tube And Mask
E-20A System User Manual V2.11 CAUTION! • Inspect the power cord often for any signs of damage. Replace a damaged cord immediately. IMPORTANTS! • After interruption and restoration of the power supply, the device will restore its pre-interruption working status automatically. -
Page 16: Using Oxygen With The Device
E-20A System User Manual V2.11 - Do not wear the mask for more than a few minutes while the device is not operating. - Use only masks with vent holes. Do not block or try to seal the vent holes in the exhalation port. -
Page 17: Using The Spo2 Kit
E-20A System User Manual V2.11 Fig. 11-7 If the SD card is inserted incorrectly or not inserted, a symbol indicating incorrect insertion or no SD card present will appear in the Main Interface on the screen of the device, as shown in Fig. -
Page 18: Kit From The Main Device
E-20A System User Manual V2.11 (2) Point the four holes of the Base Plate towards the four reference points on the back of the main device to properly stick the plate to the device, as shown in Fig. 11-11. Base Plate Fig. - Page 19 E-20A System User Manual V2.11 applies to E-20A-H-O), or the Main Interface shown in Fig. 11-15 (only applies to E-20AJ-H-O). The patient's blood oxygen saturation and pulse rate can be clearly seen during the course of therapy. Fig. 11-14 Fig. 11-15 WARNINGS! •...
-
Page 20: Using The H60 Heated Humidifier
E-20A System User Manual V2.11 11.8 Using the H60 Heated Humidifier The H60 Heated Humidifier is available from your home care provider. The humidifier may reduce nasal dryness and irritation by adding moisture (and heat if applicable) to the airflow. -
Page 21: Using The Ramp Button
E-20A System User Manual V2.11 CAUTION! • Observe the water level of the water chamber before using the humidifier. Make sure there is sufficient water in the water chamber, and avoid heating the humidifier with an empty water chamber. 12.5 Using the Ramp Button... -
Page 22: Navigating The Patient Menu
13.1.1 Accessing the Main Interface Connect the power cord and power adapter properly. The screen displays the Main Interface shown in Fig. 13-1 (only applies to E-20A-H-O), or the Main Interface shown in Fig. 13-2 (only applies to E-20AJ-H-O). Fig. 13-1 Fig. -
Page 23: Selecting Options
E-20A System User Manual V2.11 Fig. 13-4 13.1.4 Selecting Options As you turn the Knob clockwise, the cursor moves downwards from one option to another. As you turn it counterclockwise, the cursor moves upwards. When the cursor is on a certain... -
Page 24: Turning Pages
E-20A System User Manual V2.11 13.1.7 Turning Pages When the cursor is on Mask Type, the last option shown in Fig. 13-7, the remaining options will appear on a new page if you continue to turn the Knob clockwise, as shown in Fig. -
Page 25: Options Of The Patient Menu And Corresponding Descriptions
E-20A System User Manual V2.11 13.2 Options of the Patient Menu and Corresponding Descriptions Option Range Description There are five humidity levels available. As the numbering Humidifier Off, 1 ～ 5 increases, the humidity rises accordingly. “Off” means the humidifier is turned off. The default setting is “2”... -
Page 26: Alert
E-20A System User Manual V2.11 14. Alert Alert Message Description An audible alert will sound if the device is accidentally disconnected from power when it is delivering air. Note: Power Failure!!! (1) The alert will not sound if power failure occurs when the device is in standby state. -
Page 27: Cleaning And Disinfection
E-20A System User Manual V2.11 15. Cleaning and Disinfection WARNINGS! • Regular cleaning of the device and its accessories is very important for the prevention of respiratory infections. • To avoid electric shock, always unplug the device before cleaning. • Use washing liquid that is nontoxic to humans and does not cause allergies in humans. -
Page 28: Replacing The Air Filter
E-20A System User Manual V2.11 thoroughly. (3) After cleaning, air-dry the tube in a cool, well-ventilated area, and avoid direct sunlight. It takes approximately 30 minutes to completely air-dry the tube. Check whether the tube is completely dry before re-use. -
Page 29: Traveling With The Device
E-20A System User Manual V2.11 16. Traveling with the Device CAUTIONS! • Empty the water chamber of the humidifier before packing the device for your trip; in order to prevent any remaining water from entering the device. • Using the device at an incorrect elevation setting could result in airflow pressures higher than the prescribed setting. -
Page 30: Transferring The Device To Another Patient
E-20A System User Manual V2.11 17. Transferring the Device to Another Patient If the device is transferred to another patient, components in close contact with the previous owner, including the mask, headgear, tube, and air filter, should be cleaned and disinfected to prevent cross-infection. -
Page 31: Troubleshooting
E-20A System User Manual V2.11 21. Troubleshooting The table below lists common problems you may have with the device and possible solutions to those problems. If none of the corrective actions solve the problem, contact your home care provider. 21.1 Common Problems in Patients and Corresponding... - Page 32 E-20A System User Manual V2.11 Turn the humidity setting down, or raise the room temperature. When the humidifier is used, Place the tube under the quilt, or the humidified air tends to use the tube cover. Water in mask condense in the cold tube and...
-
Page 33: Common Problems In The Device And Corresponding Solutions
E-20A System User Manual V2.11 21.2 Common Problems in the Device and Corresponding Solutions Problem Possible Cause Solution (s) Take a few deep breaths with the The Auto On / Off feature is mask on, and the device will start... -
Page 34: Emc Requirements
E-20A System User Manual V2.11 22. EMC Requirements Guidance and manufacturer's declaration - electromagnetic emissions The device is intended for use in the electromagnetic environment specified below. The user of the device should ensure that it is used in such an environment. - Page 35 E-20A System User Manual V2.11 Guidance and manufacturer's declaration - electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of the device should make sure that it is used in such an environment.
- Page 36 E-20A System User Manual V2.11 Guidance and manufacturer's declaration - electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of the device should make sure that it is used in such an environment.
- Page 37 E-20A System User Manual V2.11 Recommended separation distances between portable and mobile RF communications equipment and the device The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the device can help prevent...
- Page 38 E-20A System User Manual V2.11 Recommended separation distances between wireless communications equipment The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the device can help prevent...
-
Page 39: Limited Warranty
E-20A System User Manual V2.11 23. Limited Warranty ECE TIBBİ CİHAZLAR VE MEDİKAL SAN.TİC. A.Ş warrants that the device shall be free from defects of workmanship and materials and will perform in accordance with the product specifications for a period of one (1) year for main unit and three (3) months for all accessories from the date of sale by ECE TIBBİ...
