- Page 1 ® Respirox E-20C System User Manual 0123...
-
Page 2: Table Of Contents
E-20C System User Manual V2.11 Table of Contents 1. Symbols ........................1 1.1 Control Buttons ················································································ 1 1.2 Device Symbols ················································································ 1 2. Warning, Caution and Important Tip ................2 3. Intended Use ......................2 4. Contraindications ..................... 3 5. Specifications ......................4 6. - Page 3 E-20C System User Manual V2.11 17. Transferring the Device to Another Patient ............. 27 18. Reordering ......................27 19. Technical Support ....................27 20. Disposal ......................27 21. Troubleshooting ....................28 21.1 Common Problems in Patients and Corresponding Solutions ······················· 28 21.2 Common Problems in the Device and Corresponding Solutions ···················...
-
Page 4: Symbols
E-20C System User Manual V2.11 1. Symbols 1.1 Control Buttons Ramp Button Mute Button Knob 1.2 Device Symbols Follow Instructions for Use Operating Instructions Type BF Applied Part (mask) Class II (Double Insulated) AC Power DC Power ≥12.5 mm Diameter, Dripping (15°tilted) -
Page 5: Warning, Caution And Important Tip
Warnings, Cautions, and Important Tips appear throughout this manual as they apply. 3. Intended Use The E-20C system is a CPAP (Continuous Positive Airway Pressure) device designed for the treatment of adult Obstructive Sleep Apnea (OSA) only, either in the hospital or at home. -
Page 6: Contraindications
E-20C System User Manual V2.11 4. Contraindications Studies have shown that the following pre-existing conditions may contraindicate the use of positive airway pressure therapy for some patients: Absolute Contraindications: Pneumothorax, mediastinal emphysema; cerebrospinal fluid leak, traumatic brain injury, or pneumocephalus; shock caused by a variety of conditions before treatment;... -
Page 7: Specifications
E-20C System User Manual V2.11 5. Specifications Device Size Dimensions: 170 mm × 180 mm × 118 mm, or 290 mm × 180 mm × 134 mm (with the humidifier) Weight: 1.5 kg, or 2.5 kg (with the humidifier) Product Use, Transport and Storage... -
Page 8: Available Therapy
E-20C System User Manual V2.11 Sound Pressure Level ＜30 dB, when the device is working at the pressure of 10 hPa. Sound Power Level ＜38 dB, when the device is working at the pressure of 10 hPa. Maximum Flow Test Pressures (hPa) -
Page 9: Glossary
This feature is only available for E-20C-H-O. Auto On With this feature, the device automatically initiates therapy when you breathe into the mask. This feature is always enabled. This feature is only available for E-20C-H-O. CPAP Continuous Positive Airway Pressure. -
Page 10: Model
E-20C System User Manual V2.11 Means the time unit “hour”. yy mm dd / mm dd yy / dd mm yy Means the date. 8. Model Product Description Maximum Model Product Optional Optional Work Work Contents Accessory 1 Accessory 2... -
Page 11: Package Contents
E-20C System User Manual V2.11 9. Package Contents After unpacking the system, make sure you have everything shown here (Different models of the product contain different components): Articles Qty. Notes Main Device Heated Humidifier Optional Shield Air Filter Power Adapter... -
Page 12: System Features
E-20C System User Manual V2.11 10. System Features Humidifier Indicator Display Screen Mute Button Power Indicator Knob Air Outlet Ramp Button Humidifier Connector Shield Fig. 10-1 Name Function Indicate the humidity level. There are five levels in total. The number... -
Page 13: First Time Setup
E-20C System User Manual V2.11 SD Card Slot Communications Port DC Inlet Filter Cap Fig. 10-2 Name Function SD Card Slot Insert the SD card into this slot Communications Connected external equipment (Not connection Port unrecommended devices) DC Inlet An inlet for the DC power supply... -
Page 14: Installing The Air Filter And Filter Cap
E-20C System User Manual V2.11 device. • Air must flow freely around the device for it to work properly. 11.2 Installing the Air Filter and Filter Cap (1) Attach the air filter to the filter cap, as shown in Fig. 11-1. -
Page 15: Assembling The Tube And Mask
E-20C System User Manual V2.11 Consumption”) may damage the device or cause device failure. CAUTION! • Inspect the power cord often for any signs of damage. Replace a damaged cord immediately. IMPORTANTS! • After interruption and restoration of the power supply, the device will restore its pre-interruption working status automatically. -
Page 16: Using Oxygen With The Device
E-20C System User Manual V2.11 instructions: - Use the accompanying tube and mask provided by Ece. - Do not wear the mask for more than a few minutes while the device is not operating. - Use only masks with vent holes. Do not block or try to seal the vent holes in the exhalation port. -
Page 17: Using The Spo 2 Kit
E-20C System User Manual V2.11 Fig. 11-7 If the SD card is inserted incorrectly or not inserted, a symbol indicating incorrect insertion or no SD card present will appear in the Main Interface on the screen of the device, as shown in Fig. -
Page 18: Removing The Spo 2 Kit From The Main Device
E-20C System User Manual V2.11 Base Plate Adhesive-backed Paper Fig. 11-10 (2) Point the four holes of the Base Plate towards the four reference points on the back of the main device to properly stick the plate to the device, as shown in Fig. 11-11. - Page 19 E-20C System User Manual V2.11 Communications Port. The model of the SpO Kit is KS-CM01. The SpO Kit is calibrated to display FUNCTIONAL OXYGEN SATURATION. Attach its sensor to the patient's index finger or any other finger. The sampling rate of the SpO signal is about 50 Hz, and the update rate of the frame is 1 Hz.
-
Page 20: Using The H60 Heated Humidifier
E-20C System User Manual V2.11 11.8 Using the H60 Heated Humidifier The H60 Heated Humidifier is available from your home care provider. The humidifier may reduce nasal dryness and irritation by adding moisture (and heat if applicable) to the airflow. -
Page 21: Using The Ramp Button
E-20C System User Manual V2.11 CAUTION! • Observe the water level of the water chamber before using the humidifier. Make sure there is sufficient water in the water chamber, and avoid heating the humidifier with an empty water chamber. 12.5 Using the Ramp Button... -
Page 22: Accessing The Setup Interface
E-20C System User Manual V2.11 Fig. 13-2 The first icon on the left side of the screen indicates the Main Interface, the second icon indicates the Initial Setup Interface, and the third icon indicates the iCode Interface. As you turn the Knob , the cursor switches among the three icons, and the interface displayed on the screen changes accordingly. -
Page 23: Confirming Adjustments
E-20C System User Manual V2.11 indicating a lower humidity level. At this moment, the Humidifier option is still displayed in yellow, as shown in Fig. 13-5. Fig. 13-5 13.1.6 Confirming Adjustments Confirm your adjustment to an option by pressing the Knob . - Page 24 E-20C System User Manual V2.11 Fig. 13-8 Press the Knob , the cursor jumps to the second icon on the left side of the screen. The screen displays the Initial Setup Interface, as shown in Fig. 13-9. Fig. 13-9 (2) Returning to the Main Interface Move the cursor to the Home option by turning the Knob , as shown in Fig.
-
Page 25: Options Of The Patient Menu And Corresponding Descriptions
E-20C System User Manual V2.11 13.2 Options of the Patient Menu and Corresponding Descriptions Option Range Description There are five humidity levels available. As the numbering Off, 1 ～ 5 Humidifier increases, the humidity rises accordingly. “Off” means the humidifier is turned off. The default setting is “2”... -
Page 26: Alert
E-20C System User Manual V2.11 0 ～ Use Time displays how long has the device been used by the Use Time user. The use time can be erased 50000 h Displays related information of the device (Model, SN, About ——... -
Page 27: Cleaning And Disinfection
E-20C System User Manual V2.11 15. Cleaning and Disinfection WARNINGS! • Regular cleaning of the device and its accessories is very important for the prevention of respiratory infections. • To avoid electric shock, always unplug the device before cleaning. • Use washing liquid that is nontoxic to humans and does not cause allergies in humans. -
Page 28: Replacing The Air Filter
E-20C System User Manual V2.11 thoroughly. (3) After cleaning, air-dry the tube in a cool, well-ventilated area, and avoid direct sunlight. It takes approximately 30 minutes to completely air-dry the tube. Check whether the tube is completely dry before reuse. -
Page 29: Traveling With The Device
E-20C System User Manual V2.11 16. Traveling with the Device CAUTIONS! • Empty the water chamber of the humidifier before packing the device for your trip; in order to prevent any remaining water from entering the device. • Using the device at an incorrect elevation setting could result in airflow pressures higher than the prescribed setting. -
Page 30: Transferring The Device To Another Patient
E-20C System User Manual V2.11 17. Transferring the Device to Another Patient If the device is transferred to another patient, components in close contact with the previous owner, including the mask, headgear, tube, and air filter, should be cleaned and disinfected to prevent cross-infection. -
Page 31: Troubleshooting
E-20C System User Manual V2.11 21. Troubleshooting The table below lists common problems you may have with the device and possible solutions to those problems. If none of the corrective actions solve the problem, contact your home care provider. 21.1 Common Problems in Patients and Corresponding... - Page 32 E-20C System User Manual V2.11 Contact your physician equipment supplier. The patient is allergic to the Use a mask which is not made materials of the mask with natural rubber latex. Place a lining between the skin and mask Turn the humidity setting down, or raise the room temperature.
-
Page 33: Common Problems In The Device And Corresponding Solutions
E-20C System User Manual V2.11 21.2 Common Problems in the Device and Corresponding Solutions Problem Possible Cause Solution (s) Take a few deep breaths with the The Auto On / Off feature is mask on, and the device will start... -
Page 34: Emc Requirements
E-20C System User Manual V2.11 22. EMC Requirements Guidance and manufacturer's declaration - electromagnetic emissions The device is intended for use in the electromagnetic environment specified below. The user of the device should ensure that it is used in such an environment. - Page 35 E-20C System User Manual V2.11 Guidance and manufacturer's declaration - electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of the device should make sure that it is used in such an environment.
- Page 36 E-20C System User Manual V2.11 Guidance and manufacturer's declaration - electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of the device should make sure that it is used in such an environment.
- Page 37 E-20C System User Manual V2.11 Recommended separation distances between portable and mobile RF communications equipment and the device The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the device can help prevent...
- Page 38 E-20C System User Manual V2.11 Recommended separation distances between RF wireless communications equipment The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the device can help prevent...
-
Page 39: Limited Warranty
E-20C System User Manual V2.11 23. Limited Warranty ECE TIBBİ CİHAZLAR VE MEDİKAL SAN.TİC. A.Ş warrants that the device shall be free from defects of workmanship and materials and will perform in accordance with the product specifications for a period of one (1) year for main device and three (3) months for all accessories from the date of sale by ECE TIBBİ...
