Notilo Plus Seasam Quick Start Manual

With orphie camera
Hide thumbs Also See for Seasam:

Advertisement

Quick Links

Download this manual
Quick Start Guide Seasam
with ORPHIE Camera
December 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Seasam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Notilo Plus Seasam

Summary of Contents for Notilo Plus Seasam

  • Page 1 Quick Start Guide Seasam with ORPHIE Camera December 2022...
  • Page 2 ○ Choice of configuration ● Checking the connections ● Get both video feedback ● III - USING SEASAM WITH THE ORPHIE CAMERA Using the Orphie Camera ● Videos of the Orphie Camera ● At the end of the exploration ●...
  • Page 3 I - ORPHIE CAMERA INSTALLATION...
  • Page 4 I - ORPHIE CAMERA INSTALLATION Installation of the Orphie Camera Required Equipment Drone ● Sensor Network ● Structure with Orphie Camera ●...
  • Page 5 I - ORPHIE CAMERA INSTALLATION Installation of the Orphie Camera The battery must not be connected to the drone during this step. Connect the Orphie camera to the Sensor Network by Secure the plugs of the connectors together to prevent them connecting the camera cable to the Sensor Network connector from catching on anything else during operation...
  • Page 6 I - ORPHIE CAMERA INSTALLATION Installation of the Orphie Camera The battery must not be connected to the drone during this step. Place the structure on the drone Engage the structure on the 2 ball joints of the drone. ● Lower the front of the frame onto the drone.
  • Page 7 II - STARTING UP THE DRONE...

  • Page 8: Connecting The Battery

    II - STARTING UP THE DRONE Connecting the battery Turn the drone over and place it on the structure. Be careful not to damage the camera. Ensure that the emergency stop on the underside of the drone is Make sure the battery compartment is properly closed. properly inserted.
  • Page 9 II - STARTING UP THE DRONE Connecting the WiFi reel to the drone Standard Connector Attach and lock the carabiner on the structure to secure the Drone Subconn Connector...

  • Page 10: Starting Up The Equipment

    II - STARTING UP THE DRONE Starting up the equipment Turn on the controller. Press the "On" button once. After Place the magnet on the "Power" icon on top of the drone. several seconds the LED flashes The drone will turn on and test all its components. It will make quickly blue sounds and activate its lights.
  • Page 11 II - STARTING UP THE DRONE Connecting to the WiFi Reel Delivery after September 2021 Connect the tablet to the WiFI signal of the WiFI Reel. The wifi network is: "Seasam-WiFiReel-XXXX". The password is @Notilo+ Continue directly to page 12...
  • Page 12 The wifi network is: “notilo-beacon-XXXX” Select "WiFi Reel". ● The network name and password are displayed ● Connect the tablet to the WiFi network of the drone "Seasam-XXXX". ● Copy the password ● In the configuration part choose "Drone". ●...
  • Page 13 II - STARTING UP THE DRONE Choice of configuration Start Seasam Control or select "Choice of Configuration" if you have already opened the application. In the configuration menu, select "Orphie Camera".

  • Page 14: Checking The Connections

    II - STARTING UP THE DRONE Checking the connections Check that the indicated steps have been completed and select "Next".
  • Page 15 II - STARTING UP THE DRONE Checking the connections This screen checks that all the equipment is connected correctly. Once both connections are checked, click on "Continue" to access the control screen. Move a joystick on the controller to have the connection checked.
  • Page 16 II - STARTING UP THE DRONE Get both video feedback The video feedback of the ExploCam will appear at the bottom left of the screen. If not, you can click on the specific widget to display it.
  • Page 17 III - USING SEASAM WITH THE ORPHIE CAMERA...
  • Page 18 III - USING SEASAM WITH THE ORPHIE CAMERA Using the Orphie Camera You can switch the display of the video feedback at any time by pressing the symbol in the corner of the video feedback As the Orphie camera is located above the drone, the video feedback will not be seen from the same angle as the drone’s video feedback.
  • Page 19 III - USING SEASAM WITH THE ORPHIE CAMERA Videos from the Orphie camera The video from the Orphie Camera is recorded directly on the drone and you can find it on Notilo Cloud once the dive is recovered.
  • Page 20 III - USING SEASAM WITH THE ORPHIE CAMERA At the end of the exploration Turn off the drone Remove the battery Disconnect the ExploCam from the remote cable of your drone...
  • Page 21 More information : https://support.seasam.notiloplus.com/ Contact us : support@notiloplus.com...
