Notilo Plus Seasam Quick Start Manual

Navigator and cartography
Hide thumbs Also See for Seasam:

Advertisement

Quick Links

Download this manual
Navigator - Cartography
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Seasam and is the answer not in the manual?

Questions and answers

Related Manuals for Notilo Plus Seasam

Summary of Contents for Notilo Plus Seasam

  • Page 1 Navigator - Cartography...
  • Page 2 I - PREPARING FOR THE OPERATION Prepare your equipment ● Download the map ● II - SET UP CHOICE AND INSTALLATION Choice of set up ● Setup - Navigator Only ● Connecting the battery ○ Content Connection the Navigator to the drone - drone’s side ○...
  • Page 3 III - STARTING UP THE EQUIPMENT Starting up the equipment ● Connecting to the Ground Station ● Connection of the controller ● Choice of configuration ● Map Selection ● Set up & Connection - Navigator with USBL Content ● Checking the connections ●...
  • Page 4 I - PREPARING FOR THE OPERATION...
  • Page 5 M Batteries 2,5 hours 1 hours L Batteries 3,5 hours 1,5 hour XL Batteries * Up to 10 4 hours Navigator Battery for SEASAM Drone hours Control unit 3 hours 15 hours Controller 2 hours 14 hours Navigator 2,5 hours...
  • Page 6 I - PREPARING FOR THE OPERATION Prepare your equipment The day of the operation, verify the check list to avoid forget anything Navigator - Cartography Main equipment ❏ Seasam Drone ❏ Battery for the drone ❏ Opening tool for battery compartment ❏...
  • Page 7 I - PREPARING FOR THE OPERATION Download the map Before setting up the equipment, you have to download the map on Seasam Control App. To do so, turn on the control unit and connect it to internet Open Seasam Control and go directly to the settings...
  • Page 8 I - PREPARING FOR THE OPERATION Download the map Access the “Map” settings and select “download a new map”...
  • Page 9 I - PREPARING FOR THE OPERATION Download the map The world map open, zoom in as much as possible to the place where you will use the drone then give a name and save the map...
  • Page 10 I - PREPARING FOR THE OPERATION Download the map In the maps settings, the map appears in the archived map, select the cloud to download it. The map in now saved in the “downloaded maps”...
  • Page 11 II - SET UP CHOICE AND INSTALLATION...
  • Page 12 II - SET UP CHOICE AND INSTALLATION Choice of set up You can now prepare your equipment. With the Navigator you have two choices of set up : Navigator Only Navigator with USBL ● ● To replace the WiFi Reel To use the cartography feature and see both the ○...
  • Page 13 II - SET UP CHOICE AND INSTALLATION NAVIGATOR ONLY Setup - Navigator Only...

  • Page 14: Connecting The Battery

    II - SET UP CHOICE AND INSTALLATION NAVIGATOR ONLY Connecting the battery Ensure that the emergency stop on the underside of the drone is Make sure the battery compartment is properly closed. properly inserted. Use the dedicated tool. Make sure that the safety guide is aligned in the right direction...
  • Page 15 II - SET UP CHOICE AND INSTALLATION NAVIGATOR ONLY Connecting the Navigator to the drone - drone’s side Standard Connector Attach and lock the carabiner on the drone to secure the Drone Subconn Connector...
  • Page 16 II - SET UP CHOICE AND INSTALLATION NAVIGATOR ONLY Connecting the Navigator to the drone - Navigator’s side Connect the cable under the Navigator on the connector with a drone’s image Mind the guide on the cap to be sure you place it in the correct position ●...
  • Page 17 II - SET UP CHOICE AND INSTALLATION NAVIGATOR ONLY Set up the Navigator and the Ground Station Screw the two antennas with care on the Navigator and the the Ground Station Secure the ring while screwing the antennas. Be sure it is properly screw to ensure good connectivity and avoid losing the antennas. Your setup is complete you can go to page 25...
  • Page 18 II - SET UP CHOICE AND INSTALLATION NAVIGATOR & USBL Setup - Navigator with USBL...
  • Page 19 II - SET UP CHOICE AND INSTALLATION NAVIGATOR & USBL Set up the USBL transmitter and receiver on the Navigator and drone USBL Receiver USBL Transmitter Place the plot of the USBL under the Navigator and secure it. Connect the USBL transmitter to the cable under the drone Connect the cable under the Navigator on the connector with a pinger before to place the battery inside the drone.
  • Page 20 II - SET UP CHOICE AND INSTALLATION NAVIGATOR & USBL Connecting the battery Ensure that the emergency stop on the underside of the drone is Make sure the battery compartment is properly closed. properly inserted. Use the dedicated tool. Make sure that the safety guide is aligned in the right direction...
  • Page 21 II - SET UP CHOICE AND INSTALLATION NAVIGATOR & USBL Connecting the Navigator to the drone - drone’s side Standard Connector Attach and lock the carabiner on the drone to secure the Drone Subconn Connector...
  • Page 22 II - SET UP CHOICE AND INSTALLATION NAVIGATOR & USBL Connecting the Navigator to the drone - Navigator’s side Connect the cable under the Navigator on the connector with a drone sticker. Mind the guide on the cap to be sure you place it in the correct position ●...
  • Page 23 II - SET UP CHOICE AND INSTALLATION NAVIGATOR & USBL Set up the Navigator and the Ground Station Screw the two antennas with care on the Navigator and the the Ground Station Secure the ring while screwing the antennas. Be sure it is properly screw to ensure good connectivity and avoid losing the antennas.

  • Page 24: Starting Up The Equipment

    III - STARTING UP THE EQUIPMENT...
  • Page 25 III - STARTING UP THE EQUIPMENT Starting up the equipment Start the Ground Station. Start the Navigator by clicking once on the ON/OFF button Two blue LEDs light up at the bottom of the 6 LEDs on the antenna. When the Navigator and the ground station are fully connected, the other four LEDs light up.
  • Page 26 III - STARTING UP THE EQUIPMENT Starting up the equipment Place the magnet on the "Power" icon on top of the drone. Turn on the controller. The drone will turn on and test all its components. It will make sounds and activate its lights.
  • Page 27 III - STARTING UP THE EQUIPMENT Connecting to the Ground Station Once the 6 Blue LEDs of the Ground Station are lighted up, connect the tablet to the WiFi signal of the Ground Station The wifi network is: "GroundStation”. The password is @Notilo+...
  • Page 28 III - STARTING UP THE EQUIPMENT Connection of the controller Connect the tablet to the controller via Bluetooth Steelseries controller Switch Controller Device name: SteelSeries Stratus Duo Device name: Pro Controller...
  • Page 29 III - STARTING UP THE EQUIPMENT Choice of configuration Start Seasam Control or select "Choice of Configuration" if you have already opened the app. In the configuration menu, select the configuration corresponding to your setup NAVIGATOR ONLY NAVIGATOR & USBL...

  • Page 30: Map Selection

    III - STARTING UP THE EQUIPMENT Map selection The map previously downloaded (see page 7) is available and will be displayed when you are at the operation site. If you have more than one map downloaded there is no need to select, the system will automatically detect your location of operation.
  • Page 31 III - STARTING UP THE EQUIPMENT NAVIGATOR & USBL Set up & Connection - Navigator with USBL Check that you have not forget anything...

  • Page 32: Checking The Connections

    III - STARTING UP THE EQUIPMENT Checking the connections This screen checks that all the equipment is connected correctly. Once both connections are checked, click on "Continue" to access the control screen. Move a joystick on the controller to have the connection checked.
  • Page 33 III - STARTING UP THE EQUIPMENT NAVIGATOR & USBL USBL Calibration - Navigator with USBL Calibrate your USBL by following the instructions on the App. Please use extra care, the USBL must not receive any shocks.
  • Page 34 IV - USING CARTOGRAPHY...
  • Page 35 IV - USING CARTOGRAPHY Cartography interface You now have both the video feedback and the map on Seasam Control. You can switch between both of them by clicking on the square icon on the bottom left pop-up. Cartography settings and management...
  • Page 36 IV - USING CARTOGRAPHY Display the path You can display the path of your drone. Click on the setting icon on the bottom left of your screen. Then, check “Display path”. Save by clicking on “Apply”.
  • Page 37 IV - USING CARTOGRAPHY Add a marker To add a marker, select the location icon on the bottom left on your screen. Then, choose between a selected point on the map or to enter the coordinates of a precise point. If you choose the "XY point", a pop-up window appears allowing you to enter the coordinates of the marker.
  • Page 38 IV - USING CARTOGRAPHY Waypoint Select the marker you want the drone to go to then select “travel to” According to the set up, either the navigator (Navigator Only) or the drone (Navigator & USBL) will then go to the position of the marker. You cannot control the drone with the controller.
  • Page 39 IV - USING CARTOGRAPHY Waypoint If you want to stop the drone from going to the marker, select again the marker then : “Cancel” twice to stop it completely “Cancel” then “Pause” on the second display if you want to restart after...
  • Page 40 More information : https://support.seasam.notiloplus.com/ Contact us : support@notiloplus.com Confidential...
