Notilo Plus Seasam Quick Start Manual

With explocam
Hide thumbs Also See for Seasam:

Advertisement

Quick Links

Download this manual
Quick Start Guide
Seasam with ExploCam
December 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Seasam and is the answer not in the manual?

Questions and answers

Related Manuals for Notilo Plus Seasam

Summary of Contents for Notilo Plus Seasam

  • Page 1 Quick Start Guide Seasam with ExploCam December 2022...
  • Page 2 ● Choice of configuration ● Checking the connections ● Get both video feedback ● III - USING SEASAM WITH THE EXPLOCAM Drone launching ● Switch the camera view ● Inspecting a Sea Chest ● At the end of the exploration...
  • Page 3 I - EXPLOCAM INSTALLATION...
  • Page 4 I - EXPLOCAM INSTALLATION Installation of the ExploCam Equipment required Drone ● ExploCam Arm ● Foam ● Ring ● Access the video of the ExploCam installation here...
  • Page 5 I - EXPLOCAM INSTALLATION Installation of the ExploCam Place the drone on its back and open the battery compartment. Recover the cable from the drone and pull it out from the front of the drone.
  • Page 6 I - EXPLOCAM INSTALLATION The battery must not be connected to the drone during this step Installation of the ExploCam Connect the ExploCam cable with the drone’s connector. Securise the connection by clipping the two caps around the The two white dots must face each other and the two caps attach at the front of the drone closed together...
  • Page 7 I - EXPLOCAM INSTALLATION Installation of the ExploCam Position the foam on the metallic plate of the drone Smallest part of the foam must face the front of the drone. ● The open part of the foam is looking to the bottom of the drone ●...
  • Page 8 I - EXPLOCAM INSTALLATION Installation of the ExploCam Position the ring with the two nuts around the arm Insert the connectors inside the arm ● Unscrew the two silver screws and place the ring around the arm ● Screw the blue screw to maintain the ring around the arm ●...
  • Page 9 I - EXPLOCAM INSTALLATION Installation of the ExploCam Position the ExploCam vertically or Horizontally according to the tack you need to perform...
  • Page 10 I - EXPLOCAM INSTALLATION Installation of the ExploCam You can now connect the battery. Make sure the battery is never connected when you connect or disconnect the gripper connector under the drone.
  • Page 11 II - STARTING UP THE DRONE...
  • Page 12 II - STARTING UP THE DRONE Connecting the battery Make sure the battery compartment is properly closed. Ensure that the emergency stop on the underside of the drone is Use the dedicated tool. properly inserted. Make sure that the safety guide is aligned in the right direction...
  • Page 13 II - STARTING UP THE DRONE Connecting the WiFi reel to the drone Standard Connector Attach and lock the carabiner on the drone to secure the Drone Subconn Connector...
  • Page 14 II - STARTING UP THE DRONE Starting up the equipment Turn on the controller. Press the "On" button once. After Place the magnet on the "Power" icon on top of the drone. several seconds the LED flashes The drone will turn on and test all its components. It will make quickly blue sounds and activate its lights.
  • Page 15 II - STARTING UP THE DRONE Connecting to the WiFi Reel Delivery after September 2021 Connect the tablet to the WiFI signal of the WiFI Reel. The wifi network is: "Seasam-WiFiReel-XXXX". The password is @Notilo+ Continue directly to page 16...
  • Page 16 The wifi network is: “notilo-beacon-XXXX” Select "WiFi Reel". ● The network name and password are displayed ● Connect the tablet to the WiFi network of the drone "Seasam-XXXX". ● Copy the password ● In the configuration part choose "Drone". ●...
  • Page 17 II - STARTING UP THE DRONE Choice of configuration Start Seasam Control or select "Choice of Configuration" if you have already opened the application. In the configuration menu, select "Sea Chest Inspection".
  • Page 18 II - STARTING UP THE DRONE Checking the connections Check that the indicated steps have been completed and select "Next".
  • Page 19 II - STARTING UP THE DRONE Checking the connections This screen checks that all the equipment is connected correctly. Once both connections are checked, click on "Continue" to access the control screen. Move a joystick on the controller to have the connection checked.
  • Page 20 II - STARTING UP THE DRONE Get both video feedback The video feedback of the ExploCam will appear at the bottom left of the screen. If not, you can click on the specific widget to display it.
  • Page 21 III - USING SEASAM WITH THE EXPLOCAM...
  • Page 22 III - USING SEASAM WITH THE EXPLOCAM Drone launching Launch the drone in the water. Hold the drone by the Arm the drone by clicking on the "Arm" button at the top cable and gradually lower it one hand at a time.
  • Page 23 III - USING SEASAM WITH THE EXPLOCAM Switch the camera view You can switch camera’s view during the inspection Seasam Control App View...
  • Page 24 III - USING SEASAM WITH THE GRIPPER Inspecting a Sea Chest Access the sea chest Bring the drone above the sea chest ○ Dive to the proper depth ○ You can use the depth lock to help you Pitch the drone to face the sea chest Manage the depth to move the drone toward or away from the ○...
  • Page 25 III - USING SEASAM WITH THE EXPLOCAM At the end of the exploration Turn off the drone Remove the battery Disconnect the ExploCam from the remote cable of your drone...
  • Page 26 More information : https://support.seasam.notiloplus.com/ Contact us : support@notiloplus.com...
