Quick Start Guide Seasam
with OCULUS Camera
December 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Seasam and is the answer not in the manual?

Questions and answers

Related Manuals for Notilo Plus Seasam

Summary of Contents for Notilo Plus Seasam

  • Page 1 Quick Start Guide Seasam with OCULUS Camera December 2022...
  • Page 2 Delivery before September 2021 ○ Choice of configuration ● Checking the connections ● III - SET UP THE APPS Set up Seasam Control app to use the Oculus Camera ● Start the Oculus App ● At the end of the exploration ●...
  • Page 3 I - OCULUS CAMERA INSTALLATION...
  • Page 4 I - OCULUS CAMERA INSTALLATION Installation of the Orphie Camera Required Equipment Drone ● Sensor Network or Sensor Hub ● Structure with Oculus Camera ●...
  • Page 5 I - OCULUS CAMERA INSTALLATION Installation of the Oculus Camera The battery must not be connected to the drone during this step. Sensor Network Sensor Hub Connect the Oculus camera to Connect the sensor hub to the the Sensor Network by remote cable from the drone.
  • Page 6 I - OCULUS CAMERA INSTALLATION Installation of the Oculus Camera The battery must not be connected to the drone during this step. Place the structure on the drone Engage the structure on the 2 ball joints of the drone. ● Lower the front of the frame onto the drone.
  • Page 7 II - STARTING UP THE DRONE...
  • Page 8 II - STARTING UP THE DRONE Connecting the battery Turn the drone over and place it on the structure. Be careful not to damage the camera. Ensure that the emergency stop on the underside of the drone is Make sure the battery compartment is properly closed. properly inserted.
  • Page 9 II - STARTING UP THE DRONE Connecting the WiFi reel to the drone Standard Connector Attach and lock the carabiner on the structure to secure the Drone Subconn Connector...
  • Page 10 II - STARTING UP THE DRONE Starting up the equipment Turn on the controller. Press the "On" button once. After Place the magnet on the "Power" icon on top of the drone. several seconds the LED flashes The drone will turn on and test all its components. It will make quickly blue sounds and activate its lights.
  • Page 11 II - STARTING UP THE DRONE Connecting to the WiFi Reel Delivery after September 2021 Connect the tablet to the WiFI signal of the WiFI Reel. The wifi network is: "Seasam-WiFiReel-XXXX". The password is @Notilo+ Continue directly to page 13...
  • Page 12 The wifi network is: “notilo-beacon-XXXX” Select "WiFi Reel". ● The network name and password are displayed ● Connect the tablet to the WiFi network of the drone "Seasam-XXXX". ● Copy the password ● In the configuration part choose "Drone". ●...
  • Page 13 II - STARTING UP THE DRONE Choice of configuration Start Seasam Control or select "Choice of Configuration" if you have already opened the application. In the configuration menu, select "Basic".
  • Page 14 II - STARTING UP THE DRONE Checking the connections Check that the indicated steps have been completed and select "Next".
  • Page 15 II - STARTING UP THE DRONE Checking the connections This screen checks that all the equipment is connected correctly. Once both connections are checked, click on "Continue" to access the control screen. Move a joystick on the controller to have the connection checked.
  • Page 16 III - SET UP THE APPS...
  • Page 17 III - SET UP THE APPS Set up Seasam Control app to use the Oculus Camera Access the settings...
  • Page 18 III - SET UP THE APPS Set up Seasam Control app to use the Oculus Camera Select “Sensors” and “turn on”...
  • Page 19 III - SET UP THE APPS Start the Oculus App Start the dedicated Oculus App on your tablet, you will have the sonar video feedback. We invite you to consult the official Oculus website to know how to use the Oculus App...
  • Page 20 III - USING SEASAM WITH THE ORPHIE CAMERA At the end of the exploration Turn off the drone Remove the battery Disconnect the ExploCam from the remote cable of your drone...
  • Page 21 More information : https://support.seasam.notiloplus.com/ Contact us : support@notiloplus.com...
