- Page 1 Quick Start Guide Seasam with Gripper December 2022...
- Page 2 ● Seasam Control ● Set up and calibration ● Adding the gripper to the interface ● III - USING SEASAM WITH THE GRIPPER Drone launching ● Using the gripper during your dive ● At the end of the exploration ●...
- Page 3 I - GRIPPER INSTALLATION...
- Page 4 I - GRIPPER INSTALLATION Installation of the Gripper Equipment required Drone ● Arm gripper ● Foam ● Ring ● Access the video of the gripper installation here...
- Page 5 I - GRIPPER INSTALLATION Installation of the Gripper Place the drone on its back and open the battery compartment Recover the cable from the drone and pass on the gripper cable from the front of the drone to the battery compartment The battery must not be connected to the drone during this step...
- Page 6 I - GRIPPER INSTALLATION Installation of the Gripper Connect the gripper cable with the connecter inside the drone. Store the two connectors and the caps on the side of the battery The two white dots must face each other and the two caps compartment under the hull closed together The battery must not be connected to the drone during this step...
- Page 7 I - GRIPPER INSTALLATION Installation of the Gripper Position the foam around the gripper arm Insert the cubic part of the cable inside the drone’s hull until it gets Smallest part of the foam must face the front of the drone. close to the battery compartment ●...
- Page 8 I - GRIPPER INSTALLATION Installation of the Gripper Position the ring with the two nuts around the gripper arm Place the drone on its feets Unscrew the two silver screw Position the foam on the metallic plate on the drone ●...
- Page 9 I - GRIPPER INSTALLATION Installation of the Gripper You can now connect the battery. Make sure the battery is never connected when you connect or disconnect the gripper connector under the drone.
- Page 10 II - STARTING UP THE DRONE...
- Page 11 II - STARTING UP THE DRONE Connecting the battery Make sure the battery compartment is properly closed. Ensure that the emergency stop on the underside of the drone is Use the dedicated tool. properly inserted. Make sure that the safety guide is aligned in the right direction...
- Page 12 II - STARTING UP THE DRONE Connecting the WiFi reel to the drone Standard Connector Attach and lock the carabiner on the drone to secure the Drone Subconn Connector...
- Page 13 II - STARTING UP THE DRONE Starting up the equipment Turn on the controller. Press the "On" button once. After Place the magnet on the "Power" icon on top of the drone. several seconds the LED flashes The drone will turn on and test all its components. It will make quickly blue sounds and activate its lights.
- Page 14 II - STARTING UP THE DRONE Connecting to the WiFi Reel Delivery after September 2021 Connect the tablet to the WiFI signal of the WiFI Reel. The wifi network is: "Seasam-WiFiReel-XXXX". The password is @Notilo+ Continue directly to page 16...
- Page 15 The wifi network is: “notilo-beacon-XXXX” Select "WiFi Reel". ● The network name and password are displayed ● Connect the tablet to the WiFi network of the drone "Seasam-XXXX". ● Copy the password ● In the configuration part choose "Drone". ●...
- Page 16 II - STARTING UP THE DRONE Choice of configuration Start Seasam Control or select "Choice of Configuration" if you have already opened the application. In the configuration menu, select "Basic Configuration".
- Page 17 II - STARTING UP THE DRONE Checking the connections Check that the indicated steps have been completed and select "Next".
- Page 18 II - STARTING UP THE DRONE Checking the connections This screen checks that all the equipment is connected correctly. Once both connections are checked, click on "Continue" to access the control screen. Move a joystick on the controller to have the connection checked.
- Page 19 II - STARTING UP THE DRONE Adding the gripper to the interface Go in the Settings menu by clicking on the Notilo Plus button Seasam Control App View...
- Page 20 II - STARTING UP THE DRONE Adding the gripper to the interface Go to “Interface” tab and check the gripper case. Then save. Seasam Control App View...
- Page 21 I - START UP Adding the gripper to the interface The gripper button is now displayed on the main screen. Seasam Control App View...
- Page 22 III - USING SEASAM WITH THE GRIPPER...
- Page 23 III - USING SEASAM WITH THE GRIPPER Drone launching Launch the drone in the water. Hold the drone by the Arm the drone by clicking on the "Arm" button at the top cable and gradually lower it one hand at a time.
- Page 24 III - USING SEASAM WITH THE GRIPPER Using the gripper during your dive Select the gripper button to open or close it. Seasam Control App View...
- Page 25 III - USING SEASAM WITH THE GRIPPER At the end of the exploration Turn off the drone Remove the battery Disconnect the Gripper from the remote cable of your drone...
- Page 26 More information : https://support.seasam.notiloplus.com/ Contact us : support@notiloplus.com...
