DEMO MANUAL DC1771A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 2 CIN3, CIN6
2 2 COUT1, COUT3
3 2 COUT4, COUT9
4 2 C19, C33
5 2 C24, C30
6 1 C25
7 1 C28
8 1 C32
9 1 C27
10 1 C26
11 1 D2
12 1 L1
13 1 Q1
14 1 Q3
15 1 RSNSE
16 1 U1
17 4 R32, R36, R56, R58
18 2 R9, R10
19 1 R33
20 1 R37
21 1 R38
22 1 R39
23 1 R40
24 1 R51
25 6 R49, R50, R53, R57, R59, PTC
Additional Demo Board Circuit Components
1 1 CIN1
2 8 E1, E2, E4-E11
3 4 E3, E12-E14
Hardware-For Demo Board Only
1 1 JP3
2 1 JP2
3 2 XJP2, XJP3
4 4 (STAND-OFF)
4
PART DESCRIPTION
CAP , X5R 22μF 20% 25V 1210
CAP , 330μF 20% 2.5V POSCAP 7343
CAP , X5R 100μF 20% 6.3V 1210
CAP , X5R 1μF 10% 25V 0603
CAP , X7R 1nF 10% 25V 0603
CAP , X5R 0.1μF 10% 10V 0603
CAP , C0G 100pF 5% 50V 0603
CAP , C0G 10pF 5% 50V 0603
CAP , X5R 4.7μF 10% 10V 0603
CAP , C0G 470pF 5% 50V 0603
DIODE, CMDSH-3 SOD-323
IND., 0.4μH
XSTR, MOSFET LFPAK
XSTR, MOSFET LFPAK
RES, 0.002Ω 5% 1/4W 2512
IC, LTC3867EUF ,QFN 4mm x 4mm
RES, 0Ω JUMPER 0603
RES, 100Ω 1%, 1/10W 0603
RES, 100k 1% 1/10W 0603
RES, 2.2Ω 5% 1/10W 0603
RES, 49.9k 1% 1/10W 0603
RES, 75k 1% 1/10W 0603
RES, 10k 1% 1/10W 0603
RES, 37.4KΩ 1% 1/10W 0603
RES, 10Ω 1% 1/10W 0603
CAP , 150μF 20% 16V
TESTPOINT, TURRET, 0.094" PBF
JACK BANANA
HEADER 4-PIN 0.079 SINGLE ROW
HEADER 3-PIN 0.079 SINGLE ROW
SHUNT, 0.079" CENTER
STAND-OFF , NYLON 0.50"
MANUFACTURER/PART NUMBER
TAIYO YUDEN TMK325BJ226MM-T
SANYO 2R5TPE330MF
TDK C1608X5R1E105K
AVX 06033C102KAT
AVX 0603ZD104KAT
TDK C1608C0G1H101J
TDK C1608C0G1H100J
TDK C1608C0G1H471J
CENTRAL SEMI CMDSH-3-LTC
VITEC 59PR9875
RENESAS RJK0305DPB
RENESAS RJK0329DPB
PANASONIC ERJM1WTJ2MOU
VISHAY CRCW06030000Z0EA
VISHAY CRCW0603100RFKEA
VISHAY CRCW0603100KFKEA
VISHAY CRCW06032R20JNEA
VISHAY CRCW060349K9FKED
VISHAY CRCW060375KFKEA
VISHAY CRCW060310KFKEA
VISHAY CRCW060337K4FKEA
VISHAY CRCW060310R0FKEA
SANYO 16SVP150M
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
SAMTEC, TMM104-02-L-S
SAMTEC, TMM103-02-L-S
SAMTEC, 2SN-BK-G
KEYSTONE, 8832(SNAP ON)
