- Page 1 OPERATOR'S MANUAL ROLLER JCB116, JCB116D, JCB116DD EN - 9831/4600 ISSUE 3 - 09/2017 THIS MANUAL SHOULD ALWAYS STAY WITH THE MACHINE...
- Page 2 Operator's Manual. You must understand and follow the instructions in the Operator's Manual. If you do not understand anything, ask your employer or JCB dealer to explain it. OPERATOR'S Do not operate the machine without an Operator's...
- Page 3 Notes: 9831/4600-3 Find manuals at https://best-manuals.com...
-
Page 4: Table Of Contents
Table of Contents Contents Page No. Acronyms Glossary ............................Introduction About this Manual Model and Serial Number ........................1 Using the Manual ..........................1 Left-Hand Side, Right-Hand Side ......................1 Cab/Canopy ............................1 Cross References ..........................2 Safety Safety - Yours and Others ........................3 Safety Warnings ............................ - Page 5 Table of Contents Horn ..............................22 Beacon ..............................22 Automatic Vibration ..........................22 Vibration Amplitude ..........................22 Two Speed Range ..........................22 Operation Introduction General ..............................23 Operating Safety General ..............................24 Worksite Safety ........................... 26 Risk Assessment ..........................27 Walk-Around Inspection General ..............................
- Page 6 Table of Contents Working with the Drum Working without Vibration ........................59 Working with Vibration ........................59 Padfoot Shells ............................. 60 Heating, Ventilating and Air-Conditioning (HVAC) General ..............................63 Air-Conditioning Controls ........................63 Power Sockets Auxiliary Power Socket ........................65 Moving a Disabled Machine General ..............................
- Page 7 Table of Contents Maintenance Safety General ..............................89 Fluids and Lubricants ......................... 90 Maintenance Schedules General ..............................95 How to Use the Maintenance Schedules ................... 95 Maintenance Intervals ......................... 95 Pre-start Cold Checks, Service Points and Fluid Levels ..............96 Functional Tests and Final Inspection ....................
- Page 8 Table of Contents Hubs Oil ..............................133 Wheels General ............................. 135 Tyres General ............................. 137 Drum Scraper ............................. 139 Dampers ............................140 Drive Gearbox Oil ..............................142 Vibration System Oil ..............................144 Hydraulic System General ............................. 145 Services ............................146 Oil ..............................
- Page 9 Table of Contents Wheels and Tyres General .............................. 173 Tyre Sizes and Pressures ........................ 173 Declaration of Conformity General .............................. 175 Data ..............................176 Warranty Information Service Record Sheet ........................178 9831/4600-3 Find manuals at https://best-manuals.com...
-
Page 10: Acronyms Glossary
Table of Contents Acronyms Glossary CESAR Construction Equipment Security and Registration FEAD Front End Accessory Drive FOPS Falling Object Protective Structure HVAC Heating Ventilation Air Conditioning Light Emitting Diode Product Identification Number Personal Protective Equipment Root Mean Square ROPS Roll-Over Protective Structure Revolutions Per Minute 9831/4600-3 Find manuals at https://best-manuals.com... - Page 11 Notes: viii 9831/4600-3 viii...
-
Page 12: Introduction
Particular attention must be given to all the safety aspects of operating and maintaining the machine. If there is anything you are not sure about, ask your JCB dealer or employer. Do not guess, you or others could be killed or seriously injured. -
Page 13: Cross References
Introduction About this Manual Cross References In this manual, cross references are made by presenting the subject title in blue (electronic copy only). The number of the page upon which the subject begins is indicated within the brackets. For example: Refer to: Cross References (Page 2). -
Page 14: Safety
If you do not fully understand the warning messages, ask your employer or JCB dealer to explain them. Safety is not just a matter of responding to the warnings. All the time you are working on or with the machine you must be thinking of what hazards there might be and how to avoid them. -
Page 15: General Safety
Lightning can kill you. Do not use the machine if there is lightning in your area. Machine Modifications This machine is manufactured in compliance with prevailing legislative requirements. It must not be altered in any way which could affect or invalidate its compliance. For advice consult your JCB dealer. 9831/4600-3... -
Page 16: Clothing And Personal Protective Equipment (Ppe)
Introduction Safety Clothing and Personal Protective Equipment (PPE) Do not wear loose clothing or jewellery that can get caught on controls or moving parts. Wear protective clothing and personal safety equipment issued or called for by the job conditions, local regulations or as specified by your employer. - Page 17 Notes: 9831/4600-3...
-
Page 18: About The Product
Product Compliance Your JCB product was designed to comply with the laws and regulations applicable at the time of its manufacture for the market in which it was first sold. In many markets, laws and regulations exist that require the owner to maintain the product at a level of compliance relevant to the product when first produced. -
Page 19: Description
Description Description General The JCB116 machine is a self-propelled, vibratory single drum roller which is powered by a 4 cylinder, diesel engine. Two scrapers are mounted on the machine. The hydrostatic drive system allows for infinitely variable travel speeds. The drive motor (mounted on the left side of the drum) incorporates a spring on, pressure off brake system which engages when the machine is in neutral. -
Page 20: Danger Zone
Prior to use of the machine, its suitability (size, performance, specification etc.) should be considered with regards to the intended application and any relevant hazards that may exist. Contact your JCB dealer for support in determining the appropriate JCB machine, attachment and any optional equipment that is suitable for the application and environment. -
Page 21: Main Component Locations
