Aewin AW-F703 User Manual

Pentium 4 full-size cpu card with vga, lan, tv-out , dvi interface & audio pci/isa bus, picmg compliant
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Pentium 4 Full-Size CPU Card
With VGA, LAN, TV-out , DVI Interface & Audio
PCI/ISA Bus, PICMG Compliant
User's Manual
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW-F703 and is the answer not in the manual?

Questions and answers

Related Manuals for Aewin AW-F703

Summary of Contents for Aewin AW-F703

  • Page 1 Pentium 4 Full-Size CPU Card With VGA, LAN, TV-out , DVI Interface & Audio PCI/ISA Bus, PICMG Compliant User’s Manual Version 1.1...
  • Page 2 © Copyright 2002. All Rights Reserved Manual edition 1.0, Jan.2003 This document contains proprietary information protected by copyright. All rights are reserved, no part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without prior written permission of the manufacturer.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1. General Information 1.1 Introduction---------------------------------------------------------------------------------1 1.2 Specification---------------------------------------------------------------------------------1 1.3 AW-F703 Package--------------------------------------------------------------------------2 1.4 Board Layout--------------------------------------------------------------------------------3 1.5 Board Dimension---------------------------------------------------------------------------4 Chapter 2. Connectors Location and Configuration 2.1 Connectors/Jumpers Location and Define--------------------------------------------5 2.2 Installing CPU------------------------------------------------------------------------------6 2.3 Installing System Memory----------------------------------------------------------------6 2.4 Connector and Jumpers Settings------------------------------------------------------ 7 Chapter 3.

  • Page 4: Chapter 1. General Information

    Chapter 1. General Information 1.1 Introduction The AW-F703 is fully function of socket 478 Pentium® 4 CPU Card, which is PCI/ISA bus and PICMG compliant. The AW-F703 with Intel® 845PE and ICH4 chipset supports Intel® Pentium® 4 processors with 533MHz system bus, with two 184-pin DDR DIMM sockets for DDR SDRAM to 2Gbytes.

  • Page 5: Aw-F703 Package

    13.3"(L) x 4.8"(W) (338mm x 122mm) 1.3 AW-F703 Package Please make sure that the following items have been included in the package before installation. AW-F703 Socket 478 Single Board Quick Installation Guide Cable: Please refer to Appendix C Optional Cables AW-F703...

  • Page 6: Board Layout

    Ground yourself before removing any system component from it protective anti-static packaging. To ground yourself, grasp the expansion slot covers or other unpainted parts of the computer chassis. Handle the AW-F703 board by its edges and avoid touching its component. 1.4Board Layout AW-F703...

  • Page 7: Board Dimension

    User’s manual 1.5Board Dimension AW-F703...

  • Page 8: Chapter 2. Connectors Location And Configuration

    Internal Keyboard Connector IDE1 Connector CN16 KB/MS Connector P4 12V Power CN17 VGA D-Sub Connector Floppy Connector CN18 AC-97 Connector LPT Connector CN19 LAN1 Connector CN10 USB Connector CN20 FAN Connector RS232/422/485 Select CN21 FAN Connector Watchdog Select CMOS Setting AW-F703...

  • Page 9: Installing Cpu

    User’s manual 2.2 Installing CPU The AW-F703 with 478 socket supports Intel® Pentium® 4 processors, up to 533MHz system bus. The m478PGA form factor is a chip packaging designed for the Intel® Pentium 4 processors up to 533MHz System Bus. On the m478PGA package, the processor’s silicon core faced up, and is expose.

  • Page 10: Connector And Jumpers Settings

    To remove a DDR DIMM Memory: Press down on the levers at both end of module until the module pops out. 2.4 Connector and Jumper Settings CN1: TV-Out Connector Define LUMINANCE OUT CROMIANCE OUT Ground Ground COMPOSITE OUT AW-F703...
  • Page 11 Pin 5-6: this 2-pin connector connects to case-mounted ATX power button Pin 7-8: this 2-pin connector connects to case-mounted Reset Switch, you can use it to reboot the system CN4: Main Power Connector Define +12V Ground AW-F703...
  • Page 12 SDD7 SDD8 SDD6 SDD9 SDD5 SDD10 SDD4 SDD11 SDD3 SDD12 SDD2 SDD13 SDD1 SDD14 SDD0 SDD15 Ground SDREQ Ground SDIOW# Ground SDIOR# Ground SIORDY DECECT SDDACK# Ground IRQ15 SDA1 DECECT SDA0 SDA2 SDCS#1 SDCS#3 IDEACTS# Ground CN6: IDE1 Connector AW-F703...
  • Page 13 DREQ Ground DIOW* Ground DIOR* Ground IOCHRDY CSEL DACK* Ground IRQ14 DETECT HD SELECT 0* HD SELECT 1* ACTIVE* Ground CN7: ATX Power 12V Define Define +12V Ground +12V Ground CN8: Floppy Connector Define Define Ground 2 DENSITY SELECT0* AW-F703...
  • Page 14 Ground WRITE GATE* Ground TRAK00* Ground WRITE PROTECT* Ground READ DATA* Ground SIDE 1 SELECT* Ground DISK CHANGG* CN9: Printer Connector Define Define STROBE AFD# ERR# INIT# SLIN# Ground Ground Ground Ground Ground ACK# Ground BUSY Ground Ground SLCT AW-F703...
  • Page 15 User’s manual CN10:USB Connector Define Define Ground Ground Ground CN11: COM2 Connector Define Define DCD1 DSR1 RXDD1 RTS1 TXDD1 CTS1 DTR1 Ground 422/485TX+ 422/485TX- 422RXD+ 422RXD- CN12: DVI Connector Define Define AW-F703...
  • Page 16 User’s manual TX2N TX0N TX2P TX0P TXCN DATA TXCP TX1N CHARGE TX1P CN13: IR Connector Define IRRX Ground IRTX CN14: COM1 D-Sub Connector Define Ground CN15: Internal Keyboard Connector AW-F703...
  • Page 17 User’s manual Define KB-CLK KB-DATA Ground CN16: Keyboard/Mouse Connector Define KB-DATA MS-DATA Ground KB-CLK MS-CLK CN17: VGA D-Sub Connector Define AW-F703...
  • Page 18 Ground Ground MONID1 DDC DATA HSYNC VSYNC DDC CLOCK CN18: AC-97 Connector Signal Signal +12V AC97-BTCLK +3.3V KEY PIN AC97-SDIN0 AC97-SYNC AC97-RESET AC97-SDOUT PC-BEEP NOTE: Some AC97 connector with housing that connector pin 6 is N/C. CN19: LAN1 Connectors AW-F703...
  • Page 19 MDI0+ MDI0- MDI1+ MDI2+ MDI2- MDI1- MDI3+ MDI3- LINK100_N LINK1000_N LINK_UP_N ACTIVITY_N LED: Bi-Color Speed LED 10 Mbps 100 Mbps Green 1000 Mbps Yellow Link/Activity LED Link Green Activity Blink CN20, CN21: FAN Connector Define Ground +12V Speed Detect AW-F703...
  • Page 20 User’s manual JP1: RS232/422/485 Select Setting Define RS-232 (Default) RS-422 RS-485 JP2: Reset Select Setting Define IRQ11 Reset Switch (Default) JP3: CMOS Setting Setting Define Normal Clear CMOS AW-F703...

  • Page 21: Chapter 3. Bios Setup

    User’s manual Chapter 3. BIOS Setup The ROM chip of your AW-F703 board is configured with a customized Basic Input/Output System (BIOS) from Phoenix-Award BIOS. The BIOS is a set of permanently recorded program routines that give the system its fundamental operational characteristics.
  • Page 22 Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Save User Password PnP/PCI Configuration Save & Exit Setup PC Health Status Exit Without Saving : Select Item F10: Save & Exit Setup Time, Date, Hard Disk Type..AW-F703...
  • Page 23 Configure power management features such as timer selects PNP/PCI CONFIGURATION: Configure Plug & Play IRQ assignments and PCI slots PC HEALTH STATUS: Configure the CPU speed and, if the optional Winbond W83627HF system monitor IC is installed, view system information FREQUENCY/VOLTAGE CONTROL AW-F703...
  • Page 24 Save changes of values to CMOS and exit the CMOS setup program EXIT WITHOUT SAVING: Abandon all CMOS changes and exit the CMOS setup program Standard CMOS Features Setup Use the Standard CMOS Setup option as follows: 1. Choose “Standard CMOS Features” from the main menu. The following screen appears: AW-F703...
  • Page 25 Cylinders, heads, Wpcom, L-Zone, sectors, and mode Consult the documentation received with the drive for the values that will give you optimum performance. Drive A/Drive B: Choose: None 360K, 5.25” 1.2M, 5.25” 720K, 3.5” 1.44M, 3.5” 2.88M, 3.5” AW-F703...
  • Page 26 Typematic Delay (Msec) <250> write data into this area, Security Option <Setup> BIOS will show a waring message on screen and alarm beep Enter:Select +/-/PU/PD:Value F10:Save ESC: Exit F1: General Help F7:Optimized Defaults F5:Previous Value F6:Fail-Safe Default AW-F703...
  • Page 27 Choose Setup or System. This lets you specify whether a password is required every time the system boots or only when an attempt is made to enter the CMOS Setup program. “Setup” – The password prompt only appears if you attempt to enter the CMOS setup AW-F703...
  • Page 28 Choose Enabled/Disabled if you have an ISA card compatibility problem, when enabled, this option lets you control the Delay Transaction function of the chipset. This function is used to meet the latency of the PCI cycles to or from the ISA bus. AW-F703...
  • Page 29 2. Move between items and select values by using the arrow keys. Modify the selected fields using the PgUP/PgDN keys. Please press the <F1> key for information on the various options. On-Chip Primary/Secondary PCI IDE: Enables/Disables. Select Enabled to activate the primary IDE interface. Select AW-F703...
  • Page 30 This option lets you choose the priority of AGP & PCI VGA card AC-97 Audio: Choose Auto/Disabled BIOS Lock Control: Choose Lock/Unlock IDE HDD Block Mode: Enabled/Disabled the IDE HDD Block Mode function. Note: Not all drives support this function Onboard FDC Controller: AW-F703...
  • Page 31 This option lets you to determine onboard game port address setting Midi Port Address/IRQ: Choose: 300/IRQ10 This option lets you to determine onboard Midi port address and IRQ setting Watchdog Timer Select: To select Watchdog Timer wait state time: 10/20/30/40 sec./1/2/4 min./Disabled AW-F703...
  • Page 32 Enables/Disables the ACPI function ACPI Suspend Type: Choose SI (POS) / S3 (STR) / S1 & S3 Power Management: Choose Disable, User Define, Min Saving or Max. Saving. “User Define” – Lets you specify when the HDD and system will shut down AW-F703...
  • Page 33 Press the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung” CPU Thermal-Throttling: Choose 12.5%, 25%, 37.5%, 50%, 62.5%, 75%, 87.5% Power On by Ring: Enabled/Disabled. When enabled, the system will power up automatically when modem ring. AW-F703...
  • Page 34 This option is used to configure Plug and Play assignments and route PCI interrupts to designated ISA interrupts. Use the PNP/PCI Configuration Setup option as follows: 1. Choose “PNP/PCI Configuration Setup” from the main menu, the following screen appears. AW-F703...
  • Page 35 IRQ-5 Assigned to <PCI Device> IRQ-7 Assigned to <PCI Device> IRQ-9 Assigned to <PCI Device> IRQ-10 Assigned to <PCI Device> IRQ-11 Assigned to <PCI Device> IRQ-12 Assigned to <PCI Device> IRQ-14 Assigned to <PCI Device> IRQ-15 Assigned to <PCI Device> AW-F703...
  • Page 36 -12 V -12.11 V VBAT(V) 3.29 V 5VSB(V) 4.96 V Shutdown Temperature <Disabled> Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F7:Optimized Defaults F5:Previous Value F6:Fail-Safe Default Frequency/Voltage Control Option Choose the “Frequency/Voltage Control” from main menu, the following screen appears: AW-F703...
  • Page 37 To use this feature, highlight it on the main screen and press <Enter>. A line will appear on the screen asking if you want to load the BIOS default values. Pres the <Y> key and then press <Enter> if you want to load the BIOS default. Load Optimized Defaults AW-F703...
  • Page 38 Then type your new password at the prompt. The password is case sensitive and you can use up to 8 alphanumeric characters. Press <Enter> after entering the password. At the Next Prompt, confirm the new password by typing it and pressing <Enter> again. AW-F703...
  • Page 39 Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Exit Without Saving Use this function to exit Setup without saving the CMOS value. AW-F703...
  • Page 40 PC Health Status Esc : Quit : Select Item F10 : Save & Exit Setup Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... Time, Date, Hard Disk Type... AW-F703...

  • Page 41: Chapter 4. Drivers And Utilities Installation

    User’s manual Chapter 4. Driver Utility The AW-F703 drivers and utilities CD-ROM contains the following folders. 1.VGA: VGA drivers 2.LAN: Ethernet drivers 3.Sound:AC-97 drivers 4.845PE :845PE drivers 5.Manual The Intel® Chipset Software Installation Utility installs to the target system the Windows* INF files that outline to the operating system how the chipset components will be configured.
  • Page 42 Windows XP operating systems. 1. Insert the Drivers and Utilities CD into the CD ROM drive (example E:) 2. Double click the “845PE\Iaa” folder in drive E: to open it run “iaa**.exe” (1) Click “Next” (2) Click “Yes” AW-F703...
  • Page 43 (5)Click “Finish” to restart your system VGA Driver The AW-F703 is a powerful, compact and full function single board computer that can be used in multitude of embedded applications. The board is designed with ATI Radeon 7000 4X AGP , it supports 32/64MB DDR memory , CRT display and TV-out interface , also supports DVI interface.
  • Page 44 User’s manual Intel Network Driver “My Computer” Properties (2)Click “Hardware” “Device (1)Click Manager” (3)Click “Other devices” ”Ethemet Controller” (4)Click “Reinstall Driver” (5) Click “Next” (6) Click “Next” AW-F703...
  • Page 45 1. Insert the Drivers and Utilities CD into the CD ROM drive (example E:) 2. Double click the “Sound” folder in drive E: to open it and run “Setup” program by double click it. (1) Double click “setup.exe” (2) Click “Next” AW-F703...
  • Page 46 User’s manual (3)Click “Finish” to resrart your system AW-F703...

  • Page 47: Appendix A. Programming The Watchdog Timer

    User’s manual Appendix A: Programming the Watchdog Timer The AW-F703 provides a watchdog timer that resets the CPU or generates an interrupt if processing comes to a stop. This function ensures greater system reliability in industrial stand-alone and unmanned environments.

  • Page 48: Appendix B. Ac-97 Audio Kit Optional

    8. Run Program 2 (reload the timer interval value of 3CH, 60 seconds) 9. Run Program 1 10. Run Program 3 (Load the timer interval of 00H, and disable the watchdog timer function) Appendix B: AC-97 Audio Kit AC97 Board Layout AW-F703...
  • Page 49 User’s manual AC97 Board Dimension AC97 Location of Connector AW-F703...
  • Page 50 CN1: This MIC-In jack connects to a microphone CN2: This Line-In jack connects to a tape player or other audio sources. CN3: This Speaker-Out jack connects to a headphone or a speaker. CN4: CD Audio Input Connector 1 2 3 4 Pin Signal CD AIDIO-L AW-F703...

  • Page 51: Appendix C: System Resources

    Appendix C: System Resources Interrupt Controller The AW-F703 is a fully PC compatible control board, it consists of 16 ISA interrupt request lines and most of them already in used by other part of the board. Both of ISA and PCI expansion cards may need to use IRQs, please make sure that the IRQs do not conflict if you would like to use extra add-on cards.
  • Page 52 DMA4 Cascade DMA5 Free DMA6 Free DMA7 Free Memory Map The following table indicates memory of AW-F703. The address ranges specify the runtime code length. Memory below 1MB (1Mb ~ 640KB) Address Range Type Owner A0000~AFFFF VGA Adapter B0000~BFFFF VGA Adapter...
  • Page 53 AT Interrupt Controller C0 ~ DF AT DMA Controller F0 ~ FF Math Coprocessor 170 ~ 177 IDE Controller 1F0 ~ 1F7 IDE Controller 220 ~ 22E Sound Card 294 ~297 PCI Bus 2F8 ~ 2FF Communication Port (COM2) AW-F703...

  • Page 54: Appendix D: Order Information

    B000 ~ B01E USB Controller B400 ~ B41E USB Controller B800 ~ B81E USB Controller F000 ~ F00E IDE Controller Appendix D: Order Information AW-F703 P4 CPU Card w/o CPU, with VGA –32MB DDR MemoryDVI,10/100 LAN AC97-1881 Audio kit for AW-F703 AW-F703...

  • Page 55: Appendix E. Optional Cable List

    User’s manual Appendix E: Optional Cables List Part Number Cable Description AW-F703 Terminating Connector Connector 46-ATA660-00 ATA-66 IDE Cable CN5, CN6 ATA66 IDE Cable, 46cm 46-IFDC01-00 Floppy Cable Floppy Cable 2.54 to 2.0mm, 50cm 46-I606KP-00 KB + PS/2 Mouse Cable...
