- Page 1 Low Power Embedded SBC with VGA, LAN, TV-out, Card Bus, Audio & SSD User’s Manual Version 1.0...
- Page 2 © Copyright 2002. All Rights Reserved Manual edition 1.0, Jan, 2003 This document contains proprietary information protected by copyright. All rights are reserved, no part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without prior written permission of the manufacturer.
-
Page 3: Table Of Contents
Table of Contents Chapter 1. General Information-------------------------------------------------------------2 1.1 Introduction---------------------------------------------------------------------------------2 1.2 Specification---------------------------------------------------------------------------------2 1.3 AW-EM650 Package-----------------------------------------------------------------------4 1.4 Board Layout--------------------------------------------------------------------------------5 1.5 Board Dimension---------------------------------------------------------------------------5 Chapter 2. Connectors Location and Configuration------------------------------------8 2.1 Connectors/Jumpers Location and Define--------------------------------------------8 2.2 Onboard rocessors------------------------------------------------------------------------10 2.3 Installing System Memory--------------------------------------------------------------10 2.4 Connector and Jumpers Settings------------------------------------------------------10 CN1:TV-OUT----------------------------------------------------------------------------------10 CN2:AUDIO (SPK &... - Page 4 JP5: Watchdog Timer ----------------------------------------------------------------------21...
- Page 5 User’s manual Chapter 3. BIOS Setup-----------------------------------------------------------------------22 3.1 Quick Setup--------------------------------------------------------------------------------22 3.2 Entering the CMOS Setup Program--------------------------------------------------22 3.3 Menu Options-----------------------------------------------------------------------------24 Standard CMOS Features--------------------------------------------------------------25 Advanced BIOS Features---------------------------------------------------------------26 Advanced Chipset Features------------------------------------------------------------29 Integrated Peripherals------------------------------------------------------------------32 Power Management Setup-------------------------------------------------------------35 PNP/PCI Configuration----------------------------------------------------------------36 PC Health Status-------------------------------------------------------------------------38 Frequency/Voltage Control------------------------------------------------------------39 Load Fail-Safe Default------------------------------------------------------------------39 Load Optimized Default----------------------------------------------------------------39 Set Supervisor &...
-
Page 6: Chapter 1. General Information
User’s manual Chapter 1. General Information 1.1 Introduction The AW-EM650 is a full function of 5.25” Embedded format SBC board use Intel® 815E and ICH2 chipset supports Intel® 400/650MHz (Micro-FCBGA packaging) ultra low power processors and optional Intel® PIII uFCBGA LV processors up to 933MHz and Celeron Socket 479 uFCPGA up to 1.333GHz. - Page 7 User’s manual Onboard 32/64/128MB and one 144-pin SO-DIMM socket Memory supports up to 512Mbytes SDRAM Support 2.5” IDE HDD Enhanced IDE Serial port One RS-232 and one RS-232/422/485 serial port KB/Mouse connector Supports PS/2 keyboard and PS/2 mouse USB connectors Supports two USB ports Lithium battery for data retention of up to 10 years (under Battery...
-
Page 8: Aw-Em650 Package
User’s manual Provides dual RCA(composite) video connectors Output connector Sound Interface AC 97 codec Chipset SoundBlaster Pro Hardware and Direct Sound Ready AC97 Audio Controller Digital Audio Mic in, Speaker out Audio interface Mechanical and Environmental +12V(11.4 to 12.6V) Power supply voltage 5A@+12V Max. -
Page 9: Board Layout
User’s manual Precautions Please make sure you properly ground yourself before handling the AW-EM650 board or other system components. Electrostatic discharge can be easily damage the AW-EM650 board. Do not remove the anti-static packing until you are ready to install the AW-EM650 board. - Page 10 User’s manual AW-EM650...
- Page 11 User’s manual AW-EM650...
-
Page 12: Chapter 2. Connectors Location And Configuration
User’s manual Chapter 2. Connectors/Switch Location and Configuration 2.1 Connectors/Jumpers Location and Define Location Description TV-OUT(DUAL) CONNECTOR AUDIO(SPK & MIC) CONNECTOR TV-OUT HEADER (DUAL) COM PORT(DUAL) CONNECTOR RESET HEADER AUDIO HEADER (SPK&MIC) VGA(DUAL) CONNECTOR USB0 HEADER LAN & USB 0/1 CONNECTOR CN10 KEYBOARD HEADER CN11... - Page 13 User’s manual CN14 COM PORT HEADER CN15 LAN LED HEADER CN16 VGA HEADER (DUAL) CN17 LAN HEADER CN18 IDE HEADER CN19 POWER HEADER FAN1 FAN CONNECTOR FAN2 FAN CONNECTOR RESET BUTTON DISK ON CHIP SOCKET Location Description SODIMM SOCKET CF_SOCKET1 COMPACT FLASH SOCKET CN20 PCMCIA SOCKET...
-
Page 14: Onboard Rocessors
User’s manual 2.2. Onboard Processors The AW-EM650 onboard built-in Intel® 400/650(Micro-FCBGA packaging) ultra low power processors. The CPU cooler fan will be mounted when board with 650MHz CPU and the high profile Heatsink will be mounted when 400MHz CPU. 2.3 Installing Memory To insert a DIMM Memory: The AW-EM650 supports one 144-pin DIMM sockets, memory up to 512Mbyte. -
Page 15: Cn3: Tv-Out Header
User’s manual CN3: TVOUT HEADER (DUAL) – 2mm connector Assignment CN4: COM PORT – COM1 & COM 2 Define Ground AW-EM650... -
Page 16: Cn5:Reset Header
User’s manual CN5: RESET HEADER – 2mm conncctor Assignment HWRST CN6: AUDIO HEADER (SPK & MIC) Assignment LINQUTR LINQUTL CN7: VGA (DUAL) Signal Signal GREEN Ground BLUE DDC Data Ground H-SYNC Ground V-SYNC Ground DDC Clock Ground AW-EM650... -
Page 17: Cn8:Usb0 Header
User’s manual CN8: USB0 HEADER Assignment USBVCC0 USBDATA0 - USBDATA0 + USBGND0 CN9: LAN & USB D2: Speed indicated LED 10 Mbps 100 Mbps GREEN D1 :Link/Activity LED Link YELLOW Activity BLINKING AW-EM650... -
Page 18: Cn10:Keyboard Header
User’s manual CN10: KEYBOARD HEADER Assignment KB CLOCK KB DATA KSMSVCC CN11: POWER & HDD LED HEADER Assignment Define POWER LED VCC3 IDEACT# HDD LED VCC3 CN12: USB1 HEADER Assignment USB VCC1 USB DATA1 - USB DATA1 + USBGND1 AW-EM650... -
Page 19: Cn13: Mouse Header
User’s manual CN13: MOUSE HEADER Assignment MS CLOCK MS DATA KBMSVCC CN14: COM PORT HEADER Assignment Assignment DCD0# DSR0 RXDD0 RTS0 TXDD0 CTS0 DTR0 SNRI0# DCD1# DSR1 RXDD1# RTS1 TXDD1 CTS1 DTR1 SNRI1# CN15: LAN LED HEADER AW-EM650... -
Page 20: Cn16: Vga Header
User’s manual Assignment SPEEED VCC3 LINK ACTIVE CN16:VGA HEADER (DUAL) Assignment Assignment CRT0 CRT2 CRT3 5VDDCCL 5VDDCDA CRT1 CRT2 CRT3 CN17: LAN HEADER AW-EM650... -
Page 21: Cn18: Ide Header
User’s manual Assignment Assignment TDD + TDD - RDD + RDD - CN18: IDE HEADER Signal Signal Reset IOW# Ground Ground Data7 IOR# Data8 Ground Data6 IRDY Data9 Ground Data5 DACK# Data10 Ground Data4 IRQ14 Data11 Data3 Address 1 Data12 Detect Data2 Address 0... -
Page 22: Cn20: Pcmcia Connector
User’s manual CN20: PCMCIA CONNECTOR Signal Signal Signal Signal +VPPA +VPPB ACCLK BCCLK ACAD0 BCAD0 ACCD1# ACTRDY# BCCD1# BCTRDY# ACAD1 ACIRDY# BCAD1 BCIRDY# ACAD2 ACFRAME# BCAD2 BCFRAME# ACAD3 ACCBE#2 BCAD3 BCCBE#2 ACAD4 ACAD17 BCAD4 BCAD17 ACAD18 BCAD18 ACAD5 BCAD5 ACAD6 ACAD19 BCAD6 BCAD19... - Page 23 User’s manual ACAD16 ACSTSCHG# BCAD16 BCSTSCHG# ACAD27 BCAD27 ACPAR ACAD28 BCPAR BCAD28 ARSVD/A18 ACAD29 BRSVD/A18 BCAD29 ACPERR# ACAD30 BCPERR# BCAD30 ACBLOCK# ARSVD/D2 BCBLOCK# BRSVD/D2 ACGNT# ACAD31 BCGNT# BCAD31 ACSTOP# BCSTOP# ACINT# ACLKRUN# BCINT BCLKRUN# ACDEVSEL# ACCD2 B36 BCDEVSEL# B75 BCCD2# +VCCA +VCCB +VCCA...
-
Page 24: Jp1:Tv-Out Signal Select
User’s manual Jumper setting List of Jumpers Description TV-OUT - NTSC/PAL Signal Select RS232/RS422/RS485 Select COM1/COM2 RI/Voltage Select Clear CMOS Watch Dog Timer Action Select 1. JP1 Default : 1-2 NTSC , 2-3 PAL 2. JP2 COM2 RS-232/422/485 Selector (Default: RS-232) Setting COM Port 5-6, 9-11, 10-12, 15-17, 16-18 RS-232 (Default) -
Page 25: Jp4 Clear Cmos
User’s manual COM1 COM1 RI (Default) Clear CMOS Setting Define Normal Status (Default) Clear CMOS 5. JP5 Watchdog Timer/Action Select Setting Define PIRG#E Watch Dog (Default) AW-EM650... -
Page 26: Chapter 3. Bios Setup
User’s manual Chapter 3. BIOS Setup The ROM chip of your AW-EM650 board is configured with a customized Basic Input/Output System (BIOS) from Phoenix-Award BIOS. The BIOS is a set of permanently recorded program routines that give the system its fundamental operational characteristics. - Page 27 User’s manual Use the CMOS Setup program to modify the system parameters to reflect the options installed in your system and to customized your system. For example, you should run the Setup program after you: Received an error code at startup Install another disk drive Use your system after not having used it for a long time Find the original setup missing...
-
Page 28: Menu Options
User’s manual 3. Choose a setup option with the arrow keys and press <Enter>. See the following sections for a brief description of each setup option. In the main menu, press F10 (“Save & Exit Setup) to save your changes and reboot the system. - Page 29 User’s manual limit access to the system. Save & Exit Setup Save CMOS value setting to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup. Use the Standard CMOS Setup option as follows: 1. Choose “Standard CMOS Features” from the main menu. The following screen appears: Phoenix - AwardBIOS CMOS Setup Utility Standard CMOS Features...
- Page 30 User’s manual CGA 80 , or EGA/VGA Halt On: Controls whether the system stops in case of an error detected during power up. Choose: All Errors (Default) No Errors All, But Keyboard All, But Diskette All, But Disk/Key 3. After you have finished with the Standard CMOS Features program, press the <ESC>...
- Page 31 User’s manual 2. Use the arrow keys to move between items and to select values. Modify the selected fields using the PgUP/PgDN keys. Press the <F1> “Help” key for information on the available options: Virus Warning: When enabled, any attempt to write to the boot sector and partition table will halt the system and cause a warning message to appear.
- Page 32 User’s manual By default, the BIOS attempts to first boot from drive A: and then , if unsuccessful, from derive C: You can change this sequence from Floppy, LS/ZIP,HDD-0~3,SCSI ,CDROM, Disable, LAN. Boot Other Device: Enabled: select your boot device priority function. Disabled : Disabled this function .
- Page 33 User’s manual HDD S.M.A.R.T. : Enabled :Enable HDD S.M.A.R.T. Capability. Disabled :Disable HDD S.M.A.R.T. Capability. Report No FDD For WIN 95 : Enable this item for NSTL testing only, it will report no FDD for windows 95 when the floppy disk is not installed . Video BIOS Shadow: When enabled, the ROM BIOS on the video display card is copied into system DRAM to enhance performance.
- Page 34 User’s manual Phoenix - AwardBIOS CMOS Setup Utility Advanced Chipset Features SDRAM CAS Latency Time SDRAM Cycle Time Tras/Trc SDRAM RAS-to-CAS Delay Item Help SDRAM RAS Precharge Time System BIOS Cacheable Enabled Menu Level Video BIOS Cacheable Enabled Memory Hole At 15M-16M Disable CPU Latency Timer Disabled...
- Page 35 User’s manual Normally, these areas are reserved for memory – mapped I/O cards. CPU Latency Timer: Configuration options: Enable or Disable Delayed Transaction: Choose: Enabled / Disabled if you have an ISA card compatibility problem. When enabled, this option lets you control the Delayed Transaction function of the chipset. This function is used to meet the latency of the PCI cycle to or from the ISA bus .
- Page 36 User’s manual Use the Integrated Peripherals Setup option as follows: 1. Choose “Integrated Peripherals Setup” from the main menu. The following screen appears: Phoenix - AwardBIOS CMOS Setup Utility Integrated Peripherals On-Chip Primary Enabled On-Chip Secondary PCI Enabled Item Help IDE Primary Master PIO AUTO IDE Primary Slave...
- Page 37 User’s manual Auto :BIOS will automatically detect the Primary Slave PIO IDE Accessing mode. Mode 0 ~ 4 :Manually set the IDE Accessing mode. IDE secondary Master PIO: Auto :BIOS will automatically detect the second Master PIO IDE Accessing mode. Mode 0 ~ 4 :Manually set the IDE Accessing mode.
- Page 38 User’s manual AC97 Audio : Enabled : Enable AC97 Audio. Disabled : Disable AC97 Audio Auto : Set AC97 Audio to AUTO IDE HDD Block Mode: Enabled : Enable IDE HDD Block Mode Disabled :Disable IDE HDD Block Mode. Onboard Serial Port 1 : Auto: BIOS will automatically setup the port 1 address.
- Page 39 User’s manual The Power Management Setup controls the board’s “green” features. To save energy these features shut down the video display and hard disk drive. Use the Power Management Setup option as follows: 1. Choose “Power Management Setup” from the main menu. The following screen appears.
-
Page 40: Pnp/Pci Configuration
User’s manual V/H SYNC+Blank :This selection will cause the system to turn off the vertical and horizontal synchronization ports and writes blank to the video buffer. Blank screen :This option only writes blank to the video buffer. If you don’t have a “ “green monitor”... - Page 41 User’s manual Phoenix - AwardBIOS CMOS Setup Utility PnP/PCI Configurations Item Help PNP OS Installed <No> Menu Level Menu Level Reset Configuration Date <Disabled> Select Yes if you are Resources Controlled By <Audo(ESCD)> using a Plug and Play IRQ Resources Press Enter capable operating DMA Resources...
-
Page 42: Pc Health Status
User’s manual any PCI slot . Memory Resource: N/A: Disable the MEM .Block using . C800 ~ dc00:Select the MEM.Block starting address. PPCI/VGA Palette Snoop: Enable :For having Video Card on ISA Bus and VGA Card on PCI Bus . Disable:For VGA Card only. -
Page 43: Frequency/Voltage Control
User’s manual Displays the running speeds of FAN1 and FAN2,respectively. If “0” appears, the fan is either defective , not connected ,or does not meet standard specification. Voltage Indicators: Displays voltage values detected by the Winbond W83627HF system monitor IC. After you have finished with the CPU Features Setup, press the <ESC>... - Page 44 User’s manual settings do not affect the Standard CMOS Setup screen. To use this feature, highlight it on the main screen and press <Enter>. A line will appear on the screen asking if you want to load the Optimized Default Values. Press the <Y>...
-
Page 45: System Driver Installation
User’s manual Chapter 4. Driver Utility The system driver installation procedure must be performed first. 4.1 System Driver Installation 1. Insert the AW-EM650 CD-ROM driver into the CD-ROM Drive 2. Select the Drivers/system file to click the Setup icon. 3. Click Next 4. - Page 46 User’s manual 5. Click Next AW-EM650...
-
Page 47: Vga Driver Installation
User’s manual 6. Click Finish Installation process is completed and allowed the system to reboot. 4.2 VGA Driver Installation 1. Install the AW-EM650 CD ROM into the CD-ROM Drive 2. Select the Drivers/vga/9x file to click the Setup icon A driver installation screen will appear, please follow the onscreen instruction to install the driver in sequence 3.Click Next AW-EM650... - Page 48 User’s manual 4. Click Yes AW-EM650...
-
Page 49: Ethernet Driver Installation
User’s manual 3. Click Finish Installation process is completed and allowed the system to reboot 4.3 Ethernet Driver Installation The AW-EM650 supports four Ethernet Controller by using Intel® 82559 or Realtek® 8139C+ Chipset. 4.3.1 Intel® 82559 Ethernet Installation Installation for Windows95/98 Please install Ethernet drivers as follows: AW-EM650... - Page 50 User’s manual 1. Click “Start”, go to “Setting” and click “Control Panel”. Choose the “Add New Hardware” icon and double-click the icon, the next configuration screen will appear. 2. “Add New Hardware Wizard” shown this wizard installs the software for a new hardware device.
- Page 51 User’s manual 4. Please select the device that you want to install, and then click “Next>” to the next step of installation. 5. This is Update Device Driver Wizard. This device is already installed, but it has a problem. To view properties for the device, and to see the problem and proposed solution, please click “Finish”...
- Page 52 User’s manual 7. This Wizard searches for update drivers for: PCI Ethernet Controller A device driver is a software program that makes a hardware device work. Updating to a newer version of a device driver may improve the performance of your hardware device or add functionality, please click “Next>”...
- Page 53 User’s manual 10. This is to show the “Folders”, please click “OK” to the next step of installation. 11. This is Install from Disk. Please insert the manufacturer’s installation disk into the drive selected, and then please click “OK” to next step of installation. 12.
- Page 54 User’s manual 13. This is Update Driver Wizard. Windows is now ready to install the selected driver for this device. Please click Back to select a different driver, or click Next to continue. 14. This screen shown Windows has finished installing the driver you selected for your hardware device.
- Page 55 User’s manual 5. Select the Systems icon to open the System Properties box 6. Click the Device Manager tab 7. Select the Network Adapters item Another file will appear below this file, and then click on the file 8. Click the Driver Tab 9.
- Page 56 User’s manual 10. Click Next 11. Select CD ROM Drive, D/Drivers/lan/Win98, and click Next Notice: We take the LAN installation under Win98 for example only; please choose the file depending on your Windows OS. AW-EM650...
- Page 57 User’s manual 12. Select “Next” 13. Select “Next” AW-EM650...
- Page 58 User’s manual 14. Select “Next” 15. Click “Next” AW-EM650...
- Page 59 User’s manual 16. Click Finish Installation process is completed shutdown the computer and will allow the system to reboot AW-EM650...
-
Page 60: Ac'97 Audio Driver
User’s manual 4.3.3 AC’97 Audio Driver Insert the Drivers and Utilities CD into the CD ROM drive Click Next AW-EM650... - Page 61 User’s manual 2 Click Yes AW-EM650...
-
Page 62: Appendix A. System Resources
User’s manual Installation process is completed and allowed the system to reboot. Appendix A :System Resource Interrupt Controller The AW-EM650 is a fully PC compatible control board, it consists of 16 ISA interrupt request lines and most of them already in used by other part of the board.. System IRQs are available to cards installed in the ISA expansion Bus first. - Page 63 User’s manual Channel Assignment DMA0 Available fir PCI and ISA Slot DMA1 Available for PCI And ISA Slot DMA2 Floppy Disk Controller DMA3 Available for PCI and ISA Slot DMA4 Cascade DMA5 Available for PCI and ISA Slot DMA6 Available for PCI and ISA Slot DMA7 Available for PCI and ISA Slot Memory Map...
- Page 64 User’s manual I/O Map The addresses shown in the table are typical locations. I/O Port Assignment 0 ~ F AT DMA Controller 20 ~ 21 AT Interrupt Controller 40 ~ 43 82C54 Compatible Programmable Timer 8042 Compatible keyboard Controller AT Style Speaker 8042 Compatible keyboard Controller 70 ~ 71 Real Time Clock...
-
Page 65: Appendix B. Optional Cable List
User’s manual Appendix B: Optional Cable List Part No. Cable Description AW-EM650 Terminating Connector Connector 46-I03IDE-00 IDE Cable CN18 2mm, 44-pin IDE Cable, 3cm 46-I00IDE-00 IDE Cable CN18 2mm, 44-pin Dual IDE Cable, 20cm 46-IPOW02-00 Power Cable CN19 3.96mm – 15CM 46-IAUD02-00 Audio Cable 2mm, Audio Cable, 15cm 46-ICOM3B-00 I/IO Cable...
