- Page 1 Intel Pemtium M- 5.25” Embedded Single Board Computer With VGA/LCD, LAN, AUDIO, TV-OUT, DVI Interface User’s Manual Version 1.1...
- Page 2 User’s manual © C o p y r i g h t 2 0 0 2 . A l l R i g h ts R e s e r v e d M a n u a l e d i t i o n 1 . 0 , J a n . 2 0 0 2 T h is doc umen t c on ta ins pr opr ie tar y in forma tion protec ted b y co p yr igh t.
-
Page 3: Table Of Contents
User’s manual Table of Contents Chapter 1. General information……………………………………….4 Introduction-----------------------------------------------------------------4 1.2 Specification---------------------------------------------------------------------------------4 1.3 Board Layout……………………………………………………………………..6 1.5 Board Dimension---------------------------------------------------------------------------6 Chapter 2. Connectors/Jumpers Location and Define ………….8 2.1 Connectors/Jumpers Location and Define---------------------------------------------8 2.2 Jumpers Location and Define -------------------- ---------------------------------------9 2.3 Connectors Pin Define --------------------------------------------------------------------10 CN1:CPU FAN Connector --------------------------------------------------------------------10 CN2:TV-Out Connector-----------------------------------------------------------------------11 CN3:DVI Connector----------------------------------------------------------------------------11... - Page 4 User’s manual 2.4 Jumper Setting ----------------------------------------------------------------------------24 JP1:TV Video Output Format Selection -------------------------------------------------24 JP3:Clear CMOS------------------------------------------------------------------------------24 JP4:LVDS Panel Power Selection ………………………………………………… 25 JP5:FSB Clock Selection ……………………………………………………………25 JP6:COM4/4 RI Pin Function Selection(RI/+5V/+12V) ………………………….25 JP7/JP8/JP9:COM2 RS232/422/486 Model Selection ……………………………26 Chapter 3. BIOS SETUP--------------------------------------------------------------------29 3.1 Quick Setup--------------------------------------------------------------------------------29 3.2 Entering the CMOS Setup Program-------------------------------------------------29 3.3 Menu Options-----------------------------------------------------------------------------31 Standard CMOS Features-------------------------------------------------------------------32...
-
Page 5: Chapter 1. General Information
User’s manual Chapter 1. General Information 1.1 Introduction T h e AW- E M 7 5 1 i s a 5 . 2 5 ” e m b e d d e d s i n g l e b o a r d u s e I n t e l 8 2 8 5 5 G M ( E ) a n d I C H 4 c h i ps e t s u p p o r ts I n t e l ®... - Page 6 User’s manual Support software selectable timeout interval Watchdog Timer Built in W83627HF-AW; supports temperatures, Fan speed, and System Monitoring voltages monitoring One 32-bit PCI expansion slot support two bus mater. PCI slot Support four TTL input and four output pins for customized purpose Digital I/O Power management Support ACPI 2.0, Wake on LAN and Modem Ring-in functions...
-
Page 7: Board Layout
User’s manual Max. power requirements 3.9A@18V 32-140ºF (0-60℃) Operating Temperature Board size 8"(L) x 5.75"(W)(203mm x 146mm) 1.3 Board Layout 1.4 Board Dimension Top Side AW-EM751... - Page 8 User’s manual Bottom Side AW-EM751...
-
Page 9: Chapter 2. Connectors/Jumpers Location And Define
User’s manual Chapter 2. Connectors/Jumpers Location and Define 2.1 Connectors/Jumpers Location and Define Top Side- Connector Define Connectors Define CPU FAN Connector CN14 DC Power Connector TV-Out Connector CN15 System Fan1 Connector DVI Connector CN16 IDE Connector CRT Connector CN17 Audio In/Out Connector LVDS CH1 Connector CN18... -
Page 10: Jumpers Location And Define
User’s manual CN12 IDE Power Connector CN25 Front Panel Connector CN13 IRDA Connector CN26 GPIO Ports Connector Bottom Side- Connector Define Connectors Define CN27 Compact Flash Socket 2.2 Jumpers Location and Define AW-EM751... -
Page 11: Connectors Pin Define
User’s manual Label Define TV Video Output Format Selection ( NTSC/PAL) Clear CMOS LVDS Panel Power Selection System Bus Clock Selection COM3/4 RI/+5V/+12V Selection COM2 RS232/422/485 Mode Selection-1 COM2 RS232/422/485 Mode Selection-2 COM2 RS232/422/485 Mode Selection-3 2.3 Connectors Pin define CN1: CPU FAN Connector AW-EM751... -
Page 12: Cn2:Tv-Out Connector
User’s manual Define Ground +12V Speed Detect CN2: TV-Out Connector Define LUMINANCE OUT CROMIANCE OUT Ground Ground COMPOSITE OUT CN3: DVI Connector Define Define Ground Ground TX2N TX0N TX2P TX0P Ground Ground TXCN DATA TXCP Ground Ground TX1N CHARGE TX1P Ground AW-EM751... -
Page 13: Cn4:Vga Connector
User’s manual CN4: VGA Connector Define Define Green Blue Signal Ground Chassis Ground Chassis Ground Chassis Ground Signal Ground DDC Data H-SYNC V-SYNC DDC Clock CN5: LVDS Channel 1 Connector Define Define Ground Ground RXO0-/RXIN0- RXO0+/RXIN0+ Ground RXO1-/RXIN1- RXO1+/RXIN1+ Ground RXO2-/RXIN2- RXO2+/RXIN2+ Ground... -
Page 14: Cn7:Lvds Panel Backling Enable Control Connector
User’s manual Define Define RXE0- RXE0+ Ground RXE1- RXE1+ Ground RXE2- RXE2+ RXEC- RXEC+ RXE3- RXE3+ Ground Ground Ground CN7: LVDS Panel Backlight Enable Control Connector Define +12V Ground Ground SMBUS Clock Backlight Enable CN8: System FAN2 Connector AW-EM751... -
Page 15: Cn9:Usb Port 3/4 Connector
User’s manual Define Ground +12V Fan Speed Detect CN9: USB Port 3/4 Connector Define Define USB VCC USB VCC USB D3- USB D4- USB D3+ USB D4+ Ground Ground Ground CN11: USB1/2 Connector Define Define USB VCC USB VCC USB D1- USB D2- USB D1+ USB D2+... -
Page 16: Cn12:Ide Power Connector
User’s manual CN12: IDE Power Connector Define +12V Ground Ground CN13: IRDA Power Connector Define IRRX Ground IRTX CN14: DC-IN Power Connector AW-EM751... -
Page 17: Cn15:System Fan 1 Connector
User’s manual Define +DC Input (12~25V) Ground CN15: System FAN1 Connector Define Ground +12V Fan Speed Detect CN17: Audio Input/Output Connector Define Define Line-In(R)/Surround(R) Ground Line-In(L)/Surround(L) NC/LFE-OUT Ground MIC-In/Cent-Out Speaker-Out(R) Ground Speaker-Out(L) CN16: IDE Connector AW-EM751... -
Page 18: Cn18:Floppy Drive Connector
User’s manual Define Define RESET* Ground DATA7 DATA8 DATA6 DATA9 DATA5 DATA10 DATA4 DATA11 DATA3 DATA12 DATA2 DATA13 DATA1 DATA14 DATA0 DATA15 Ground KEY PIN DREQ Ground DIOW* Ground DIOR* Ground IOCHRDY CSEL DACK* Ground IRQ14 DETECT HD SELECT 0* HD SELECT 1* ACTIVE* Ground... -
Page 19: Cn20:Parallel Port Connector
User’s manual Define Define Ground 2 DENSITY SELECT0* Ground Ground 6 DENSITY SELECT1* Ground INDEX* Ground 10 MOTOR ENABLE 0* Ground DRIVE SELECT 1* Ground DRIVE SELECT 0* Ground 16 MOTOR ENABLE 1* Ground DIRECTION* Ground STEP* Ground WRITE DATA* Ground WRITE GATE* Ground... -
Page 20: Cn19:Aux-In Connector
User’s manual Define Define STROBE AFD# ERR# INIT# SLIN# Ground Ground Ground Ground Ground ACK# Ground BUSY Ground Ground SLCT CN19: Aux-In Connector AW-EM751... -
Page 21: Cn21:Cd Analog -In Connector
User’s manual Define Aux-In ( L ) Ground Ground Aux-In ( R ) CN21: CD Analog-In Connector Define CD-In ( L ) Ground Ground CD-In ( R ) CN22: COM Port 1-4 Connector AW-EM751... - Page 22 User’s manual RS232 Mode Define Define DCD#1 DSR#1 RXD1 RTS#1 TXD1 CTS#1 DTR#1 RI#1 Ground DCD#2 DSR#2 RXD2 RTS#2 TXD2 CTS#2 DTR#2 RI#2 Ground DCD#3 DSR#3 RXD3 RTS#3 TXD3 CTS#3 DTR#3 RI#3 Ground AW-EM751...
-
Page 23: Cn23:Lan Connector
User’s manual DCD#4 DSR#4 RXD4 RTS#4 TXD4 CTS#4 DTR#4 RI#4 Ground RS422 Mode(COM2) RTS- RTS+ CTS+ CTS- Ground RS485 Mode(Half-Duplex)(COM2) TX-/RX- TX+/RX+ Ground RS485 Mode(Four-Wire)(COM2) Ground CN23: LAN Connector AW-EM751... -
Page 24: Cn24:Ps/2 Keyboard/Mouse Connector
User’s manual Define Define MDI0+ Ground MDI0- LINK100# MDI1+ MDI1- LINK1000# MDI2+ LINK_UP# MDI2- ACT# MDI3+ MDI3- Ground CN24: PS2 Keboard/Mouse Connector Define Define KB-Clock Mouse-Clock KB-Data Mouse-Data Ground Ground CN25: Front Panel Connector Define Define Power LED+(+5V) Power LED-(Ground) IDE LED+(+5V) IDE LED-(Active) Power On Switch+... -
Page 25: Cn26:Gpio Port Connector
User’s manual (Ground) Reset Switch- Reset Switch+ (Ground) CN26: GPIO Port Connector Define Define GPIN0 GPIN1 GPIN2 GPIN3 Ground +3.3V GPOUT0 GPOUT1 GPOUT2 GPOUT3 Ground 2.4 Jumper Setting JP1: TV Video Output Format Selection Setting Define NTSC (Default) JP3: Clear CMOS AW-EM751... -
Page 26: Jp4:Lvds Panel Power Selection
User’s manual Setting Define Normal (Default) Clear CMOS JP4: LVDS Panel Power Selection Setting Define +3.3V (Default) JP5: FSB Clock Selection Setting Define 133MHz 100MHz JP6: COM3/4 RI Pin Function Selection.(RI/+5V/+12V) AW-EM751... -
Page 27: Jp7/Jp8/Jp9:Com2 Rs232/422/486 Model Selection
User’s manual Setting Define COM3 COM4 Setting Define COM3 9-10 COM4 Setting Define COM3 +12V 11-12 COM4 +12V JP7,JP8,JP9 : COM2 RS232/422/485 Mode selection RS232 Mode 9-11 10-12 15-17 16-18 21-23 22-24 27-29 28-30 AW-EM751... - Page 28 User’s manual Not Stuff Not Stuff RS422 Mode 8-10 13-15 14-16 19-21 20-22 25-27 26-28 31-32 33-34 RS485 Mode(Half-Duplex) 8-10 31-32 33-34 AW-EM751...
- Page 29 User’s manual RS422 Mode(4-Wire) 8-10 13-15 14-16 33-34 AW-EM751...
-
Page 30: Chapter 3. Bios Setup
User’s manual Chapter 3. BIOS Setup The ROM chip of your AW-EM751board is configured with a customized Basic Input/Output System (BIOS) from Phoenix-Award BIOS. The BIOS is a set of permanently recorded program routines that give the system its fundamental operational characteristics. - Page 31 User’s manual 1. Received an error code at startup 2. Install another disk drive 3. Use your system after not having used it for a long time 4. Find the original setup missing 5. Replace the battery 6. Change to a different type of CPU 7.
-
Page 32: Menu Options
User’s manual the program. Pressing <ESC> anywhere in the program returns you to the main menu. 3.3 Menu Options The main menu options of the CMOS Setup program are described in the following and the following sections of this chapter. Option Function Standard CMOS Features... -
Page 33: Standard Cmos Features
User’s manual Phoenix - Award BIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) Tue, Oct 22 2003 Time (hh:mm:ss) 16 : 53 : 10 Item Help IDE Primary Master <NONE> IDE Primary Slave <NONE> Menu Level IDE Secondary Master <NONE> Change the day, month, IDE Secondary Slave <NONE>... - Page 34 User’s manual Select this field to type of floppy disk drive installation in your system, the choices are: None; 360K, 5.25 in; 1.2M, 5.25 in; 720K, 3.5 in; 1.44MB, 3.5 in; 2.88M, 3.5 in Video: Choose: MONO, CGA 40, CGA 80 or EGA/VGA Mono: Monochrome Adapter, includes high resolution monchrome adapter CGA40: Color Graphics Adapter, power up in 40 column mode CGA80: Color Graphics Adapter, power up in 80 column mode...
-
Page 35: Advanced Bios Features
User’s manual 1. Choose “BIOS Features Setup” from the main menu. The following screen appears: Phoenix - Award BIOS CMOS Setup Utility Advanced BIOS Features CPU Feature <Press Enter> First Boot Device <Floppy> Item Help Second Boot Device <HDD-0> Third Boot Device <LS120>... -
Page 36: Advanced Chipset Features
User’s manual OS2 :Using OS2 operating system and RAM > 64MB Small Logo (EPA) Show: Advanced Chipset Features Setup Use the Advanced Chipset Feature Setup option as follows: 1. Choose “Advanced Chipset Features Setup” from the main menu. The following screen appears: Phoenix - Award BIOS CMOS Setup Utility Advanced Chipset Features... -
Page 37: Integrated Peripherals
User’s manual The On-Chip Frame Buffer Size can be set as 1MB or 8MB. This memory is shared with the system memory. Boot Display: Boot Display determines the display output device where the system boots. The options are Auto, CRT and LVDS 3. - Page 38 User’s manual Phoenix - Award BIOS CMOS Setup Utility OnChip IDE Device On-Chip Primary PCI IDE <Enabled> IDE Primary Master PIO <Auto> Item Help IDE Primary Slave PIO <Auto> IDE Primary Master UDMA <Auto> Menu Level IDE Primary Slave UDMA <Auto>...
- Page 39 User’s manual Onboard Device: Select this item to setup the onboard device features. When you select this item, the following menu shows: Phoenix - Award BIOS CMOS Setup Utility Onboard Device USB Controller <Enabled> USB 2.0 Controller <Enabled> Item Help USB Keyboard Support <Disabled>...
-
Page 40: Ir Transmission Delay
User’s manual SuperIO Device: Select this item to setup the SuperIO Device features. When you select this item, the following menu shows: Phoenix - Award BIOS CMOS Setup Utility SuperIODevice Onboard FDC Controller <Enabled> Onboard Serial Port 1 <3F8/IRQ4> Item Help Onboard Serial Port 2 <2F8/IRQ3>... -
Page 41: Power Management Setup
User’s manual UR2 Duplex Mode: In an Infrared port mode, this field appears. Full-duplex mode permits simultaneous two-direction transmission. Half-duplex mode permits transmission in one direction only at a time. Select the value required by the IR device connected to the IR port. Onboard Parallel Port: This feature allows you to select the I/O address and IRQ for the onboard parallel port. - Page 42 User’s manual Phoenix - Award BIOS CMOS Setup Utility Power Management Setup ACPI Function <Disabled> ACPI Suspend Type <S3(STR)> Item Help Run VGA BIOS if S3 Resume <Auto> Power Management <User Define> Menu Level Video Off Method <DPMS> Video Off Suspend <Yes>...
- Page 43 User’s manual This determines the manner in which the monitor is blanked. There are three choices: V/H SYNC+Blank: This selection will cause the system to turn off the vertical and horizontal synchronization port and write blanks to the video buffer. Blank Screen: This option only writes blanks to the video buffer.
-
Page 44: Pnp/Pci Configuration
User’s manual Wake Up On LAN: USB KB Wake-Up From S3: Resume by Alarm: 3. After you have finished with the Power Management Setup, press the <ESC> key to return to the main menu. PNP/PCI Configuration This setup is used to configure Plug “n” Play IRQ assignments and route PCI interrupts to designated ISA interrupts. -
Page 45: Pc Health Status
User’s manual Resources Controlled By: The Award Plug and Play BIOS has the capacity to automatically configure all of the boots and Plus and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as going into each of the submenus that follows this field. -
Page 46: Load Fail-Safe Default
User’s manual Current CPU Temp: Displays the current Socket 370 temp. Fan1,Fan2,Speed Displays the running speeds of FAN1 and FAN2,respectively. If “0” appears, the fan is either defective , not connected ,or does not meet standard specification. Voltage Indicators: Displays voltage values detected by the Winbond W83627HF system monitor IC. 3. - Page 47 User’s manual To use this feature, highlight it on the main screen and press <Enter>. A line will appear on the screen asking if you want to load the Optimized Default Values. Press the <Y> key and then press <Enter> if you want to load the SETUP default. Phoenix - AwardBIOS CMOS Setup Utilities Standard CMOS Features Load Fail-Safe Default...
- Page 48 User’s manual Phoenix - AwardBIOS CMOS Setup Utilities Standard CMOS Features Load Fail-Safe Default Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Supervisor Password Integrated Pheripherals Set Password Power Management Setup Save and Exit Setup Set User Password (Y/N)? Y PnP/PCI Configuration Exit Without Saving PC Health Status...
- Page 49 User’s manual Phoenix - AwardBIOS CMOS Setup Utilities Standard CMOS Features Load Fail-Safe Default Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Supervisor Password Integrated Pheripherals Set Password Power Management Setup Save and Exit Setup Exit Without Saving (Y/N)? Y PnP/PCI Configuration Exit Without Saving PC Health Status...
-
Page 50: Chapter 4. Drivers And Utilities
User’s manual Chapter 4. Driver Utility The system driver installation procedure must be performed first. 4.1 System Driver Installation AW-EM751... - Page 51 User’s manual AW-EM751...
-
Page 52: Video Driver Installation
User’s manual 4.2 Install Video Driver: AW-EM751... - Page 53 User’s manual AW-EM751...
-
Page 54: Lan Driver Installation
User’s manual 4.3 Install LAN Drivers: AW-EM751... - Page 55 User’s manual AW-EM751...
- Page 56 User’s manual AW-EM751...
- Page 57 User’s manual AW-EM751...
-
Page 58: Audio Driver Installation
User’s manual 4.4 Install Audio Drivers: AW-EM751... - Page 59 User’s manual AW-EM751...
-
Page 60: Appendix A. System Resources
User’s manual Installation process is completed and allowed the system to reboot. 4.5 Appendix A: System Resource Interrupt Controller The AW-EM751 is a fully PC compatible control board, it consists of 16 ISA interrupt request lines and most of them already in used by other part of the board. Please make sure that the IRQs do not conflict if you would like to use extra add-on cards. - Page 61 User’s manual System IRQs are available to cards installed in the ISA expansion Bus first. Any remaining IRQs then may be assigned to this PCI Bus. You are able to use the Microsoft’s Diagnostic(MSD.EXE) utility include in Windows director to see their map. Assignment IRQ0 System Timer Output...
- Page 62 User’s manual Memory below 1MB (1Mb ~ 640KB) Address Range Type Owner A0000~AFFFF VGA Adapter B0000~BFFFF VGA Adapter C0000~CD1FF Adapter ROM F0000~FFFFF System BIOS Memory above 1MB (1MB ~ 189408KB) Address Range Type Owner D0000000~D7FFFFF7 PCI VGA Adapter D8000000~DFFFFFF7 PCI Display Adapter E0000000~E00FFFFF PCI PCI-PCI Bridge...
-
Page 63: Appendix B. Cable List
User’s manual 70 ~ 71 Real Time Clock 81 ~ 83 AT DMA Controller AT DMA Controller 89 ~ 8B AT DMA Controller 8F ~ 91 AT DMA Controller A0 ~ A1 AT Interrupt Controller C0 ~ DF AT DMA Controller F0 ~ FF Math Coprocessor 170 ~ 177... -
Page 64: Appendix C. Optional Peripherals
User’s manual Part Number Cable Description AW-EM751 Terminating Connector Connector 46-IVGA01-00 CRT VGA Cable 2mm 15-pin Female D-Sub, 20cm 46-IUSB01-00 USB Port Cable CN11/CN3 Two-channels USB Cable(pin1 block),25cm 46-IATA66-00 IDE Cable CN16 IDE Cable 46-IPW422-00 IDE Power Cable CN12 IDE Power Cable 46-IFDC02-00 FDC Cable CN18... - Page 65 User’s manual AW-R014 Audio Kit CN17 Audio Kit w/46-I10IDE-00 Cable AW-R015 DVI Kit DVI Kit w/46-DVI000-00 Cable AW-R016 TV-Out Kit TV-Out Kit w/46-TV0002-00 Cable AW-EM751...
