AW-C661 Socket-370 5.25" Embedded
SBC
STARTUP MANUAL
Specifications
General Functions
CPU: Intel®socket 370Celeron™/
Pentium®III/Tualatin & VIA C3
processor up to 100MHz FSB
BIOS: Award®256KB Flash BIOS
Cache: 128/256KB on-chip cache
Chipset: Intel®440BX+82371EB
I/O Chipset: Two Winbond
w83977EF-AW
Memory: Two 144-pin SO-DIMM
socket up to 512MB
Enhanced IDE: Up to two IDE
devices (UDMA 33)
FDD interface: Supports one 34-pin
header
Parallel port: Supports
SPP/ECP/EPP
Serial port: Three RS-232 and one
RS-232/422/485 serial ports
IR interface: Supports one IrDA
Tx/Rx header
KB/Mouse connector: Supports PS/2
keyboard and mouse
USB connectors: Supports two USB
ports
Battery: Lithium battery for data
retention up to 10 years
Watchdog Timer: Supports software
selectable timeout interval
System Monitoring: Software
programmable
PC/104 connector: One PC/104
QUICK SETUP C661
connector
PCI slot: One 32-bit PCI slot
Digital I/O: Supports eight TTL
input and output pins
SMBus connector: Supports SMBus
LCD interface
Power management: Supports ATX
power supply, PC97, LAN wake up,
and modem ring-in functions
Flat Panel/CRT Interface
Chipset: SMI Lynx3DM
Display memory: Built-in
4MB/8MB for Lynx3DM SMI721
Display type: Supports CRT and
LCD displays
Resolution: Supports up to
1024 x 768 16M colors and CRT
monitors up to 1280 x 1024 16M
colors
TV-Out Interface (option)
TV Format: Supports NTSC,
NTSC-EIA (Japan) and PAL signals
format
Output connector: Supports RCA
(Composite) video and S-video
connector
Resolution: Supports 640 x 480 and
800 x 600 resolutions
Ethernet Interface
Chipset: Three Intel® 82559ER or
Realtek RTL8139C (option)
Ethernet interface: PCI 100/10MB
Ethernet controller
SSD Interface
One 50-pin CompactFlash™ socket
PCI Sound Interface
Chipset: ESS Solo-1
Audio controller: SoundBlaster and
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the AW-C661 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aewin AW-C661

  • Page 1 AW-C661 Socket-370 5.25” Embedded PCI slot: One 32-bit PCI slot Digital I/O: Supports eight TTL STARTUP MANUAL input and output pins SMBus connector: Supports SMBus LCD interface Specifications Power management: Supports ATX General Functions CPU: Intel®socket 370Celeron™/ power supply, PC97, LAN wake up, Pentium®III/Tualatin &...
  • Page 2 (203mm x 146mm) sales representatives immediately. Weight: 0.6lb. (0.3Kg) (bare) Note: For detailed contents of the For more information on AW-C661 or AW-C661, please refer to the enclosed Aewin products, please visit our website CD-ROM http://www.aewin.com.tw...
  • Page 3 AW-C661 Board Dimension Component Side Solder Side QUICK SETUP C661 - 3 -...
  • Page 4 AW-C661 Board Layout AW-C661 Location of Connectors QUICK SETUP C661 - 4 -...
  • Page 5 List of Connectors Connectors Description Connectors Description Speaker Connector CN16 PS/2 Mouse/KB Connector -5V/-12V Power CN17 USB Connector Connector ATX Power Control CN18 PC/104 Connector Connector SMBus Connector CN19 TV-Out Connector Front Panel Connector CN20 GPIO Connector LAN LEDs CN21 Notebook Type FDD Connector LAN1 Connector...
  • Page 6 CN5: Front Panel Connector CN28: Isolated Digital I/O Connector Signal ISO_OUT0 Signal ISO_OUT1 Ground +12V Ground IDEACT Reset Ground PANSWIN Ground CN20: GPIO Connector Signal GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 Ground QUICK SETUP C661 - 6 -...
  • Page 7 CN25, 26: Flat Panel Connector CN25: DF13A-40DP-1.25V CN26: DF13A-40DP-1.25V Signal Signal Signal Signal VDDSAFE5 VDDSAFE5 VDDSAFE5 VDDSAFE5 Ground Ground Ground Ground VDDSAFE3 VDDSAFE3 VDDSAFE3 VDDSAFE3 Ground Ground 9 LCD_FD24 10 LCD_FD25 LCD_FD0 LCD_FD1 11 LCD_FD26 12 LCD_FD27 LCD_FD2 LCD_FD3 13 LCD_FD28 14 LCD_FD29 LCD_FD4 LCD_FD5...
  • Page 8 Location of Jumpers List of Jumpers Jumper Signal Jumper Signal Watch Dog Timer Action Select COM2 RS-232/422/485 Select COM3/COM4 RI/Voltage Select Clear CMOS Panel Type Select COM1/COM2 RI/Voltage Select JP1: COM2 RS-232/422/485 Selector (Default: RS-232) Setting COM Port 5-6, 9-11, 10-12, 15-17, RS-232 (Default) 16-18 3-4, 7-9, 8-10, 13-15, 14-16 RS-422...
  • Page 9 JP2: COM3/COM4 RI/Voltage Selector Pin Setting COM Port RI/Voltage 11-12 COM4 +12V 9-10 COM4 COM4 RI (default) COM3 +12V COM3 COM3 RI (Default) JP3: COM1/COM2 RI/Voltage Selector Pin Setting COM Port RI/Voltage 11-12 COM2 +12V 9-10 COM2 COM2 RI (default) COM1 +12V COM1...
  • Page 10 SW1: Panel Type Select Setting Pin No. Resolution/Type 640 x 480 (18-bit) 640 x480 (16-bit) DSTN 800 x 600 (18-bit) 800 x 600 (16-bit) DSTN 1024 x 768 (18-bit) 1024 x 768 DSTN (24-bit) QUICK SETUP C661 - 10 -...
