Page 1
TRITON routing switcher Telecom Data Router 8x8 140/155 Mbps Product model no. TTN-BTS-0808/140 INSTALLATION MANUAL MANUAL PART NO. 071-8238-00 Rev. 1 March 19, 2003 the most watched worldwide...
Page 2
FRANCE Nevada City, CA 95959-7900 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
Contents Electromagnetic Radiation Notice Hardware Warranty and Software License Parts and Service Revision history General 1.1. Specifications 1.2. Connection drawing Power connection Connecting the BTS-0808/140 to your PC Selection of router level Pin-out of RS-232 connector Maximum cable length NCB connection Several routers in one system Connecting control panels Pin-out and cable type...
Page 4
7.2.2 Example: Several units connected by NCB RS232 Commands 7.5.1 Audio crosspoint set 7.5.2 Audio crosspoint set acknowledge 7.5.3 Video crosspoint set 7.5.4 Video crosspoint set acknowledge 7.5.5 Crosspoint status request...
88 - 216 216 - 1000 The policy of Thomson is one of continual development and improvement. For that reason Thomson uses components and manufacturing techniques that provide the current state-of-the-art suppression of electromagnetic radiation. This equipment, in production before October 1, 1981, has not been tested to the above listed measurements. However, equipment such as this delivered after October 1, 1983 will have the measurements on record at the factory.
Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you.
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 19/03/03 Updated with new Thomson/GVG design. 22/10/01 Initial Revision...
BTS-0808/140 Rev. 1 1 General The BTS-0808/140 is a 8x8 telecom router for 140Mbit/s and 155Mbit/s data rate. The BTS- 0808/140 meets ITU-T G.703 for CMI coded signals. This state of the art router provides maximum quality with a data rate of up to 360Mbit/s and automatic cable equalizing on all inputs. High performance circuits in SMD technology assure undiminished signal quality.
BTS-0808/140 can also be delivered with DC ±5V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information.
Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router.
BTS-0808/140 Rev. 1 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data Pin 6 = Not Connected...
BTS-0808/140 Rev. 1 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45.
Page 14
BTS-0808/140 Rev. 1 o RS-422 Data + CP for data on Level 3 o Universal Control Panel to control all devices above, with user configurable default level. • Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. Triton - RCS •...
BTS-0808/140 Rev. 1 5 Router configuration Router level Switches 1 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router.
BTS-0808/140 Rev. 1 Power up mode Switch 8 on the configuration switch defines the power up mode. The BTS-0808/140 router provides two modes for powering up the system. Mode 1 switches all outputs to input 1. Mode 2 switches all outputs according to the buffered information in the routers processor system. The power up reset can be switched according to the following pattern: means switch down means switch up...
BTS-0808/140 Rev. 1 7 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 7.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters.
BTS-0808/140 Rev. 1 7.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB.
BTS-0808/140 Rev. 1 Commands 7.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
BTS-0808/140 Rev. 1 7.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
