- Page 1 TRITON routing switcher Telecom Data Router 8x8 34/45 Mbps Product model no. TTN-BTS-0808/34 INSTALLATION MANUAL MANUAL PART NO. 071-8239-00 Rev. 1 MARCH 19, 2003 the most watched worldwide...
- Page 2 FRANCE Nevada City, CA 95959-7900 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
-
Page 3: Table Of Contents
Contents Electromagnetic Radiation Notice Hardware Warranty and Software License Parts and Service Revision history General Specifications Connection drawing Power connection Power supply for RECL8 Connecting the BTS-0808/34 to your PC Selection of router level Pin-out of RS-232 connector Maximum cable length NCB connection Several routers in one system Connecting control panels... - Page 4 7.2.1 Example: A single unit with no NCB connected 7.2.2 Example: Several units connected by NCB RS232 Commands 7.5.1 Audio crosspoint set 7.5.2 Audio crosspoint set acknowledge 7.5.3 Video crosspoint set 7.5.4 Video crosspoint set acknowledge 7.5.5 Crosspoint status request...
-
Page 5: Electromagnetic Radiation Notice
88 - 216 216 - 1000 The policy of Thomson is one of continual development and improvement. For that reason Thomson uses components and manufacturing techniques that provide the current state-of-the-art suppression of electromagnetic radiation. This equipment, in production before October 1, 1981, has not been tested to the above listed measurements. However, equipment such as this delivered after October 1, 1983 will have the measurements on record at the factory. -
Page 6: Hardware Warranty And Software License
Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you. -
Page 7: Revision History
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 19/03/03 Updated with the new Thomson/GVG design. 22/10/01 Initial Revision... -
Page 9: General
BTS-0808/34 Rev. 1 1 General The BTS-0808/34 is an 8x8 telecom router for 34Mbit/s or 45Mbit/s data rate. BTS-0808/34 meets ITU-T G.703 for HDB3 coded signals. The BTS-0808/34 routing system consists of one broadband router (1RU) and one equalizing and re-clocking unit (1RU). This combination provides maximum signal quality with automatic cable equalizing and re-clocking of incoming signals. -
Page 10: Connection Drawing
BTS-0808/34 Rev. 1 Connection drawing Configuration switch Input section Router Output section Power connectors RS-232 port Output connections Network Control Bus. The protocol of this bus is equal, and compatible to the MIDI bus protocol. -
Page 11: Power Connection
BTS-0808/34 can also be delivered with DC ±5V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information. -
Page 12: Connecting The Bts-0808/34 To Your Pc
BTS-0808/34 Rev. 1 3 Connecting the BTS-0808/34 to your PC For connection to a PC with Triton Router Control System, the RS-232 interface is used. The RS-232 port on all Triton devices uses the standard DCE pin-out, see pin-out table under 4.3. A standard modem cable can be used for connecting the router to the PCs serial port. -
Page 13: Ncb Connection
Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router. -
Page 14: Pin-Out And Cable Type
BTS-0808/34 Rev. 1 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data Pin 6 = Not Connected... -
Page 15: Rj45 To 5-Pin Din Converter
BTS-0808/34 Rev. 1 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45. - Page 16 BTS-0808/34 Rev. 1 o SDI + AES/EBU + CP for digital system on Level 2 o RS-422 Data + CP for data on Level 3 o Universal Control Panel to control all devices above, with user configurable default level. • Pay attention to the figure below, in order to achieve full controllability of all devices in the loop.
-
Page 17: Router Configuration
BTS-0808/34 Rev. 1 5 Router configuration Router level Switches 1 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router. -
Page 18: Power Up Mode
BTS-0808/34 Rev. 1 Power up mode Switch 8 on the configuration switch defines the power up mode. The BTS-0808/34 router provides two modes for powering up the system. Mode 1 switches all outputs to input 1. Mode 2 switches all outputs according to the buffered information in the routers processor system. The power up reset can be switched according to the following pattern: means switch down means switch up... -
Page 19: Control And Connection Of Triton Systems, Interface Protocol
BTS-0808/34 Rev. 1 7 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 7.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters. -
Page 20: Example: Several Units Connected By Ncb
BTS-0808/34 Rev. 1 7.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB. -
Page 21: Commands
BTS-0808/34 Rev. 1 Commands 7.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 22: Video Crosspoint Set Acknowledge
BTS-0808/34 Rev. 1 7.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
