- Page 1 TRITON routing switcher Analog Video Router 64x64 Product model no. TTN-BVS-6464 INSTALLATION MANUAL MANUAL PART NO. 04-052907-004 Rev. 2 MARCH 14, 2003 the most watched worldwide...
- Page 2 FRANCE Nevada City, CA 95959-7900 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
-
Page 3: Table Of Contents
Contents Electromagnetic Radiation Notice Hardware Warranty and Software License Parts and Service Revision history General Specifications Connection drawing Power connection Connecting the BVS-6464 to your PC Selection of router level Pin-out of RS-232 connector Maximum cable length NCB connection Several routers in one system Connecting control panels Pin-out and cable type 4.3.1... - Page 4 7.2.2 Example: Several units connected by NCB RS232 Commands 7.5.1 Audio crosspoint set 7.5.2 Audio crosspoint set acknowledge 7.5.3 Video crosspoint set 7.5.4 Video crosspoint set acknowledge 7.5.5 Crosspoint status request...
-
Page 5: Electromagnetic Radiation Notice
88 - 216 216 - 1000 The policy of Thomson is one of continual development and improvement. For that reason Thomson uses components and manufacturing techniques that provide the current state-of-the-art suppression of electromagnetic radiation. This equipment, in production before October 1, 1981, has not been tested to the above listed measurements. However, equipment such as this delivered after October 1, 1983 will have the measurements on record at the factory. -
Page 6: Hardware Warranty And Software License
Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you. -
Page 7: Revision History
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 14/03/03 Updated with new Thomson/GVG design. 26/07/02 Corrected Chapter 2 (Power supply info). 29/08/01 Initial Revision... -
Page 9: General
BVS-6464 Rev. 2 1 General The BVS-6464 is a 64x64 video router with vertical interval switching. This state of the art router provides 125MHz video bandwidth. High performance circuits in SMD technology assure undiminished signal quality. The BVS-6464 is designed for all demanding routing tasks in digital studio and broadcast environments. -
Page 10: Connection Drawing
BVS-6464 Rev. 2 Connection drawing Configuration Video input section Video output section switches Vertical Interval Trigger RS-232 port Power connector Network Control Bus. The protocol of this bus is equal, and compatible to the MIDI bus protocol. -
Page 11: Power Connection
BVS-6464 can also be delivered with DC ±5V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information. -
Page 12: Ncb Connection
Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router. -
Page 13: Pin-Out And Cable Type
BVS-6464 Rev. 2 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data Pin 6 = Not Connected... -
Page 14: Rj45 To 5-Pin Din Converter
BVS-6464 Rev. 2 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45. - Page 15 BVS-6464 Rev. 2 o Universal Control Panel to control all devices above, with user configurable default level. Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. • Triton - RCS Complete the Control loop, by connecting all Control bus connections to all Triton devices, before •...
-
Page 16: Router Configuration
BVS-6464 Rev. 2 5 Router configuration Router level Switches 1 - 4 on the configuration switch SW A set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router. -
Page 17: Router Mode
BVS-6464 Rev. 2 Router mode The BVS-6464 router allows switching in different modes. You can choose among: 64x64 Composite Video 32x32 Y/C (SVHS) 21x21 Beta / YUV 16x16 RGB/Sync Switches 5 - 6 on the configuration switch SW A set the router’s mode. The Triton Router Control System software must be configured according to the mode chosen on the router. - Page 18 BVS-6464 Rev. 2 Y/C (SVHS) Y-Signal Input Y-Signal Output C-Signal Input C-Signal Output...
- Page 19 BVS-6464 Rev. 2 R-Signal Input R-Signal Output G-Signal Input G-Signal Output...
- Page 20 BVS-6464 Rev. 2 B-Signal Input B-Signal Output RGBS R-Signal Input R-Signal Output G-Signal Input G-Signal Output...
- Page 21 BVS-6464 Rev. 2 B-Signal Input B-Signal Output S-Signal Input S-Signal Output...
-
Page 22: Vit Mode
BVS-6464 Rev. 2 VIT Mode The BVS-6464 may be configured to switch in different vertical intervals, depending on the video format that is applicable. This may be either PAL or NTSC. NTSC (525/60) and PAL (625/50) have different Vertical Intervals. Switching in line 6 in PAL means switching in line 8 in NTSC. -
Page 23: Control And Connection Of Triton Systems, Interface Protocol
BVS-6464 Rev. 2 7 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 7.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters. -
Page 24: Example: Several Units Connected By Ncb
BVS-6464 Rev. 2 7.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB. -
Page 25: Commands
BVS-6464 Rev. 2 Commands 7.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 26: Video Crosspoint Set Acknowledge
BVS-6464 Rev. 2 7.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
