    BVS-1602CP Rev. 2 1 General The BVS-1602CP is a 16x2 video router with vertical interval switching and integrated control panel. This state of the art router provides high performance circuits in SMD technology for maximum system performance. The BVS-1602CP is designed for all demanding routing tasks in digital studio and broadcast environments.
  • Page 10: Connection Drawing

    BVS-1602CP can also be delivered with DC ±5V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information.
  • Page 11: Connecting The Bvs-1602Cp To Your Pc

    BVS-1602CP Rev. 2 3 Connecting the BVS-1602CP to your PC For connection to a PC with Triton Router Control System, the RS-232 interface is used. The RS-232 port on all Triton devices uses the standard DCE pin-out, see pin-out table under 4.3. A standard modem cable can be used for connecting the router to the PCs serial port.
  • Page 12: Ncb Connection

    Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router.
  • Page 13: Pin-Out And Cable Type

    BVS-1602CP Rev. 2 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data Pin 6 = Not Connected...
  • Page 14: Rj45 To 5-Pin Din Converter

    BVS-1602CP Rev. 2 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45.
  • Page 15 BVS-1602CP Rev. 2 o Universal Control Panel to control all devices above, with user configurable default level. Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. • Triton - RCS Complete the Control loop, by connecting all Control bus connections to all Triton devices, before •...
  • Page 16: Router Configuration

    BVS-1602CP Rev. 2 5 Router configuration Router level Switch 1 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router.
  • Page 17: Router Extension Mode

    BVS-1602CP Rev. 2 Router extension mode Switch 5, 6 and 7 on the configuration switch set the router’s input offset in systems with 2 or more BVS- 1602CP. You can build systems up to 128x2. The chosen input offset defines on which input range each BVS-1602CP works on.
  • Page 18: Programming Of Restrictions

    BVS-1602CP Rev. 2 Programming of restrictions If the user enables the Restrictions option, the previously programmed restrictions will be fetched from the on-board memory during power-up. New restrictions may be programmed by putting the panel in “Programming mode”. This is done, starting from Panel Disable state, by pushing and holding “V/A toggle”, “Take On/Off”...
  • Page 19: Input Extension

    BVS-1602CP Rev. 2 7 Input extension BVS-1602CP allows input extension up to 128x2. Please connect the routers like shown below. The end of a loop chain must be terminated. This can be done either with a termination plug (75 Ohms) or the termination on the loop section.
  • Page 20: Control And Connection Of Triton Systems, Interface Protocol

    BVS-1602CP Rev. 2 8 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 8.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters.
  • Page 21: Example: Several Units Connected By Ncb

    BVS-1602CP Rev. 2 8.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB.
  • Page 22: Commands

    BVS-1602CP Rev. 2 Commands 8.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
  • Page 23: Video Crosspoint Set Acknowledge

    BVS-1602CP Rev. 2 8.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128...
  • Page 24: Control Panel Operation

    BVS-1602CP Rev. 2 9 Control panel operation The built-in panel in the BVS-1602CP offers 16 input select buttons on the top row. The input buttons are equipped with two LED indicators for displaying both video and audio status during breakaway operations.
