- Page 1 INSTRUCTION AND OPERATING MANUAL Compressor installation Cmax3 Powerband driven...
- Page 2 Repairs, maintenance or conversion w ork shall only be carried out by authorised, trained and qualified personnel that are familiar w ith the current safety regulations. - page 2 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013)
-
Page 3: Table Of Contents
Qualification and training personnel Operating safety-conscious Safety instructions operator Modifications and repairing spare parts Modifications installation Mounting installation Mounting inst ructions RTI installation pow erband driven Mounting instructions high air intake Start-up Maintenance installation Inspection during operation Weekly inspection Monthly inspection... -
Page 4: General
Telephone number: (0031) 544-377050 Fax: (0031) 544-376499 Email: info@rti.nl Service facilities For addresses of service/technical support facilities, please visit our w ebsite www.rti.nl Technical data compressors - page 4 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013) -
Page 5: Oil Cmax3 Compressor
5W50 or 10W50 5W50 or 10W50 Specification Specification Specification SJ/CD/EC SJ/CD/EC SJ/CD/EC Oil pressure: The oil pressure has to be between 0.5 and 2.0 bar (g.). - page 5 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013) -
Page 6: Oil Cooler
It is important to keep the oil cooler clean to prevent the overheating of the compressor. The oil temperature cannot exceed 90° C. Image 1.5.1 Oil cooler (art.no. 1342) - page 6 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013) -
Page 7: Safety
Using foreign spare parts and accessories may entail the loss of any liability for the consequences arising therefrom. Modifications installation Without approval from RTI, it is not permitted to make any alterations to the installation. - page 7 of 14 – Instruction and operating manual Cmax3... -
Page 8: Mounting Installation
The vacuum valve has not been set w hen the installation is delivered as a building kit (w ithout mounting by RTI). - page 8 of 14 –... -
Page 9: Mounting Instructions High Air Intake
The sliding joint should separate from the high air intake before the drivers cab is tilted. Check the negative pressure after mounting (this should not be below 45 mbar). Image 3.2.1 - page 9 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013) -
Page 10: Start-Up
The rotors of the compressor are sprayed w ith an anti-corrosion agent prior to delivery. During the initial operation this agent w ill evaporate as the compressor heats up. Since the RTI-installations are all tested a few minutes, the anti-corrosion agent on the rotors w ill have evaporated. -
Page 11: Maintenance Installation
Check the tension of the V-belt/pow erband and asses the w ear of the belt. Retighten the belt if your can press over 0.5 centimetre into the belt. - page 11 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013) -
Page 12: Monthly Inspection
0.5 centimetres into the middle of the belt after retightening. Stainless steel tension bolt M16x140 art.no. 16140 Image 5.3.1 - page 12 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013) -
Page 13: Halfyearly Inspection
Clean the compressed air cooler Maintenance/inspection list Along w ith every maintenance inspection the maintenance checklist on the next page must be filled out. We recommend sending the checklist to RTI after filling it out. Mail: info@rti.nl Fax: (0031) 544-376499 Hold on to the checklist, the checklist can be handed to the mechanic w hen the next maintenance service is due or w hen the installation needs to be repaired. -
Page 14: Maintenance Checklist
O -- Check pressure valve for 2.5 bar O -- Check functioning of indicators O -- Check the engine for unusual sounds O -- Clean the w indow pane - page 14 of 14 – Instruction and operating manual Cmax3 Pow erband driven (for-030/031013)
