INSTRUCTION AND
OPERATING MANUAL
Compressor installation CS750
direct driven

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GHH CS750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RTI GHH CS750

Summary of Contents for RTI GHH CS750

  • Page 1 INSTRUCTION AND OPERATING MANUAL Compressor installation CS750 direct driven...
  • Page 2 Preface This instruction and operating manual is required for compressor installations manufactured by the follow ing company: RTI Transport Installaties B.V. Albert Schw eitzerstraat 29 7131 PG Lichtenvoorde Tel. + 31 (0)544-377050 The manual provides information about the follow ing installation:...

  • Page 3: Table Of Contents

    General Qualification and training personnel Operating safety-conscious Safety instructions operator Modifications and repairing spare parts Modifications installation Mounting installation Mounting inst ructions RTI installation direct driven Start-up Maintenance installation Inspection during operation Weekly inspection Monthly inspection Half-yearly inspection Maintenance checklist - page 3 of 13 –...

  • Page 4: General

    Telephone number: (0031) 544-377050 Fax: (0031) 544-376499 Email: info@rti.nl Service facilities For addresses of service/technical support facilities, please visit our w ebsite www.rti.nl Technical data compressor - page 4 of 13 –...

  • Page 5: Oil Cooler

    Image 1.3.3 Oil cooler A GHH CS750 is equipped w ith an integrated oil-cooler. If this oil-cooler is removed to save space, the installation is equipped w ith an external oil-cooler. An external oil-cooler is equipped w ith a 24 volt fan. The fan must be rotating during operation and therefor the functioning of the fan must be checked during operation.

  • Page 6: Safety

    Using foreign spare parts and accessories may entail the loss of any liability for the consequences arising therefrom. Modifications installation Without approval from RTI, it is not permitted to make any alterations to the installation. - page 6 of 13 – Instruction and operating manual GHH...

  • Page 7: Mounting Installation

    The vacuum valve has not been set w hen the installation is delivered as a building kit (w ithout mounting by RTI). - page 7 of 13 –...

  • Page 8: Start-Up

    The rotors of the compressor are sprayed w ith an anti-corrosion agent prior to delivery. During the initial operation this agent w ill evaporate as the compressor heats up. Since the RTI-installations are all tested a few minutes, the anti-corrosion agent on the rotors w ill have evaporated.

  • Page 9: Maintenance Installation

    Maintenance installation INSPECTION DURING OPERATION Check the oil manometer before every start-up. The oil pressure must not drop below the minimum value of 0.3 bar, (normally 1-3 bar). When outside temperature is low it may take a few seconds before the oil pressure is visible. Check the air filter indicator.

  • Page 10: Weekly Inspection

    WEEKLY INSPECTION * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * ONLY CARRY OUT WHEN INSTALLATION IS COOL AND AT A STANDSTILL * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * Check the level of lubricating oil w eekly.

  • Page 11: Monthly Inspection

    MONTHLY INSPECTION * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * ONLY CARRY OUT WHEN INSTALLATION IS COOL AND AT A STANDSTILL * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * This check may only be carried out by skilled mechanics.

  • Page 12: Halfyearly Inspection

    Maintenance/inspection list Along w ith every maintenance inspection the maintenance checklist on the next page must be filled out. We recommend sending the checklist to RTI after filling it out. Mail: info@rti.nl Fax: (0031) 544-376499 Hold on to the checklist, the checklist can be handed to the mechanic w hen the next maintenance service is due or w hen the installation needs to be repaired.

  • Page 13: Maintenance Checklist

    Maintenance checklist Firma Date maintenance Name mechanic Compressor Address Serial number Installation-no. : PO………….. Truck Year manufactured Truck nr. Licence plate no. Chassis: No. KM driven: Actions COMPRESSOR: O -- Drain oil O -- Clean oil filter O -- Check potential leakage machine O -- Change + top up oil O -- Check oil hose for potential cracks/damages SILENCER:...
