USING THE HEATER

HEATER OPERATION

Always operate the heater in the upright position following all instructions and
recommendations listed in this manual.

HEATER LOCATION

Place the heater in the area of the room that is coldest.

HEATER CONNECTION

Plug heater directly into 120 volt A.C. 60Hz outlet. Be sure the plug fits tightly in outlet. A
loose connection may cause overheating and damage to the plug or heater.
NOTE: To prevent overloading a circuit, do not plug the heater into a circuit that is serving
other electrical needs.
The heater may be operated by the controls located on the heater (see Fig.2) or by the
remote control(see Fig.3)
1.Carefully remove the heater from the plastic bag and the carton.
2.Place the heater on a firm level surface.
3.Power On the unit by switching on the Main Power Switch(Fig.1).The control panel will
display the factory default temperature of 77 °F for one second, and then show the
current room temperature.
4.Turn the heater ON by pressing the
- If the room temperature is less than 2°F lower than the set temperature, the heater will
go into FAN MODE and blow unheated air.
- If the room temperature is less than 2°F-4°F lower than the set temperature, the heater
will go into LOW HEAT MODE and blow warm air.
- If the room temperature is more than 4°F lower than the set temperature, the heater will
go into HIGH HEAT MODE and blow hot air.
5.Regardless of the difference between room temperature and heater settings, you may
repeatedly press the
mode.
NOTE: Once in a particular mode, using the
setting will also advance the mode according to the temperature differences specified in
step 4 above.
6.To turn the heater off, press the POWER button.
NOTE: When the unit is powered off on the control panel, the fan may continue to run to
cool off the ceramic elements and dispense any retained heat. The unit shut off
automatically when sufficiently cooled down.

OSCILLATING FUNCTION

The Oscillating function will work in any mode.
Press the button to oscillate the heater fan from left to right across a wide degree arc.
To turn the oscillation off, press this button again.
on the control panel or remote control.
button to force the heater to advance to LOW, HIGH or FAN
3
or buttons to adjust the heater
