TIMER FUNCTION

The Timer function will work in any mode. The timer function allows you to set the length
of operation from 1 to 8 hours. Each time the
will increase 1 hour. The duration the timer is set for will be displayed on the LED screen
in hour increments. TO TURN THE TIMER FUNCTION OFF: Press the
continuously until the LED screen displays " 0 H".
USING THE HEATER

TEMPERATURE SETTING

1. You may adjust the desired temperature setting in any heater operation mode. The
temperature can be set from 50°F to 95°F.
2. Press the or
- The heater will operate in LOW HEAT mode and blow warm air when the set
temperature is 2°F-4°F higher than the room temperature.
- The heater will operate in HIGH HEAT mode and blow hot air when the set temperature
is more than 4°F higher than the room temperature.
- When the room temperature reaches the set temperature the heater will automatically
go into FAN MODE and blow unheated air.
NOTE: The heater will cycle between FAN MODE and LOW HEAT MODE as it maintains
the set temperature.

SAFETY FEATURES

A thermal overload protector is built into the heater to automatically shut the heater off if it
becomes overheated. The heater must cool down and be reset before it will operate
again. To reset, turn the Main Power Switch button to Off and then back ON. Press the
button on the control panel to resume normal operation. Be sure that the heater is on a
smooth level surface with no obstructions. The heater is also equipped with a safety tip-
over switch to turn power off to the heater when the heater tip over. To resume heater
functions simply stand heater upright. With tip over protection, the heater will only
operate when placed upright on a level surface.

REMOTE CONTROL

The remote control uses on button cell battery, type CR2025(3V).To remove the battery
carriage use your thumb to squeeze the release tab to the right and then pull the carriage
out. Place the battery into the carriage and slide the carriage back into the remote. See
Fig.4. We recommend the use of a Lithium-ion battery for longer use.
NOTE: Follow battery disposal instruction on battery packaging, or contact your local
safety council for safely disposal of batteries.
Before using the remote control, you must remove the insulating film as shown in the
figure below.
1. All functions performed with remote control work identically to the heater control panel.
2. Aim the remote control at the heater control panel to operate the heater.
button to adjust the temperature setting.
button is pressed the length of operation
Fig. 4
4
button
