- Page 1 FogMist™ Track System for Produce Cases System Installation Manual toll free help line: 866.677.6339 engineering & parts: 770.420.3060 www.prodew.com | sales@prodew.com REV - MAR 2016...
-
Page 3: Table Of Contents
10 - 11 Start-up Procedure Timer Settings System Warranty If there is any information in this manual that is unclear, please let us know so we can revise future editions. Contact our Customer Service department with your suggested edits: sales@prodew.com or 770.420.3060... -
Page 4: Packing List
Packing List Quantity Description Images Timer Box with Transformer and 110V Plug Solenoid Box VARIES FogMist™ Track Line Air Compressor Kit Sediment Filter (5 Micron) with Ball Valve VARIES 3/8in Air/Water Supply Polypropylene Tubing VARIES 5/8in Corrugated Tubing VARIES 8in Zip Ties VARIES Track Cover VARIES... -
Page 5: Utility Requirements
Utility Requirements THE FOLLOWING MUST BE IN PLACE BEFORE OUR INSTALLERS ARRIVE ON LOCATION Water Power Drain • Dedicated water supply: • 2-plug outlet: • Floor drain: 1/2in female NPT adapter 110/220VAC Minimum 3/4in for waste with ball valve 60/50Hz water or a 1/2in drain pipe 20Amp • Easily accessible and near... -
Page 6: Quick Connect Fitting Assembly
Quick Connect Fitting Assembly Page 5... -
Page 7: System Layout
System Layout ITEM PART NUMBER DESCRIPTION QUANTITY NUMBER HTIM001-110C10 Timer, 110VAC - Premium HSOLBX-PRM-A-FOG Humidity Solenoid Box - Premium HCOM001-2HD-FOG Air Compressor, Double Head, 110VAC FMTRC38-4BLK FogMist™ Track, 4ft - Black 2FIL-ENCAP-S10-05 Filter, Sediment 10in - 5 mic Page 6... -
Page 8: Air Compressor Kit Diagram
Air Compressor Kit Diagram ITEM NUMBER PART NUMBER DESCRIPTION QUANTITY 2GAU006 Gauge 1.5 inch 1/4 inch NPT, 0-160 2PBSHM14F18-B Bushing, 1/4 inch M x 1/8 inch F - Plastic 2PMCQ38M14 M Con, 3/8 inch QC x 1/4 inch MPT 2AFIL-INL14-5MIC Air Filter 1/4 inch FNPT 5 mic 2MSTF14F14M14 Straight Tee 1/4 inch, MTL... -
Page 9: Track Breakdown
Track Breakdown ITEM PART NUMBER DESCRIPTION QUANTITY NUMBER 2PURQ38Q14 Poly, Union Red 3/8in Q x 1/4in Q 2P2WDIVQ6-2XQ6 2-Way Divider, 6mm Q-2 x 6mm QA2 2VALQ6 Straight Valve 6mm x 6mm FMSPR-4W6A-BL38T Spray Head, FogMist™ 4mm x 6mm Stem 3CLP388B Clamp, 388 - Black 3CLPCOV03-B C-Clamp Cover 9.75in... -
Page 10: Track Mounting Options
Track Mounting Options Page 9... -
Page 11: Installation Instructions
Installation Instructions Instructions Images STEP 1 • Mount the mist control box, air compressor, and timer box at the center of the area being misted on top of the case. • Other mounting locations can be used. STEP 2 • Mount the clamp lock into the case ceiling in the area to be fogged with the provided screws. - Page 12 Installation Instructions (Continued) Instructions Images STEP 6 • Attach the 3/8in water tubing to the port labeled “NOZZLE” on the mist control box. • Run the 3/8in water tubing to the 7/8in drilled hole in the case ceiling. Cut to length for the canopy. • The feed’s under-shelf lines will be cut at shelf locations.
-
Page 13: Start-Up Procedure
Start-up Procedure 1. Plug in the air compressor(s) into the outlet on the timer box. Plug the timer’s 110V plug and transformer into the city power supply outlet. 2. Ensure that you have water and power. 3. Confirm that everything is plugged in and connected. 4. Turn on water valve and check the inlet pressure by looking at the solenoid box gauge. The pressure is factory set to 30 PSI. -
Page 14: Timer Settings
Timer Adjustment • The recommended settings are preset at our manufacturing facility. • ONLY change the settings if there is too much or too little mist. • Start with adjusting the off time first and then the on time. Recommended Timer Settings Settings Time ON TIME 1.5 minutes (Amount of time fog is being produced) OFF TIME 8 minutes (Amount of time between fogging) -
Page 15: System Warranty
365 days from the date of invoice for parts and 90 from the date of invoice for labor, and that either Prodew, Inc. or its Authorized Service Agency’s examination, shall disclose to the Distributor’s satisfaction to be thus defective. - Page 16 Water, Air & Energy Innovations toll free help line: 866.677.6339 engineering & parts: 770.420.3060 www.prodew.com | sales@prodew.com...
