FogMist™ Track

Installation Manual for Produce Canopy

rev June 2017

Table of Contents

Need help?

Do you have a question about the FogMist Track and is the answer not in the manual?

Questions and answers

Summary of Contents for Prodew FogMist Track

Page 1 FogMist™ Track Installation Manual for Produce Canopy rev June 2017...
Page 2 www.facebook.com/Prodew.Inc...
Page 3: Table Of Contents
Package Contents Utility Requirements System Layout Air Compressor Kit Diagram FogMist™ Track Breakdown System Installation 11 - 15 Start-Up Procedures 16 - 19 Timer Settings System Warranty Having trouble understanding our instructions? Contact our customer service department with your questions. sales@prodew.com...
Page 4 Quick Connect Fitting Assembly...
Page 5: Package Contents
Package Contents Timer Box Solenoid Box FogMist™ Track FogMist™ Track Cover FogMist™ Clamp Lock (HTIM001-110-CLDUL) (FMSOLBX-PRM38) (FMTRC38- ― -1B) (3CLPCOVO ― -B) (3CLP388B) Phosphate Filter (5mic) 3/8” Tubing 3/4” Tubing 1/2” x 6” Protective Air Compressor Kit (2FIL-EC-S10-2038-P) (2TUB12O-38I-B) (2TUB340-58ID-B) (HCOM001-2HD-FOG) Corrugated Tubing (2TUB-COR-12ID-B-SLT)
Page 6: Utility Requirements
Utility Requirements IMPORTANT These utility requirements must be in place before installation can take place. Water Supply 4-Plug Power Outlet Floor Drain • 1/2in female NPT • 110/220VAC • Minimum 3/4in for adapter with ball valve 60/50Hz waste water or a 1/2in 20Amp drain pipe • Minimum inlet pressure...
Page 7: System Layout
System Layout...
Page 8: Air Compressor Kit Diagram
Air Compressor Kit Diagram HCOM001-2HD-FOG (Small Systems) PART NUMBER PART NUMBER DESCRIPTION DESCRIPTION QTTY QTTY PART NUMBER PART NUMBER DESCRIPTION DESCRIPTION QTTY QTTY 2FCVAL-M14 Air Flow Control Valve 1/4 inch NPT 2GAU007 Gauge 1.5'' 1/4NPT, 0-150 3CLPHUM003 Suction Cup, w/ 8-32 MS Insert 2PMCQ38M14 M Con, 3/8 inch QC x 1/4 inch MPT 1WIR050...
Page 9 FogMist™ Track for Produce Breakdown ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION 2PURQ38Q14 Poly, Union Red 3/8Qx1/4Q 3CLP388B Clamp, 388 BK 2P2WDIVQ6-2XQ6-C 2 Way Divider, 6mmQ-2 x 6mmQA2 3CLPCOV03-B C Clamp Cover 9.75" 2VALQ6 Straight Valve 6mm x6mm 2PSP6-C Red Stem Plug 4SPRFM-4W6A-BL38T...
Page 10: System Installation
System Installation Mount the mist control, air compressor and Decide where to mount the clamp lock onto the IMPORTANT timer box at the center of the area being case ceiling in the area to be fogged - preferably misted on top of the case. inside the air curtain (can Make sure to place the control box also be placed outside of air...
Page 11 System Installation Spread the lines across the area to be Using 3/4in tubing on the track line, insert Once the lines are in place, ensure that all fogged, starting from the center point and the lines into the clamp. (Try not to twist the tubing fits into the clamp.
Page 12 System Installation Insert a piece of corrugated tubing into Once the corrugated tubing is set into place Remove the couplers from the ends of the the hole to protect the lines. it’s time to connect track lines to the controls. track liners to be able to guide lines through the corrugated tubing.
Page 13 System Installation Attach the 3/8in water tubing to the port Run 3/8in water tubing to water Run 3/8in air tubing from the air compressor labeled “NOZZLE” on the mist control box. Y-divider. to air Y-divider. Cut to length. Cut to length. Connect the 3/8in air tubing from the Connect the 3/8in water tubing from the mist Your lines should look like this after they’re...
Page 14 System Installation FLUSH THE CITY WATER LINE FOR Connect the 3/8in black tubing from the Fill all voids around the corrugated tubing 3-4 MINUTES BEFORE CONNECTING water supply to the inline filter at the ball with silicone to avoid leaks. TO OUR WATER LINE.
Page 15: Start-Up Procedures
Start-up Procedures Plug the air compressor(s) into the outlet on the timer box. Plug the Ensure that you have water and power. Confirm timer’s 110V transformer into the city power supply outlet. that everything is plugged in and connected. Turn on water valve and check the inlet pressure by looking at the Set OFF TIME to its minimum (0.5 min) and ON Time to solenoid box gauge.
Page 16 Start-up Procedures Flip the toggle switch on the timer box to ON position. The air Check the air pressure by looking at the gauge on the air compressor should start after 5 seconds. Flush for one cycle and compressor. The air pressure should be 15-20 PSI (higher then replace the stem plugs.
Page 17 Start-up Procedures Set the timer to Do a happy dance. recommended settings System is ready for use. (See Recommended Timer Settings - pg 20).
Page 18: Timer Settings
Timer Settings FILTER CHANGE IMPORTANT The recommended cycle times are preset at our manufacturing facility. SCHEDULE The factory presets are the If repairs or changes have been made to the system, we recommend that you recommended settings for the system. flush the lines to ensure that no particles, liquid Teflon, Teflon tape, pipe dope, Only change the settings if there is or other foreign matter is present in the system.
Page 19: System Warranty
365 days from the date of invoice for parts (not including nozzles) and 90 from the date of invoice for labor, and that either Prodew, Inc. or its Authorized Service Agency’s examination, shall disclose to the Distributor’s satisfaction to be thus defective.
