Summary of Contents for Lifan KP2300i-2
- Page 1 INVERTER PETROL GENERATOR Owner’s Manual KP2300i-2 Read this manual carefully before operating this generator...
- Page 2 PREFACE Thank you for choosing a petrol generator set by our Co. Based on the latest technology at home and abroad, our Co. has successfully developed the petrol generator set. The unit is characterised by advanced design, compact structure, reliable performance, convenient service, low fuel consumption and noise as well as fashion shape.
- Page 3 Safety Warnings Please read this manual carefully before using this petrol generator set Special important contents in this manual will be indicated in the following ways, please note. DANGER：If you do not follow the instructions, your life will be in danger or you will be seriously injured. WARNING：If you do not follow the instructions, your life will be in danger or you will be seriously injured.
-
Page 4: Table Of Contents
CONTENTS 1. Safety notice for petrol generator ········································································································· 1 2. Introduction to Parts and Components ································································································· 4 3. Control functions ··································································································································· 7 3.1 Three-in-one combination switch ······························································································· 7 3.2 Low oil warning light (red) ··········································································································· 8 3.3 Overload indicator light (red) ······································································································ 8 3.4 AC indicator light(green) ··············································································································... - Page 5 5. Operating ··············································································································································· 17 5.1 Starting the Generator ················································································································· 18 5.2 Stopping the Generator ··············································································································· 19 5.3 AC connection ······························································································································ 20 5.4 Battery charging ·························································································································· 21 5.5 AC parallel operation ··················································································································· 23 5.6 Scope of application ···················································································································· 25 6. Maintenance ·········································································································································· 27 6.1 Spark plug maintenance ··············································································································...
-
Page 6: Safety Notice For Petrol Generator
1.0 Safety Notice for Petrol Generator 1. Never operate it in an enclosed room 2. Never connect directly to home/mains electricity 4. Keep inflammables at least 1m away from the unit 3. Do not operate in wet conditions... - Page 7 5. No smoking when filling fuel 6. Always fill fuel with the generator stopped 7. Avoid spilling fuel when filling...
- Page 8 DANGER If connecting the generator to home/mains power supply, ensure this is performed by a qualified electrical engineer as this involves fitting specialists switch gear (ATS). Improper connection between the generator and loads could cause injury, death, fire or damage to the generator 1.
-
Page 9: Introduction To Parts And Components
2.0 Introduction to Parts and Components ① Fuel gauge/sight glass (not always present) ⑦ 3-in-1 combination switch (ignition on, fuel on ② Fuel tank cap vent lever and choke on/closed) ③ Fuel tank cap ⑧ Spark plug access cover ④ Carrying handle ⑨... - Page 10 2.1 Control panel 120V 60Hz ① Voltage recovery button ② Low Oil Warning light (red) ③ Overload indicator light (red) ④ AC indicator light (green) ⑤ AC socket ⑥ Energy conservation switch (ECS) ⑦ DC socket ⑧ USB socket ⑨ DC protection ⑩...
- Page 11 230V 50Hz ① AC socket ② Low Oil warning light (red) ③ Overload warning light (red) ④ AC indicator light (green) ⑤ Voltage recovery button ⑥ Energy conservation switch (ECS) ⑦ DC protection ⑧ DC socket ⑨ USB socket ⑩ Parallel socket (optional) ⑪...
-
Page 12: Control Functions
3.0 Control function 3.1 Three-in-one Combination Switch ① Conbination Switch in "OFF" position: The ignition circuit is closed, the fuel is off and the engine cannot not start. ② Combination Switch in "ON" position: The ignition circuit is open, fuel is on, choke is in full open state allowing the engine to run normally. -
Page 13: Low Oil Warning Light (Red)
3.2 Low oil warning light (red) When the crankcase oil drops below the safety level, the oil protection system will automatically shut off the engine and the low oil warning light (red) will light up. Filling the oil to the correct level will allow the engine to be re-started. -
Page 14: Ac Indicator Light(Green)
3. Check whether there is a foreign body blocking the air inlet and whether there is any abnormality in the relevant control parts. If there is any problem, immediately eliminate it. 4. After checking, press the voltage recovery button for 1-3 seconds to restore the voltage output. NOTICE：When using electrical equipment with high startup current (such as compressors, submersible pumps, etc.), the overload indicator may light up for a few seconds at the beginning. -
Page 15: Dc Protection
6. When the green light is off and the red light flashes 5 times in 3 seconds: This indicates that the bus voltage is too high and the generator has no output. 7. The green light is off and the red light flashes 6 times in 3 seconds: This indicates overload protection and no output. -
Page 16: Energy Conservation Switch
3.6 Energy Conservation switch ① "ON", when the energy conservation switch is in the "ON" position, the energy saving device controls the engine speed according to the connected load, which can achieve better fuel consumption and lower noise. ② "OFF", when the energy conservation switch is in the "OFF" position, the engine is running at the rated speed (3600r/min) regardless of whether the load is connected. -
Page 17: Fuel Tank Cap
3.8 Fuel tank cap Rotate counter clockwise to remove the tank cap. 3.9 Fuel tank cap vent lever There is a vent lever on the top of the fuel tank to prevent the flow of fuel. When using the generator, the vent lever must be in the "ON" position allowing fuel to flow into the carburetor to keep the engine running. -
Page 18: Parallel Operation
3.11 Parallel operation (optional feature) The parallel connector is used to connect two 2300i-2 of the same voltage and frequency running parallel to one another. Parallel operation requires two 2300i-2 devices and special cables (Rated output power of parallel operation is 3.4KVA, rated current of 120V generator is 28.0A and rated current of 230V generator is 14.5A) Operating procedures and related considerations are detailed in the parallel output system. -
Page 19: Pre-Use Inspection
4.0 Pre-use inspection NOTICE：Be sure to check before each use. WARNING： The engine and muffler will become very hot during use. Do not check or perform any repairs until they have fully cooled. Ensure any parts of the body or clothing do not come into contact with the engine and muffler. -
Page 20: Engine Oil
4.2 Engine oil This generator is delivered dry WITHOUT OIL or FUEL. Do not attempt to start the engine until the oil has been filled to the correct level. 1. Please place the engine on a level surface. 2. Rotate the locking handle of the oil port cover and remove to gain access to the dipstick ①. 3. -
Page 21: Preparation
4.3 Preparation WARNING: If any of the following parts do not work properly, please carefully check and repair the engine before starting. The user should be concerned about the state of the generator. Even if the generator is not in use, its important parts may break down suddenly. -
Page 22: Operating
5. Operating the Generator WARNING: ⚫ Do not use the generator in a confined space. The exhaust gases discharged from the generator may cause loss of consciousness or even death in a short time. Please use it in a well-ventilated place. ⚫... -
Page 23: Starting The Generator
5.1 Starting the Generator from cold 1. Turn the energy saving switch to "OFF". 2. Turn the fuel tank cap ventilation lever to "ON". 3. Rotate three-in-one combination switch to the "CHOKE" position to: A) turn the fuel on B) turn the ignition system on C) close the choke to assist the cold engine to start NOTICE: When the engine is hot, it may not always be necessary to set the "CHOKE"... -
Page 24: Stopping The Generator
5.2 Stopping the Generator NOTICE: Turn off all connected electrical equipment. 1. Turn the energy saving switch to "OFF" 2. Disconnect all electrical equipment 3. Set the combination control switch to the "OFF" position to: A) turn the fuel off B) turn the ignition system off 4. -
Page 25: Ac Connection
5.3 AC connection WARNING: All electrical equipment should be disconnected before the plug is inserted. NOTICE: ⚫ Ensure that all electrical equipment, including wires and plugs, are in good condition before connecting to the generator. ⚫ Make sure all load of the generator is within the rated load range. ⚫... -
Page 26: Battery Charging
5.4 Battery charging NOTICE: ⚫ The rated DC voltage of this generator is 12V ⚫ Connect the battery to the generator once the generator is running ⚫ Before starting to charge, make sure the DC protector is on 1. Turn on the generator. 2. - Page 27 ⚫ It is recommended to check the electrolyte specific gravity at least every 1 hour to prevent the battery from overcharging. WARNING: Do not smoke while connecting or disconnecting the battery during charging. The resulting spark will ignite the gas around the battery. Battery electrolyte contains sulfuric acid, which is toxic and is a burn hazard.
-
Page 28: Ac Parallel Operation
5.5 AC parallel operation (optional feature) Before connecting a device to any generator, ensure that it is in good working condition and that its electrical rating does not exceed the total number of parallel generators. Most motors require more than their working current when started. - Page 29 Correct the problem and restart the generator. The two types of 2300i-2 generators (same voltage and frequency) can be connected to each other, using a parallel cable suite to increase the available power supply. Connect the equipment or power cord to the generator first as described in the accessories to the parallel running cable kit accessories.
-
Page 30: Scope Of Application
The limit time when the maximum power can be operated: 30 minutes Maximum power for parallel operation: 3.6Kw Rated power for parallel operation: 3.4Kw, continuous operation, not exceeding rated power. The requirement for total power of all connected equipment must be considered. The list of manufacturers of electrical appliances and power tools usually lists power ratings for similar models or serial numbers. - Page 31 For example: Generator rated output 1600W Frequently Power factor ≤1600W ≤1280W When the total power exceeds the rated power, the overload indicator light will illuminate (see P8). NOTICE: Do not overload; the total power of the electrical equipment must not exceed the output power of the generator, or it will cause damage to the generator.
-
Page 32: Maintenance
6. Maintenance Good maintenance is the best guarantee to achieve safe, economical and zero fault operation. It also contributes to environmental protection. The user should operate the machine safely. Periodic inspection, adjustment and lubrication can ensure safe and efficient operation of the generator. Warning: Please turn off the engine before maintenance. - Page 33 Spark eliminator Check-adjust Cylinder head & ★★ Clean carbon deposit piston ★ These items should be replaced if necessary ★★ These items shall be maintained by the company's authorised dealers, unless the user has appropriate tools and maintenance capabilities NOTICE: *1-- the first oil change should be done 1 month or 20 hours whichever is reached first *2-- air filters should be cleaned more frequently when used in damp or dusty places...
-
Page 34: Spark Plug Maintenance
6.1 Spark plug maintenance The spark plug is an important part of generator and must be checked regularly 1. Remove the outer plastic cover ①, open the spark plug maintenance cover and remove the spark plug cap ② insert the spark plug spanner ④ into the hole from the outside of the cover 2. -
Page 35: Adjustment Of Carburetor
6.2 Carburettor adjustment The carburetor is an important part of the engine. Adjustments should only be performed by someone with professional mechanical knowledge 6.3 Changing the engine oil Warning: Drain the oil when warm; do not drain oil immediately after shutting down the generator. Oil temperature is still very high, be careful to avoid burns. -
Page 36: Air Filter
6.4 Air filter 1. Remove the screw ①, and outer plastic cover ② 2. Remove the screw ③ and air filter housing cover ④ 3. Remove the foam element ⑤ 4. Clean the foam element with solvent and dry it 5. -
Page 37: Muffler Mesh And Spark Collector
6.5 Muffler mesh and spark collector Warning: engine and muffler will remain very hot after use. Do not allow your skin and clothing to directly touch the engine and muffler during inspection and maintenance. 1. Remove the screw ①, remove the rear grille ② 2. -
Page 38: Fuel Tank Filter
6.6 Fuel tank filter Warning: Do not use petrol where there is smoke or flame. 1. Remove fuel tank cap and strainer. 2. Clean the fuel tank strainer with fresh petrol. 3. Dry the strainer and replace back in the fuel tank. 4. -
Page 39: Storage
7. Storage Some storage measures should be taken to prevent aging if you plan to store this generator for a long time. 7.1 Draining off fuel 1. Turn the three-in-one combination switch to the OFF position 2. Open the tank cap and remove the strainer. Syphon all the fuel from the tank into a suitable storage container and reinstall the tank cap. - Page 40 7.2 Engine storage Follow the steps below to protect the cylinder, piston rings and other corrosion-prone parts. 1. Set the three-in-one combination switch to “OFF” 2. Remove the spark plug, pour in approx. 15ml (1 tblespn) of SAE10W30 oil , replace the spark plug then pull and release the hand-pull starter several times to lubricate the cylinder and valves with the oil.
-
Page 41: Troubleshooting
8. Troubleshooting Engine does not start starter normal Spark plug has no spark 1. Fuel system Spark plug may have carbon deposits or moisture There is no petrol in the combustion chamber Clean and dry spark plug or replace No fuel in the tank Refuel Trouble in ignition system Please contact... -
Page 42: Parameters
9. Parameters Model No. KP2300iO-2 Type Inverter Rated frequency/Hz 50/60 Rated voltage/V 120/220/230 Rated output power/Kw Max. output power /Kw 1.95 Power factor Generator DC output /V-A 12V-8A AC output quality ISO8528 G2 THD/% Noise /dB Non-fuse protector Overload protect Controlled by inverter overload protect program... - Page 43 Engine model 148F Engine type Single cylinder, 4-stroke, forced air cooled, OHV Displacement/cc Fuel type Unleaded petrol Engine Fuel tank capacity/L Continue running time/h Engine oil capacity 350ml Spark model No. NGK CR5HS Starting mode Hand Recoil Dimensions L×W×H/mm 495*290*460 Net weight/Kg 18.70...
-
Page 44: Wiring Diagram
10.0 Wiring diagram AC 120V 60Hz... - Page 45 AC 220V 5...
- Page 46 Y-160-1...
