Installing the hob flush with the
worktop
 Create the worktop cut-out.
Remember to maintain the minimum
safety distances (see "Installation –
Safety distances").
 Solid wood, tiled and glass worktops:
Fix a wooden frame 5,5 mm or 7 mm
(KM 7404 FX, KM 7414 FX,
KM 7414 FX Glas) below the top
edge of the worktop.

Risk of damage from incorrect
connection.
The hob electronic module may be
damaged if a short circuit occurs.
The mains connection cable must be
connected to the hob by a qualified
electrician.
 Connect the mains connection cable
to the hob by following the
instructions in the wiring diagram (see
"Installation – Electrical connection").
 For all hobs, apart from the following
models: KM 7404 FX, KM 7414 FX,
KM 7414 FX Glas, attach the sealing
strip provided underneath the edge of
the hob. Do not apply the sealing
strip under tension.
 Feed the mains connection cable for
the hob down through the worktop
cut-out.
The gap between the ceramic surface
and the worktop must be at least
2 mm wide. This is required so that
the hob can be sealed.
 Centre the hob in the cut-out.
 If an air intake-optimised base panel
is installed, position the hob so that
the fans are located above the cut-
outs.
 Connect the hob to the electricity
supply (see "Installation – Electrical
connection").
 Check that the hob works.
 Seal the gap between the hob and
worktop with a silicone sealant that is
heat-resistant to at least 160 °C.
