- Page 1 URBAN EDGE DISPLAY CASE Assembly Instructions Scan the QR code to visit the SKU WRADC product page.
- Page 2 PART QUANTITY Side Panel (A, B) ............................2 Wood Shelf (C, D, E, F, G, H) ........................6 Acrylic Panel (I, J) ............................2 Acrylic Door (K, L) .............................2 Door Hinge ..............................2 Lock Components ............................2 Slotted Screw ............................20 Key ................................2 Tools Required: Philips screwdriver (not included) Assembly 2 people recommended for assembly.
- Page 3 4. Lift the unit to standing position. 5. Slide glass panel I down into channel of shelf E. 6. Slide glass panel J down into channel of shelf H. Holding panel J, slide shelf F into position, then secure shelf F with slotted screws to keep panel J in place. Hand-tighten screws.
- Page 4 7. Attach shelf C with hole for door hinge facing down with slotted screws. Hand-tighten screws. 8. Attach the rest of the shelves using slotted screws. Hand-tighten screws.
- Page 5 9. Assemble door lock components on acrylic doors (K, L). Add lock and secure with washer. Then attach locking tab. Secure all pieces with crosshead screw. 10. Repeat on other door.
- Page 6 13. Fully tighten all slotted screws. Use a coin or flat object to tighten carefully and avoid scratching the surfaces of the screws. Assembly is complete. If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388.
