PFlow Industries B Series Owner's, Installation And Maintenance Manual

Box lift
Hide thumbs Also See for B Series:
Table of Contents

Advertisement

Quick Links

Download this manual
B Series | Box Lift
Owner's, Installation,
and Maintenance Manual
Important:
Read this entire manual.
Important safety information
is included.
Before starting the installation,
verify the job site dimensions and the
dimensions of the delivered materials
against the PFlow Industries, Inc.
General Arrangement (GA) drawing.
The illustrations depicted in this manual
are not to scale or detail. The illustrations
are for reference only.
15719-0001 | Rev H | 2023-12-01 | Printed in the U.S.A.
www.pflow.com
P 414 352 9000
F 414 352 9002
6720 N. Teutonia Ave.
Milwaukee, WI 53209
