21 Series | Hydraulic VRC
Owner's Manual
Important:
Read this entire manual.
Important safety information
is included.
The illustrations depicted in this manual
are not to scale or detail. The illustrations
are for reference only.
15707-0002 | Rev F | 2018-10-15 | Printed in the U.S.A.
www.pflow.com
P 414 352 9000
F 414 352 9002
6720 N. Teutonia Ave.
Milwaukee, WI 53209

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21 Series and is the answer not in the manual?

Questions and answers

Related Manuals for PFlow Industries 21 Series

Summary of Contents for PFlow Industries 21 Series

  • Page 1 P 414 352 9000 F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 21 Series | Hydraulic VRC Owner’s Manual Important: Read this entire manual. Important safety information is included. The illustrations depicted in this manual are not to scale or detail. The illustrations are for reference only.
  • Page 2 www.pflow.com P 414 352 9000 Table of Contents F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Description Section | Page 1. Contact Information 15705-0011 1 | 1 2. General Information 15710-0004 2 | 1 Introduction 2 | 1 General Overview 2 | 1 Code Requirements...

  • Page 3: Table Of Contents

    www.pflow.com P 414 352 9000 Table of Contents F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Description Section | Page ectrica tan ar efinition 15709-0085 6 | 1 Field Electrical Wiring Standards 6 | 1 e nitions 6 | 1 Requirements 6 | 1...
  • Page 4 www.pflow.com P 414 352 9000 Table of Contents F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Description Section | Page 10. Manual Lowering 15702-0008 10 | 1 Operation Safety Information 10 | 1 Emergency Use Only! 10 | 1 11.
  • Page 5 Product Support Department e-mail: psd@p ow.com Sales e-mail: sales@p ow.com For a list of contact personnel visit the PFlow Industries, Inc. website at: http://www.p ow.com/contact-us/ Documentation PFlow Industries, Inc. reserves the right to make changes or improvements to the standard model line at any time. PFlow Industries, Inc. reserves the right to make changes to subsequent editions of the manual without prior notice to holders of this edition.
  • Page 6 www.pflow.com P 41 4 3 5 2 9 0 0 0 Contact Information Section 1 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Section 1 | 2 15705-0011 | Rev | 2018-04-01 | e-mail psd@pflow.com...
  • Page 7 VRCs general installation. The information and illustrations do not cover every possible contingency or circumstance regarding nonstandard options or site conditions. If there is a problem, call PFlow Industries, Inc. at (414) 352-9000, during normal business hours, 8:30 a.m. to 5:00 p.m. central standard time, Monday through Friday.
  • Page 8 www.pflow.com P 41 4 3 5 2 9 0 0 0 General Information Section 2 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Section 2 | 2 15710-0004 | Rev C | 2018-04-01 | e-mail psd@pflow.com...
  • Page 9 7. Lost time and/or additional trips for missing or damaged components. 8. Expedited freight charges. i ation The obligation for PFlow Industries, Inc. is limited to only the replacement or repair of defective components that received prior authorization. This is the owner’s sole remedy.
  • Page 10 Notify PFlow Industries, Inc. by phone, FAX, or e-mail during the next business day if an event NOTE occurs during our non-working hours. Issuance of an authorization number does not guarantee approval and/or payment.
  • Page 11 Instructions and warnings must be read and thoroughly understood by all operators and users. PFlow Industries, Inc. recommends that the owner conduct regular sta training including safety instructions on a regular basis to avoid the risk of accident or damage to the VRC.
  • Page 12 Keep clear of unsupported platforms. Stay out of the area under a raised platform. If a maintenance operation requires the carriage to remain in the raised position, refer to Bulletin 15709-0083 for additional information or contact PFlow Industries, Inc. Product Support Department for assistance.
  • Page 13 Climbing, sitting, walking, or riding on equipment while the equipment is in operation could result in death or serious injury. If this VRC needs to be modi ed in any way, contact PFlow Industries, Inc. for assistance. Do not make any unauthorized changes.
  • Page 14 www.pflow.com P 41 4 3 5 2 9 0 0 0 Important Safety Section 4 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Information Milwauke e , WI 5 3 2 0 9 Hydraulic Safety Precautions Wear personal protective equipment, such as gloves and...
  • Page 15 www.pflow.com P 41 4 3 5 2 9 0 0 0 Important Safety Section 4 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Information Milwauke e , WI 5 3 2 0 9 During operation, the surfaces of some components may become hot.
  • Page 16 www.pflow.com P 41 4 3 5 2 9 0 0 0 Important Safety Section 4 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Information Milwauke e , WI 5 3 2 0 9 Electrical Safety Precautions...
  • Page 17 www.pflow.com P 41 4 3 5 2 9 0 0 0 Important Safety Section 4 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Information Milwauke e , WI 5 3 2 0 9 Electrical Safety Precautions...
  • Page 18 www.pflow.com P 41 4 3 5 2 9 0 0 0 Important Safety Section 4 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Information Milwauke e , WI 5 3 2 0 9 Section 4 | 8 21 Se ies | 15707-0004 | Rev | 2018-10-15 | e-mail psd@pflow.com...
  • Page 19 www.pflow.com P 41 4 3 5 2 9 0 0 0 Entrance Below a F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Raised Carriage Deck Milwauke e , WI 5 3 2 0 9 Safety First The mo st c o mmo n re aso n to ac c e ss the are a be low a raise d c arriage de c k is to c le an de bris fro m the pit o r ho istway.
  • Page 20 www.pflow.com P 41 4 3 5 2 9 0 0 0 Entrance Below a F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Raised Carriage Deck Milwauke e , WI 5 3 2 0 9 Pit Access Ac c e ss to the are a be ne ath the raise d c arriage de c k c an be gaine d thro ugh manual meas es implemented...
  • Page 21 Although the wording and descriptions may sound familiar to the person who has read the manual, other terms and descriptions might not. It is recommended by PFlow Industries, Inc. that this glossary be reviewed before reading the remainder of this manual.
  • Page 22 www.pflow.com P 41 4 3 5 2 9 0 0 0 Glossary Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 A horizontal conveyor that is driven by separate loops of chain or a continuous Chain Driven Live Roller chain.
  • Page 23 www.pflow.com P 41 4 3 5 2 9 0 0 0 Glossary Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Drive chains on the F series mechanical VRC, through a series of a sha and Drive chain sprockets allow the carriage to be raised and lowered.
  • Page 24 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 The drawing produced by PFlow Industries, Inc. which shows the VRC General Arrangement li , gates, and enclosures. The drawing may show but does not specify (GA) drawing building details.
  • Page 25 www.pflow.com P 41 4 3 5 2 9 0 0 0 Glossary Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 A permanent-working surface at a xed elevation used for loading or unloading Landing the carriage.
  • Page 26 www.pflow.com P 41 4 3 5 2 9 0 0 0 Glossary Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 A sensor which detects hydraulic pressure.
  • Page 27 Conveyor (VRC) these objects from one operating elevation to another. ecification PFlow Industries, Inc. informational data sheet providing general information on a speci c VRC. sheet Sub-assembly fastened to the carriage upright that contains the guide roller Wheelblock assembly elements and safety cam for the chain driven VRC li .
  • Page 28 www.pflow.com P 41 4 3 5 2 9 0 0 0 Glossary Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Gate Types: This type of gate hinges on one side and latches on the other, may be either Single swing gate...
  • Page 29 Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 21 Series Straddle Sprocket Drivebase assembly Jackscrew Guide column, Column...
  • Page 30 Glossary Section 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 21 Series Cantilever Sprocket Drivebase assembly Jackscrew...

  • Page 31: Requirements 6

    www.pflow.com P 41 4 3 5 2 9 0 0 0 Electrical Standards Section F 41 4 3 5 2 9 0 0 2 efinition 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 All electrical wiring and cra smanship completed in the eld shall be Field Electrical in accordance with existing state, local and National Electrical Code...
  • Page 32 NEMA 12 classi cation is to be used in a general purpose, indoor only application. All PFlow Industries, Inc. control systems are built to a NEMA 12 minimum classi cation. All PFlow Industries, Inc. control systems conform to the following standards: NFPA 70 (NEC): The National Electrical Code.
  • Page 33 www.pflow.com P 41 4 3 5 2 9 0 0 0 Electrical Standards Section F 41 4 3 5 2 9 0 0 2 efinition 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 tan ar contin e a ar o...
  • Page 34 www.pflow.com P 41 4 3 5 2 9 0 0 0 Electrical Standards Section F 41 4 3 5 2 9 0 0 2 efinition 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Section 15709-0085 | Rev - | 2018-04-20 | e-mail psd@pflow.com...

  • Page 35: Mechanical Overview 15707-0009 7

    www.pflow.com P 414 352 9000 Mechanical Overview Section 7 | F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Mechanical Each Series 21 (hydraulic) Vertical Reciprocating Conveyor (VRC) consists of two (2) columns, hydraulic pump and motor, hydraulic actuating mechanism, Overview a moving carriage deck, enclosures, and if furnished, interlocked safety gates or doors.

  • Page 36: Hydraulic Pump And Motor 7

    Install the hydraulic pump and motor on a level, static, and solid foundation Considerations at the recommended oor level listed on the PFlow Industries, Inc. General Arrangement (GA) drawing. Install the hydraulic pump and motor in a location that is easily accessible.

  • Page 37: Velocity Fuse 7

    www.pflow.com P 414 352 9000 Mechanical Overview Section 7 | F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Wheelblocks Wheelblocks are bolted to the carriage uprights. This allows the wheels to ride within the li columns and guide the carriage travel. See Figure 7-4 and Figure 7-5.
  • Page 38 The enclosure panels are steel with 1-1/2" (38mm) angle frame and 16 gauge attened expanded metal designed to reject a ball 2" (51mm) in diameter. PFlow Industries, Inc. standard enclosure panels are typically 8' tall (2438mm). Full height enclosures (FHE) are furnished when designed for site speci c requirements.
  • Page 39 See Figure 7-8. PFlow Industries, Inc. o ers various styles of interlocks depending upon the gate type and application. The parts section of this manual contains views with part numbers.
  • Page 40 www.pflow.com P 414 352 9000 Mechanical Overview Section 7 | F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Examples 1. Bi-Panel Swing Gate 2. Single Panel Swing Gate 3. Vertical Acting Sliding Gate 15690-0002-S.SMG 16520-1000.SMG PFL-1875-8 4. Sliding Gate PFL-3076G Gate Examples Figure 7-9 Peelle - VAC Figure 7-10...

  • Page 41: Electrical Overview 15709-0018 8

    www.pflow.com P 41 4 3 5 2 9 0 0 0 Electrical Overview Section 8 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Electrical The following is a standard description of the electrical wiring of an D series Overview...
  • Page 42 www.pflow.com P 41 4 3 5 2 9 0 0 0 Electrical Overview Section 8 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 The pump and motor has three (3) electrical components: a motor, a pressure Hydraulic Pump switch, and an electrically actuated valave.

  • Page 43: Sequence Of Operation 15707-0010 9

    If a maintenance operation requires the carriage to remain in the raised position, refer to Bulletin 15709-0083 for additional information or contact PFlow Industries, Inc. Product Support Department for assistance. Always return the carriage to the lowest level when the VRC is not in use.
  • Page 44 www.pflow.com P 41 4 3 5 2 9 0 0 0 Sequence of Operation Section 9 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 1.

  • Page 45: Sequence 9

    www.pflow.com P 41 4 3 5 2 9 0 0 0 Sequence of Operation Section 9 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 5.

  • Page 46: To Operate The Lift 9

    www.pflow.com P 41 4 3 5 2 9 0 0 0 Sequence of Operation Section 9 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 1.
  • Page 47 www.pflow.com P 41 4 3 5 2 9 0 0 0 M anual Lowering Section 10 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Before You Begin Read this entire manual before operating the Vertical Reciprocating Conveyor (VRC).
  • Page 48 www.pflow.com P 41 4 3 5 2 9 0 0 0 M anual Lowering Section 10 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Section 10 | 2 Se ies | 15702-0008 | Rev - | 2018-10-01 | e-mail psd@pflow.com...
  • Page 49 www.pflow.com P 41 4 3 5 2 9 0 0 0 Cleaning - VRC Section 1 1 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Do not use any corrosive or ammable solvents or cleaning agents on the machine that contain TRI, PER, TETRA, or FCHC.
  • Page 50 www.pflow.com P 41 4 3 5 2 9 0 0 0 Cleaning - VRC Section 1 1 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 2 | Section 11 15709-0088 | Rev - | 2018-08-15 | e-mail psd@pflow.com...
  • Page 51 A record of regular, properly conducted preventive maintenance provides a running history of any issues the VRC may have. The reports will identify trends, and helps anticipate expected wear and tear repairs. Sign and return to PFlow Industries, Inc. Product Support Department via e-mail to psd@p ow.com ASME B20.1-2015 defines a qualified person as a person who, by possession of a...
  • Page 52 P 41 4 3 5 2 9 0 0 0 21 Series Preventive Section 1 2 | F 41 4 3 5 2 9 0 0 2 M aintenance and 6 7 2 0 N. Te uto nia Ave .
  • Page 53 P 41 4 3 5 2 9 0 0 0 21 Series Preventive Section 1 2 | F 41 4 3 5 2 9 0 0 2 M aintenance and 6 7 2 0 N. Te uto nia Ave .
  • Page 54 Extreme temperatures below 32°F (0°C) or above 100°F (38°C) and corrosive atmosphere may a ect oil requirements. Consult PFlow Industries, Inc. Product Support Department for assistance. PFlow Industries o ers four (4) di erent ISO 32W oils. Oil Offered Standard - PFlow part #9000-9700...
  • Page 55 P 41 4 3 5 2 9 0 0 0 21 Series Preventive Section 1 2 | F 41 4 3 5 2 9 0 0 2 M aintenance and 6 7 2 0 N. Te uto nia Ave .
  • Page 56 P 41 4 3 5 2 9 0 0 0 21 Series Preventive Section 1 2 | F 41 4 3 5 2 9 0 0 2 M aintenance and 6 7 2 0 N. Te uto nia Ave .
  • Page 57 www.pflow.com P 41 4 3 5 2 9 0 0 0 Troubleshooting Section 1 3 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Before You Begin Read this entire manual before any troubleshooting and service is attempted on the Vertical Reciprocating Conveyor (VRC).
  • Page 58 www.pflow.com P 41 4 3 5 2 9 0 0 0 Troubleshooting Section 1 3 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 The following table identi es some of the most common issues with the VRC, the possible causes, and the suggested solution.
  • Page 59 www.pflow.com P 41 4 3 5 2 9 0 0 0 Troubleshooting Section 1 3 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 M alfunction Possible Cause Solution...
  • Page 60 www.pflow.com P 41 4 3 5 2 9 0 0 0 Troubleshooting Section 1 3 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 M alfunction Possible Cause Solution...
  • Page 61 6720 N. Teutonia Ave. Overload Sensor Milwaukee, WI 53209 Before You Begin Read this entire manual. The PFlow Industries, Inc. D series Vertical The Purpose of the Reciprocating Conveyor (VRC) is equipped Motor Overload with a Motor Overload Sensor (MOL). The MOL...
  • Page 62 www.pflow.com P 414 352 9000 Adjust Motor Section 14 | F 414 352 9002 6720 N. Teutonia Ave. Overload Sensor Milwaukee, WI 53209 Section 14 | 2 and 21 Se ies | 15702-0022 | Rev - | 2018-05-01 | e-mail psd@pflow.com...
  • Page 63 This list is a guide to assist the customer in establishing an emergency inventory for your PFlow Industries, Inc. VRC. Convenience and minimal down time are two good reasons to maintain an inventory of spare parts. This list does not imply that any part is subject to failure.
  • Page 64 Section 1 5 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . 21 Series Milwauke e , WI 5 3 2 0 9 2 | Section 15 21 Se ies | 15707-0013 | Rev - | 2018-10-15 | e-mail psd@pflow.com...
  • Page 65 - in Face Seal 3 8 ale ipe Fittin Red ce 1 2 72 0-000 3 8 F ** Contact PFlow Industries, Inc. Parts Department for part number. VRC serial number required. PFL-181003 PFL-181003-2 PFL-181003-1 21 Se ies | 15707-0014 | Rev - | 2018-10-15 | e-mail psd@pflow.com...
  • Page 66 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Carriage Stop Item Qty Part No.
  • Page 67 Co plin nse t 1107 8 -0 0 2 2 * Not Shown on Illustration ** Contact PFlow Industries, Inc. Parts Department for part number. VRC serial number required. 16217-7253.SMG PFL-181003-4 21 Se ies | 15707-0014 | Rev - | 2018-10-15 | e-mail psd@pflow.com...
  • Page 68 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 The following drawings illustrate Chain Loop the path of the li chain and...
  • Page 69 R ate Resistant wit 029-0020 Sc ew C 1 4-20 1-1 4 ** Contact PFlow Industries, Inc. 5858-0009 as e Std 1 4 Parts Department for part number. VRC serial 5834-0001 t 1 4-20 wit Sp in number required.
  • Page 70 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 The interlock is a device used to mechanically prevent the gate from opening.
  • Page 71 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 A gate status switch is supplied when the contact are not being used.
  • Page 72 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Upper Wheelblock Assembly Phenolic Wheel 5-1/ 2"...
  • Page 73 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Lower Wheelblock Assembly Phenolic Wheel 5-1/ 2"...
  • Page 74 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Upper Wheelblock Assembly Phenolic Wheel 5-1/ 2"...
  • Page 75 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Upper Wheelblock Assembly Steel Wheel 5-1/ 2"...
  • Page 76 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Lower Wheelblock Assembly Steel Wheel 5-1/ 2"...
  • Page 77 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Upper Wheelblock Assembly Steel Wheel 5-1/ 2"...
  • Page 78 www.pflow.com P 41 4 3 5 2 9 0 0 0 Parts Section 16 | F 41 4 3 5 2 9 0 0 2 6 7 2 0 N. Te uto nia Ave . Milwauke e , WI 5 3 2 0 9 Section 1 | 14 21 Se ies | 15707-0014 | Rev - | 2018-10-15 | e-mail psd@pflow.com...
  • Page 79 www.pflow.com P 414 352 9000 Recommended Storage Section 17 | F 414 352 9002 6720 N. Teutonia Ave. Requirements - Hydraulic Milwaukee, WI 53209 Environment All components should be stored indoors. The area of storage should be kept at a constant temperature above 55ºF (13ºC) and relative humidity of approximately 40%, free from heavy dust and contaminants.
  • Page 80 The VRC installation manual, electrical, and owner’s manuals are located in the parts container (crate). Do not open the parts container (crate). If the manuals are required, contact the PFlow Industries, Inc. Product Support Department for an electronic copy (.pdf). Section 17 | 2 15709-0080-1 | Rev | 2018-10-01 | e-mail psd@pflow.com...
  • Page 81 PFlow Industries, Inc. supplies the appropriate signage in a manilla envelope in the parts crate with the original shipment. Contact PFlow Industries, Inc. Product Support Department for signage if another language is needed.
  • Page 82 www.pflow.com P 414 352 9000 Signage Locations Section 1 | F 414 352 9002 6720 N. Teutonia Ave. Milwaukee, WI 53209 Section 18 | 2 15709-0035 | Rev C | 2018-04-01 | e-mail psd@pflow.com...
  • Page 83 Milwaukee, WI 53209 Thank You PFlow Industries, Inc. would like to thank you for the opportunity to serve you. Your business is appreciated. Please help us to ensure that your expectations are met by taking a few minutes to tell us about the equipment and service that you have received.
  • Page 84 www.pflow.com P 414 352 9000 Section 19 | Installation F 414 352 9002 6720 N. Teutonia Ave. Questionnaire Milwaukee, WI 53209 Section 19 | 2 15708-1500 | Rev F | 2018-04-01 | e-mail psd@pflow.com...
  • Page 85 Acceptance Date: Name/Phone: PFlow Rep Present: Title: Name: Company: Company: Please return a copy of this form to the PFlow Industries, Inc. Customer Support Department at csd@p ow.com. 15710-0017-VRC | Rev G | 2023-11-15 | e-mail csd@pflow.com Section 20 | 1...
  • Page 86 www.pflow.com P 414 352 9000 Acceptance Section 20 | F 414 352 9002 Certification - VRC 6720 N. Teutonia Ave. Milwaukee, WI 53209 Section 20 | 2 15710-0017-VRC | Rev G | 2023-11-15 | e-mail csd@pflow.com...
