Red Arrow CMT50Y Installation Instructions

Safety Warning
•
The installation should be carried out
by a qualified electrician in compliance
with the current edition of the IEE
Wiring Regulations.
•
Prior to installation, carry out the
necessary risk assessment considering
the people who could be at risk,
the level of risk and the precautions
required to control the risk
•
Ensure that the circuit supply is
isolated either by the circuit supply
fuse being removed or the applicable
Specification
Box Contents -
1 x Comet Site Floodlight and mounting bracket
CMT50Y: L: 216 x W: 212 x D: 32mm. Weight: 0.846kg. Max Projected Area: 0.0284m2
CMT100Y: L: 251 x W: 290 x D: 37mm. Weight: 1.445kg. Max Projected Area: 0.0459m2
Dimensions:
CMT150Y: L: 311 x W: 348 x D: 40mm. Weight: 2.12kg. Max Projected Area: 0.0683m2
CMT200Y: L: 374 x W: 414 x D: 41mm. Weight: 3.09kg. Max Projected Area: 0.1014m2
Body: Die-Cast Aluminium
Material:
Lens: Tempered Glass
Working
Standard: -30°C - 45°C
Temperature:
Guarantee: 3 Years
3
50-200
YRS
WATT
GUARANTEE
MAXIMUM FITTINGS PER CIRCUIT
Automatic Circuit Breaker Type:
Rated Current:
Cable (mm):
CMT50Y
CMT100Y
CMT150Y
CMT200Y
Installation Instructions
Note: This is a Class I Luminaire - Earth connection is required
This is an IP65 rated product. Do not break or loosen any seals as this will affect the IP rating and will render the warranty void.
1. Isolate the mains supply before commencing the installation.
2. Ensure there is adequate free air circulation of at least 100mm around the luminaire. All luminaires run hot. It is the installer's responsibility to consider any
fire risks and take appropriate precautions.
3. The nearest illuminated surface must be at least 0.5m from the front of the fitting.
4. Do not install or use if the glass is broken. Replace the luminaire. The pre-wired cable is not replaceable. If it is damaged, replace the luminare.
5. Select a suitable, solid mounting surface and fixings that are capable of holding the weight of the luminaire. Maximum installation height is ≤ 5m.
INSTALLATION INSTRUCTIONS
Comet Site Slim Floodlights
Product Codes: CMT50Y, CMT100Y, CMT150Y, CMT200Y
IP65
4000K
B6 B10 B13 B16
6A 10A 13A 16A
1.5 1.5 1.5 2.5
8 13 17 21
4 6 8 10
2 4 5 7
2 3 4 5
circuit breaker being turned off before
installation or any maintenance.
•
Check the total load on the circuit
ensuring the luminaire does not exceed
the rating of the circuit cable, fuse or
circuit breaker.
•
Long-term use and voltage fluctuations
can reduce the life span of the fitting.
•
If the fitting incorporates control gear,
ensure careful sizing to avoid instances
of nuisance tripping of the protective
device used in the installation.
LED
110V
B20 C10 C13 C16
20A 10A 13A 16A
2.5 1.5 1.5 2.5
25 16 21 25
13 8 10 13
8 5 7 8
6 4 5 6
•
Follow the provided installation
instructions, using the fixings supplied
or recommended.
•
Keep out of reach of children.
Lmm
Dmm
5000- IK06
20000LM
/IK07
C20
20A
2.5
25
16
10
8
Wmm
