- Page 1 VERMEIREN 2202 2215 2217 2219 INSTALLATION MANUAL MANUEL D'INSTALLATION INSTALLATIEHANDLEIDING INSTALLATIONSANLEITUNG MANUALE DI INSTALLAZIONE MANUAL DE INSTALACIÓN INSTRUKCJA INSTALACJI PŘÍRUČKU PRO INSTALACI...
-
Page 3: Table Of Contents
Tricycles 2023-06 Preface Contents Preface........................2 This product ....................3 Scope of delivery ..................5 Tools ......................5 Assembly and adjustments ................. 6 Torque ......................7 Adjust the brakes .................... 8 Adjusting the chain ..................8 4.3.1 2202, 2215 ................... 8 4.3.2 2217, 2219 ................... -
Page 4: Preface
To support you on the installation and repairs of this tricycle, this manual is offered. Please read it carefully. If you still have questions after reading this manual, do not hesitate to contact Vermeiren. The information in this manual applies to all tricycles in the following list: ... -
Page 5: This Product
Tricycles 2023-06 This product This product 1. Handgrips 2202 2. Bell 3. Handlebar 4. Brake levers 5. Front reflector 6. Mudguards 7. Front brakes 8. Front wheel 9. Frame 10. Pedals 11. Chain cover 12. Rear wheels 13. Rear reflector 14. - Page 6 Tricycles 2023-06 This product 1. Handgrips 2217 2. Bell 3. Handlebar 4. Brake levers 5. Front reflector 6. Mudguards 7. Front brakes 8. Front wheel 9. Frame 10. Pedals 11. Chain cover 12. Rear wheels 13. Rear reflector 14. Tray 15.
-
Page 7: Scope Of Delivery
Tricycles 2023-06 Scope of delivery Scope of delivery The following items are part of the delivery. 1 frame with rear and front wheels pedals saddle handlebar + handgrips bell basket instruction manual accessories Tools To repair and adjust the tricycle, the following tools are needed: ... -
Page 8: Assembly And Adjustments
Important remark Read the user manual of this tricycle. Be aware of the technical details and limits of intended use; see the user manual. For more information, contact Vermeiren. See the website http://www.vermeiren.com/. Installation manual - 6 -... -
Page 9: Torque
Tricycles 2023-06 Assembly and adjustments Torque 2202, 2215 2217, 2219 Installation manual - 7 -... -
Page 10: Adjust The Brakes
Tricycles 2023-06 Assembly and adjustments Adjust the brakes 1. The brake tightness can be adjusted by the brake cable adjuster . Adjusting the chain 4.3.1 2202, 2215 The wheels of the tricycle are driven by a chain on the rear axle. For first time use the chain ... -
Page 11: Adjusting The Handlebar
Tricycles 2023-06 Assembly and adjustments Tightening driving chain : Loosen the nut . The wheel can now be moved upwards to tighten the chain . When the chain between the two chain-wheels can be moved ± 20 mm, the chain tension is correct. Retighten the nut . - Page 12 Tricycles 2023-06 Assembly and adjustments Assembly: WARNING: Risk of injury - Check that the pressure is correct. CAUTION: Risk of injury - Make sure that no objects or body parts are pinched between the tyre and the rim when mounting a tyre. 2202, 2215 Put the deflated tube around the center of the rim.
- Page 13 Tricycles 2023-06 Assembly and adjustments Check all around on both sides that the tube is not pinched between the rim and the edge of the tyre. Lightly push the air valve inwards and pull it out again to make sure that the tyre is positioned properly in the region of the air valve.
- Page 16 Vermeiren GROUP Vermeirenplein 1 / 15 2920 Kalmthout website: www.vermeiren.com Instructions for specialist dealer This instruction manual is part and parcel of the product and must accompany every product sold. Version: A, 2023-06 Basic UDI: 5415174 1218062202 4U 5415174 1218062215 55...
